TNG Alert- Ingres LogFile Full !

1
TNG Alert- Ingres LogFile Full !

• Dennis Adams Keith McLennan
• BNP Paribas

2
Or...How to build a simple messaging interface
to TNG

• with emphasis on simple !

3
Health Warning

• This is not intended to be a build your own TNG
  Agent course
• It is not a replacement for TNG Agents or
  monitoring tools.
• No graphics or trend analysis
• Uses quick and dirty approach.
• Need to have some understanding of Unix Shell
  Scripting

4
Why we started this

• Collecting Data from Ingres already using
  Monitoring Tools
• Already using Unicenter/TNG as the Alert Console
  for Operators
• Didnt want yet another console on the
  Operators Bridge.
• Why not send messages to TNG instead ?
• KISS !

5
Task Breakdown

• Ingres
• Custom script to monitor the Ingres Log file
• Has a threshold has been exceeded ?
• Should we send a message to TNG ?
• Format Message and send to the TNG console
• Unicenter
• Configure TNG Console to receive messages
• Incoming Messages create icons in Unispace
• Define Message Actions to display icons

6
Ingres Setup
7
Monitoring Ingres Log File

• Use Standard Ingres utilities piped through grep
  and awk.
• Be aware of Ingres version differences...

if -f II_SYSTEM/ingres/bin/cbf then
PERCENTlogstat grep Percent \ awk print
9 else PERCENTlogstat grep Percent
\ awk print 7 fi echo Log Usage is
PERCENT
8
Monitoring Ingres Log File (2)

• Using the IMA (Ingres II only)
• then parse the output !

sql -uingres imadb execute procedure
ima_set_vnode_domain \g select from
ima_lgmo_lfb\g \quit
9
Scheduling Monitoring

• Crontab scheduling as a last resort.
• Ensure environment is set up OK.
• II_SYSTEM
• PATH
• LD_LIBRARY_PATH
• export II_SYSTEM PATH LD_LIBRARY_PATH
• Run a crontab under Ingres, or use a valid ingres
  user

10
Privileges

• To use trace points like DM420
• ensure user has correct privs in accessdb.
• Ingres II
• edit config.dat to allow user to run infodb etc.
• Add the line ii.MACHINE_NAME.privileges.user.
  MONI_USERSERVER_CONTROL,NET_ADMIN,MONITOR,TRUSTED

11
Checking for Thresholds

• Standard Shell logic..

if PERCENT -ge 60 then echo Houston, we
might have a problem fi
12
Minimising Message Traffic

• Advisable to reduce SNMP traffic.
• Only send messages if state changed
• Create Temporary marker files to indicate
  whether message has been sent.
• After checking value..
• If a marker file exists - no action
• If marker file does not exist
• create one and send a message

13
GOODFILE/tmp/log_good_message_sent BADFILE/tmp/l
og_bad_message_sent If PERCENT -ge 60
then rm -f GOODFILE if ! -f BADFILE
then touch BADFILE echo Send Bad Message to
TNG fi else rm -f BADFILE if ! -f
GOODFILE then touch GOODFILE echo Send
Good Message to TNG fi fi
14
Sending Messages

• To send a message to Uncenter, raise a SNMP trap
  using awtrap

/opt/tng/factory/bin/awtrap \ ingsrv1
tngcons 162 public \ 1 6 3 1
\ E Ingres ingsrv1 log_file
Ingres_log_file_is_PERCENT_full UNICENTER
CONSOLE DISPLAYS.. CATD_I_60_SNMPTRAP -c public
unknown 6 3 000000 1 OID 1.0 iso 0 VALUE
E Ingres ingsrv1 Ingres
15
Awtrap

• TNG-supplied binary file installed on Agent
  Machines
• Used to forward SNMP messages to any
  SNMP-compliant console.
• Syntax
• awtrap from_addr local dest_addr
  port community enterprise type subtype
  oid "value"

16
Awtrap Parameters

• from_addr
• local or use the IP name of the originator
• dest_addr
• IP name of TNG DSM machine (more later..)
• port
• UDP/IP port for SNMP traps 162
• community
• public
• enterprise
• 1 indicates that it is an enterprise MIB entry

17
Awtrap Parameters (2)

• type
• 6 (major ID?)
• subtype
• 3 (minor ID - it works !!)
• oid
• 1 Should correspond to MIB definition.
• value
• Optional free-fomat text message. This is the
  feature we exploit in our solution.
• But first, we need to set up Unicenter...

18
TNG Configuration
19
TNG Architecture

• Agents
• Data collection software on monitored server
• DSM Distributed State Machine
• Polls Agents
• Receives Incoming traps forwards to CORE/EM
  (some basic filtering)
• EM Event Manager
• Scrolling Event Display and Message Actions.
• CORE Common Object Repository
• Database of 2D / 3D map info.

20
TNG Architecture
21
TNG Setup - Discovery

• Command-Line routine run on Console.
• Needed for setting up icons on 3-D map
• Creates entries in Core Database for machine
  discovered.
• Syntax
• C\gt dscvrone -r core lons000021
  -h node name -c Snmp community Name
  -u Core Username -p Password

C\gt dscvrone -r tngcons1 -h ingsrv1 -c
public -u admin -p letmein
22
TNG Setup - Filters

• Also need to change Filters
• ensure new machine is being polled, and incoming
  messages will be received.
• Edit Filter File on DSM to include this machine.
• AGENTWORKSDIR/services/config/
  aws_wvgate/gwipflt.dat
• similar layout to hosts file

23
SNMP Message Structure

• MIB Management Information Base
• Hierarchical message structure

24
MIBs and OIDs

• MIB Tree structure names and numbers are
  registered with Standards Body.
• OIDs
• unique object at the leaf of the MIB
• unique heirarchical name
• computer.applications.databases.ingres.log_file.pe
  rcent
• has unique Numeric representation
• 1.2.6.5.7.9.1.8.5.4.2.6.3.2.1
• unique meaning
• e.g. network router x is up

25
How TNG Processes Messages

• Incoming Messages Received by the DSM
• If OID number is in the MIB
• automatic action based on MIB structure
• If OID is non-standard
• forward to the Event Manager as a non-standard
  trap
• this is where we come in
• Event Manager Actions
• we program EM to ignore the OID
• parse the incoming message text.

26
Formatting Messages

• EM processes space-delimited words.
• Pad all spaces with _
• Send the OID of 1 so it gets passed to EM
• Only the text is important !

/opt/tng/factory/bin/awtrap \ ingsrv1
tngcons 162 public \ 1 6 3 1
\ E Ingres ingsrv1 log_file Ingres_log_file_
is_PERCENT_full
27
Parsing Messages

• E Ingres ingsrv1 log_file
  Ingres_log_file_is_PERCENT_full
• E/N Error / Normal
• Update CORE Create Folder called Ingres in
  Unispace for this machine
• Create Icon called ingsrv1_log_file in this
  Folder
• Change Icon to RED
• rest_of_text_as_one_word supplementary message

28
Creating Event Manager Message Actions

• Console - DSM - Events - Messages
• (Not Message Actions !)

29
Creating Event Manager Message Actions

• Enter Filter Pattern for the Message
• matched against incoming message, using
  wildcards
• Save.
• Chose Message Action
• Not exactly free-format text language !
• Card-based action line-by-line

CATD_I_60_SNMPTRAP -c public unknown 6 3
000000 1 OID 1.0 iso 0 VALUE E Ingres
30
Processing Incoming Messages

• Update the Application Icon (machine-category)
  to RED
• Send a Replacement Console Message

31
Creating Unispace Folder

• Create new Folder (Ingres-machine) if unable to
  update it.

32
Creating Icon

• Create Icon (machine-category), move it then
  update it.

33
Putting it all together
34
Putting it all together

• Schedule tasks using Crontab
• logstat grep to extract figures
• check for badfile/ goodfile to determine when
  to send SNMP Traps
• Send OID 1 Trap with formatted text string.
• Script TNG DSM to parse incoming text.
• Create icons in distinct folder in Unispace as
  required
• Change icon colour as required.

35
Disadvantages

• Alerting Only
• no trend analysis, graphing supporting data.
• Very limited functionality
• Error trapping for Ingres down ?
• Asynchronous Traps only
• No communication from DSM
• If data is collected just from shell scripts
• no keep-alive etc.
• collection scheduling is a nightmare.
• Crontab !

36
TNG Alert- Ingres LogFile Full !

• Dennis Adams Keith McLennan
• BNP Paribas
