ATML Test Description

1
ATML Test Description

• January 2006

2
Overview

• Format for exchanging the test description
  information defining test performance, test
  conditions, diagnostic requirements, and support
  equipment to locate, align, and verify proper
  operation of a UUT.
• Purpose
• Support the development of TPSs that will be used
  in an automatic test environment
• Test Program generation
• Test Requirement Document development and
  maintenance
• Test Description analysis, etc.
• Promote and facilitate interoperability between
  components of ATSs where UUT test requirement
  definitions need to be shared.
• Ex. Rehosting test requirements between ATS
  platforms

3
Overview

• Rehosting benefits
• Current TPSs are implemented with tight coupling
  between components. The components are typically
  developed specific to that particular
  architecture.
• Once the test program is fielded, the
  requirements and strategies used to initially
  develop the TPS typically become obsolete.
• As the ATS is replaced or achieves some level of
  obsolescence, it is typical to re-host the
  implementation of the TPS.
• This is a more expensive, time consuming task,
  than that if implementing the UUT test
  requirement on the newer Automatic Test Equipment
  (ATE) or as part of instruments replaced within
  the existing ATE.

4
Overview
5
Overview...

• UUT Description
• UUT description by name and nomenclature

6
Overview...

• Documentation
• References to all Documents, Drawings, Diagrams,
  Parts Lists associated with the UUT and its
  sub-assemblies (used to verify UUT operation).

7
Overview...

• General Data
• All of the General Data that may be of use in
  developing test scenarios.

8
Overview...

• Power Requirements

9
Overview...

• Interface Definition

10
Overview...

• Interface Definition (contd)

11
Overview...

• Interface Requirements
• The characteristics of equipment and circuitry
  required to test the UUT, excluding the Test
  Equipment (e.g. UUT Connector information).

12
Overview...

• Interface Requirements / Electrical

Reference to Connector Definition
13
Overview...

• Interface Requirements Pin Function

14
Overview...

• Interface Requirements / Mechanical, EO

15
Overview...

• Performance Characteristics
• Detailed description of the performance
  characteristics of the UUT.

16
Overview...

• Detailed Test Information
• All of the sufficient data for each UUT test to
  completely describe all input conditions and
  measurements required.

17
Overview...

• Failure Fault Data
• UUT Design Fault Data (Faults and Failures)

18
Overview...

• Failure

19
Overview...

• Fault

Reference to Component
Reference to Component / Pin
20
Overview...

• Components

21
Overview...

• ATPG
• All of systems level information sufficient to
  identify any Automatic Test Program Generation
  (ATPG) tool(s) (e.g. LASAR)

22
Overview...

• Detailed Test Information - Layers
• 1. Test Groups
• Subtypes
• Sequences describe fault trees as sequence of
  steps
• Parallel,
• Reasoner, ...
• Call Tests and other Test Groups
• 2. Tests
• Describe stimuli, measurements, limits and
  behavior (ex. actions)
• Tests that have common behavior may reference the
  same Test Template
• 3. Test Templates
• Contain data items common to multiple Tests
• Optional

23
Overview...

• Test
• Contents
• Outcomes
• Outcome is a special output used for sequencing
• Parameters (inputs)
• Test Results (outputs)
• Conditions
• Behavior
• Sequence of Actions
• User-defined
• Free-form description
• Ref. to Test Template (optional)

24
Overview...

• Test Group
• Contents
• Outcomes
• Parameters
• Test Results
• Conditions
• Initialization Termination
• References to other Test Entities
• Possible entry point (independently executable
  entity)

25
Overview...

• Test Sequence
• Specialization of Test Group
• Additional contents
• Steps
• Reference to Test or a Test Group (ex. Sequence)
• For each possible Outcome of the Test or Test
  Group
• 1. Reference to Next Step Components to Adjust
  (optional), or
• 2. Reference to Sequence Outcome (Entry Points
• Reference to Step

26
Schema Integration

• Adjusted root schema (from Draft N) for style
  consistency
• Streamlined the definition of UUT interface
• Created new type Connection, to allow the
  enforcement of referential integrity. Used in
  Parameters and in PowerRequirements.
• Enhanced the assignment of fault data to
  Outcomes, to better support the integration
• Individual Faults can be now be specified for
  Test Entity Outcomes (Draft 6 supported only
  faulty components)
• Connected the two parts of the schema through
  references

27
Schema Integration...

• Removed Fault Ambiguity Group data
• It can be reconstructed from fault information
  already present in instance documents
• Under UUT Power Requirements, replaced the type
  Characteristics from Common with a new, simpler
  type called Requirements.
• Assigned new type to individual parameters of
  power sources, to allow the specification of
  max/min limits and tolerances for multiple
  parameters of the same power source.
• Note Some elements are simply defined as strings
  (ex. SignalConditioning, Fixtures, etc.) these
  definitions may be extended or deleted, when
  verifying consistency with UUT Description

28
Test Templates (Design Change)

• During the last meeting a solution was proposed
  to simplify referencing of Test Templates by
  eliminating the Parameter elements residing under
  Test, when the parameters are inherited from the
  test template.
• A similar solution cannot be implemented for Test
  Results and Outcomes. All Test Result elements
  must exist under Test for referencing purposes.
  Similarly, all Outcome elements must exist under
  TestGroup, for referencing purposes.
• While potentially reducing the amount of data in
  instance documents, this solution would make the
  design inconsistent.
• The design from Draft 6 includes a set of rules
  that cannot be expressed in the XML schema (for
  example, when a Test inherits from a Test
  Template, all Test Result, Parameter and Outcome
  elements must contain references to the
  corresponding Template elements).
• The new solution simplifies the referencing of
  Test Templates by using the order of elements in
  collections

29
Test Templates (Design Change)...

• Test Templates
• Optional
• Used to model commonality in Test functionality

30
Test Templates (Design Change)...

• Overriding Test Template data in Test
• When a Test inherits from a Test Template, it
  shall contain exactly one corresponding element
  for each of the Outcomes, Parameters and Test
  Results of the Test Template. The correspondence
  between Test elements and Test Template elements
  shall be determine by their order in the
  collections. For example, the second Parameter of
  the Test inherits from the second Parameter of
  the Test Template.
• When a Test inherits from a Test Template, all
  its Outcome elements shall have FromTestTemplate
  children. This rule models the fact that Outcomes
  inherited from the Test Template cannot be
  overridden.
• When a Test inherits from a Test Template, its
  Behavior element shall have a FromTestTemplate
  child. This rule models the fact that Behavior
  inherited from the Test Template cannot be
  overridden.

31
Description of Measured Values (Design Change)

• The original solution was not extensible
• The set of data types was represented by an
  enumeration simple type. This type is no longer
  extensible.
• The representation of default values for
  collections and arrays was not very good -
  consistency between the descriptive part and the
  default value part had to be maintained by the
  producer.
• New solution
• Changed former Measurement type into
  ValueDescription type, similar to cValue.
• Matching data types for the child elements.
• The data types for the terminal elements
  (doubleDescription, doubleArrayDescription, etc.)
  are similar to the types from Common, but instead
  of the required value have an optional default
  value.
• Advantages
• Ensures extensibility
• Offers a better mechanism for representing
  default values
• Is more consistent with Value associated types
  from Common
• May be included in the Common schema

32
Description of Measured Values (Design Change)...
33
Description of Measured Values (Design Change)...
34
Description of Measured Values (Design Change)...
35
Default Value for Signal Measurement (Design
Change)

• Added Default Value
• Applies to the measured signal attribute
• The ATML type must be consistent with the type of
  the measured attribute
• To Do Define mapping from 1641 signal attribute
  types to ATML data types

36
Names of Parameters and Test Results (Design
Change)

• Attribute name of Parameter/Local is now
  required
• For consistency, the attribute name of
  TestResult/Local is also required
• Q Add uniqueness constraints (name to be
  unique for a Test Entity Test Template)?
• Note that ID provides a unique identifier
• However, having two parameters with the same name
  may be confusing...

37
Conditions (Design Change)

• Removed Exit Conditions
• In AI-ESTATE, the intent of preconditions is to
  override optimization process.
• I interpreted this as verification (off-line or
  at run-time), and not automatic execution of a
  procedure that would make the condition happen.
• This is consistent with use cases from NI, TYX
  and Indra
• Without automatic execution, the concept of Exit
  Conditions is no longer applicable.
• Abandoned Setup Actions
• During the last meeting a solution was proposed
  to assign Setup Actions to values of state
  variables. The Setup Actions would be
  automatically executed to set the state variable.

• The solution was proposed in response to the
  question what should the application executive
  do if more that one Test or Test Group can make a
  precondition true?. As automatic execution is no
  longer envisioned, this is no longer a problem
• Preserved Post Conditions
• As a side effect of the above solution, Tests are
  no longer required to change state variables. But
  this situation may occur in applications. Thus, I
  believe Post Conditions associated with Tests are
  still necessary. This is consistent with
  effects in AI-ESTATE.

38
Conditions (Design Change)...

• Q Rename Post Conditions to Effects?
• For consistency with AI-ESTATE
• Q Use predicates instead of state variables?
• The two approaches are equivalent.
• Predicates are consistent with AI-ESTATE.
• Not clear how predicates are used in AI-ESTATE.
• Effects imply that predicates become true.
• In applications, Tests could cause predicates to
  become false (ex. Power in ON becomes false
  when power is turned off)

39
Specification of Fault/Failure Data (Design
Enhancement)

• Fault/failure data can now be specified for any
  Test Entities in the fault tree
• In Draft 6, could be specified only for terminal
  Test Entities.
• This ensures consistency with AI-ESTATE.

Applicable to any Test or Test Group
40
Other Design Changes

• Multiple Test Results can be referenced as the
  source of a Parameter.
• TestGroup_Unspecified and TestGroup_Parallel can
  now reference Test Entities (Tests and Test
  Groups) . Before they could only reference Tests.
• Initialization and Termination can now reference
  a Test Entity (Test or Test Group). Before they
  could only reference a Test Group.

41
Open Issues

• Associate Post-Conditions with Test Outcomes
• During the last meeting a solution was proposed
  to associate post-conditions with specific
  Outcomes of Test and Test Groups. This was in
  response to the question what does it mean for
  post-conditions if a Test returns a Failed
  outcome?.
• There are two problems with this solution
• In AI-ESTATE effects do not depend on the
  Outcome.
• It is likely that a Test would change the UUT
  state in the same manner, regardless of the
  Passed/Failed Outcome it returns.
• The Outcome is typically calculated based on a
  measurement, while the state change is the result
  of stimulus operations, which typically occur
  before the measurement.
• Proposed solution
• Keep the current design post-conditions are
  associated with Tests Entities
• Add rule If a Test Entity returns an Aborted
  outcome, the values of the state variables
  referenced by its post-conditions shall be
  considered unknown. Pre-condition relative to
  those state variable shall be considered not
  fulfilled.
• In general, it is impossible to know if the Test
  failed before of after changing the UUT state.

42
Open Issues...

• Q Do adjust actions apply to terminal steps?
• In the current design, they do not.
• To support the feature, move AdjustComponent one
  level up, under Result.

43
Open Issues...

• Q Should we support parametrized Test Group
  calls?
• The current design does not
• Test is a call
• Test Group is a definition
• Possible solutions
• 1. Create a Test Group Call element.
• A sequence Step would reference this element,
  which in turn would reference a Test Group.
• Associate parametric data and fault data to the
  Test Group Call element.
• Two Test Group Calls could reference the same
  Test Group, but two Steps cannot reference the
  same Test Group Call.
• 2. Enable a Test to be a Test Group call (in
  addition to the currently supported behaviors).
• In this case, parametric data and fault data
  would be associated to the Test (this is
  currently supported), but not to the Test Group.
• For parametric data associated with a Test Group,
  we may support a description (i.e., data type
  unit, but not value).

44
Open Issues...

• Q Do we want to be able to define Conditions for
  Test Templates and inherit them in Tests?
• This may make sense, as the common functionality
  captured by the Test Template is likely to
  include the effect on UUT state.
• Not supported now.
• Q Add support for variables?
• Many test executives support variables. Not
  supporting them in Test Description would limit
  the exchange of Test Description data between
  these test executives.
• On the other hand, the significant differences
  between the sequencing models of test executives
  impose serious limitations of data exchange.
• Q DiagTestDescription/EntryPoints/EntryPoint is
  a reference to TestEntity, which can be a Test
  Group (ex. Sequence) or a Test. This means that
  Tests could be executed individually. Is this a
  good idea?

45
Indra Issues

• Why the AdjustComponent element is under
  TestGroupSequence and not under Outcome or
  TestEntity. Would not it be the same case than
  "ReplaceComponent"?
• In the typical DTIs there is an "Adjust" field at
  the same level that the "Replace" field.
• Current design
• Replace Components apply to all types of Test
  Entities, to support static fault trees, as well
  as reasoners.
• Adjust Components apply only to steps of
  sequences, to support modeling of TRDs
• May be changed.
• Q Where to move AdjustComponent?

46
Indra Issues...

• Dont allow "ReplaceComponents" element at Test
  Group level
• Should assign fault data for a particular call of
  the Test Group, rather than to the Test Group
  itself
• This is similar to the problem described before
  for Parameters

47
Common.xsd Issues

• The set of units is not extensible. This may
  cause problems when reverse engineering existing
  TPSs, where incorrect or non-standard units are
  used.
• Suggestion design an extensible solution.
• Collection has a global unit (applies to all
  items) and also a local unit.
• The global unit is not necessary (the intent of
  Collection is to represent a set of heterogeneous
  items) and may be confusing (what means if both
  are present and different?).
• Suggestion remove the unit attribute of
  Collection. Also, adjust CollectionDescription
  for consistency.

48
STDTSFLib.xsd Issues

• Removed attributes abstract false from
  elements. The original schema generates the a
  validation error in XML Spy (its OK for the .NET
  parser)
• Note Removing this attribute does not change the
  operation of the schema. It may be accommodated
  in the stylesheet that converts XML to XSD.

49
STDTSFLib.xsd Issues...

• Replaced the character µ with u. The original
  schema generated a validation error with the .NET
  parser (XML Spy does not complain)
• Note Removing this attribute does not change the
  operation of the schema. It may be accommodated
  in the stylesheet that converts XML to XSD.

50
STDTSFLib.xsd Issues...

• Temporarily removed limits for values of
  attributes derived from Physical. The original
  schema generates a validation error in XML Spy
  and a validation error in the .NET parser
• Note Removing this attribute eliminates a useful
  validation feature. We should find a different
  way of expressing the constraints.

51
STDTSFLib.xsd Issues...

• The sample StdSignals.xml does not validate with
  XML Spy (2006 SP2) but validates with the .NET
  parser. The IDREFS attribute shown below
  generates a validation error
• Note I believe this worked with an earlier
  version of XML Spy...
