Multi-Agent Systems Lecture 10 University

1
Multi-Agent SystemsLecture 10University
Politehnica of Bucarest2005-2006Adina Magda
Floreaadina_at_cs.pub.rohttp//turing.cs.pub.ro/bl
ia_06
2
Machine LearningLecture outline

• 1 Learning in AI (machine learning)
• 2 Reinforcement learning
• 3 Learning in multi-agent systems
• 3.1 Learning action coordination
• 3.2 Learning individual performance
• 3.3 Learning to communicate
• 3.4 Layered learning
• 5 Conclusions

3
1 Learning in AI

• What is machine learning?
• Herbet Simon defines learning as
• any change in a system that allows it to perform
  better the second time on repetition of the same
  task or another task drawn from the same
  population (Simon, 1983).
• In ML the agent learns
• knowledge representation of the problem domain
• problem solving rules, inferences
• problem solving strategies

3
4
Classifying learning

• In MAS learning the agents should learn
• what an agent learns in ML but in the context of
  MAS - both cooperative and self-interested agents
• how to cooperate for problem solving -
  cooperative agents
• how to communicate - both cooperative and
  self-interested agents
• how to negotiate - self interested agents
• Different dimensions
• explicitly represented domain knowledge
• how the critic component (performance evaluation)
  of a learning agent works
• the use of knowledge of the domain/environment

4
5
Single agent learning
Learning Process
Feed-back
Data
Environment
Learning results
Problem Solving K B Inferences Strategy
Feed-back
Results
Performance Evaluation
5
6
Self-interested learning agent
Feed-back
Communication
Data
Environment
Actions
Feed-back

• NB Both in this diagram and the next, not all
  components or flow arrows are always present - it
  depends on the type of agent (cognitive,
  reactive), type of learning, etc.

6
7
Cooperative learning agents
Feed-back
Learning Process
Learning Process
Feed-back
Communication
Learning results
Learning results
Data
Results
Results
Performance Evaluation
Feed-back
Actions
Actions
Communication
Communication
Environment
7
8
2 Reinforcement learning

• Combines dynamic programming and AI machine
  learning techniques
• Trial-and-error interactions with a dynamic
  environment
• The feedback of the environment reward or
  reinforcement
• search in the space of behaviors
  genetic algorithms
•
• Two main approaches
•
• learn utility based on statistical techniques
  and dynamic programming methods

8
9
2.1 A reinforcement-learning model

• B agent's behavior
• i input current state of the env
• r value of reinforcement
• (reinforcement signal)
• T model of the world
• The model consists of
• -         a discrete set of environment states S
  (s?S)
• -         a discrete set of agent actions A (a ?
  A)
• -         a set of scalar reinforcement signals,
  typically 0, 1 or real numbers
• - the transition model of the world, T
• environment is nondeterministic
• T S x A ? P(S) T transition model
• T(s, a, s)
• Environment history a sequence of states that
  leads to a terminal state

9
10

•  A 4 x 3 environment
• The intended outcome occurs with probability 0.8,
  and with probability 0.2 (0.1, 0.1) the agent
  moves at right angles to the intended direction.
• The two terminal states have reward 1 and 1,
  all other states have a reward of 0.04

0.8
0.1
0.1
3 2 1
Up, Up, Right, Right, Right (4,3) 0.85 0.32768
1 2 3 4
10
11

• 2.2 Features varying RL
• accessible / inaccessible environment
• has (T known) / has not a model of the
  environment
• learn behavior / learn behavior model
• reward received only in terminal states or in any
  state
• passive/active learner
• learn utilities of states
• active learner learn also what to do
• how does the agent represent B, namely its
  behavior
• utility functions on states or state histories (T
  is known)
• active-value functions (T is not necessarily
  known) - assigns an expected utility to taking a
  given action in a given state

11
12
Agents

• State and goals
• goal  E ? 0, 1
• Utilities
• utility  E ? R
• env  E x A ? P(E)
• Expected utility of an action a in a state e
• Maximum Expected Utility (MEU)

12
13

• 2.3 The RL problem
• the agent has to find a policy ? a function
  which maps states to actions and which maximizes
  some long-time measure of reinforcement.
• The agent has to learn an optimal behavior
  optimal policy a policy which yields the
  highest expected utility - ?
• The utility function depends on the environment
  history (a sequence of states)
• In each state s the agents receives a reward -
  R(s)
• Uh(s0, s1, , sn) utility function on
  histories

13
14

• Models of behavior
• Finite-horizon model at a given moment of time
  the agent should optimize its expected reward for
  the next h steps
• E(?t0, h R(st))
•  rt represents the reward received t steps into
  the future.
•
• Infinite-horizon model optimize the long-run
  reward
•   E(?t0,? R(st))
•
• Infinite-horizon discounted model optimize the
  long-run reward but rewards received in the
  future are geometrically discounted according to
  a discount factor ?.
•   E(?t0,? ?t R(st))
• 0 ? ? lt 1.
• ? can be interpreted in several ways. It can be
  seen as an interest rate, a probability of living
  another step, or as a mathematical trick to bound
  an infinite sum.

14
15

• 2.4 Markov systems
• Discounted rewards
• An AP gets payed 20/year
• 202020..
• (reward now) ?(reward at time 1) ?2(rewards
  at time) 2
• A Markov System with rewards
• (S1, S2,Sn)
• A transition probability matrix
  PijProb(NextSjThis Si)
• Each state has a rweard r1, r2,rn
• Discount factor ? in 0,1
• On each time step
• Assume state is Si
• Get reward ri
• Randomly move to another state Pij
• All future rewards are discounted by ?

15
16

• U(Si)expected discounted sum of future rewards
  starting in state Si
• U(Si) ri?(Pi1U(S1)Pi2U(S2) .. PinU(Sn)),
  i1,n
• Solve equations, get an exact answer but 100 000
  states splve a 100 000 by 100 000 system of
  equations
• Value iteration to solve a Markov system
• U1(Si)ri
• U2(Si) ri ? ?j1,N PijU1(Sj)
• Compute U1(Si) for each sate
• Compute U2(Si) for eaxch state, etc
• Stop when Uk1(Si) - Uk(Si) lt eps

16
17

• 2.5 Markov Decision Problem (MDP)
• consists of
• ltS, A, P, Rgt
• S - a set of states
• A - a set of actions
• R reward function, R S x A ? R
• T S x A ? ?(S), with ?(S) the probability
  distribution over the states S
• On each time step
• Assume state is Si
• Get reward Ri
• Choose action a (from a1ak)
• Move to another state Pij with probability
  T(Si,a)
• All future rewards are discounted by ?
• We shall use T(s,a,s)

PassProb(NextsThiss and I use action k)
17
18

• Markov Decision Problem (MDP)
• The model is Markov if the state transitions are
  independent of any previous environment states or
  agent actions.
• MDP finite-state and finite-action focus on
  that / infinite state and action space
• For every MDP there exists an optimal policy
• Its a policy such that for every possible start
  state there is no better option than to follow
  the policy
• Finding the optimal policy given a model T
  calculate the utility of each state U(state) and
  use state utilities to select an optimal action
  in each state.

18
19

• Value iteration to solve a MDP
• U1(s)R(s)
• U2(s) maxa(R(s) ? ?s T(s,a,s)U1(s))
• .
• UK1(s) maxa(R(s) ? ?s T(s,a,s)Uk(s))
• Compute U1(si) for each state, ssi
• Compute U2(si) for each state, etc
• Stop when maxi Uk1(si) - Uk(si) lt eps
• convergence
• (dynamic programming)

Value iteration for a MS Uk1(Si) ri ? ?j1,N
PijU k(Sj)
19
20

• The utility of a state is the immediate reward
  for that state plus the expected discounted
  utility of the next state, assuming that the
  agent chooses the optimal action
• U(s) R(s) ? max a?sT(s,a,s)U(s)
• Bellman equation - U?(s) unique solutions
• The utility function U(s) allows the agent to
  select actions by using the Maximum Expected
  Utility principle
• ?(s) argmaxa (R(s) ? ?sT(s,a,s)U(s))
•  optimal policy

20
21

•  A 4 x 3 environment
• The intended outcome occurs with probability 0.8,
  and with probability 0.2 (0.1, 0.1) the agent
  moves at right angles to the intended direction.
• The two terminal states have reward 1 and 1,
  all other states have a reward of 0.04, ?1

0.8
0.1
0.1
3 2 1
3 2 1
0.812
0.868
0.918
0.762
0.660
0.705
0.655
0.611
0.388
1 2 3 4
1 2 3 4
21
22
Bellman equation for the 4x3 world Equation for
the state (1,1) U(1,1) -0.04 ? max 0.8
U(1,2) 0.1 U(2,1) 0.1 U(1,1), Up
0.9U(1,1) 0.1U(1,2), Left
0.9U(1,1) 0.1U(2,1), Down
0.8U(2,1) 0.1U(1,2) 0.1U(1,1) Right U
p is the best action
3 2 1
0.812
0.868
0.918
0.762
0.660
0.705
0.655
0.611
0.388
1 2 3 4
23
defines the best action in state s

• Value Iteration
• Given the maximal expected utility, the optimal
  policy is
•
• ?(s) arg maxa(R(s) ? ?s T(s,a,s) U(s))
•
• Compute U(s) using an iterative approach ? Value
  Iteration
•
• U0(s) R(s)
• Ut1(s) R(s) maxa(? ?s T(s,a,s) Ut(s))
•
• t ? inf .utility values converge to the
  optimal values
•

compute for all s
23
24

• Policy iteration
• Manipulate the policy directly, rather than
  finding it indirectly via the optimal value
  function
• choose an arbitrary policy ? (randomly)
• at each time t, compute the the long time reward
  starting in s, using ?t, i.e. solve the equations
• Ut(s) R(s) ? ?s (T(s, ?t(s),s) Ut(s))
• improve the policy at each state
• ?t1(s) ? arg maxa (R(s) ? ?s T(s,a,s)
  Ut(s))
• Involves all next states - complex

24
25

• 2.6 RL learning
• Use observed rewards to learn an optimal (or near
  optimal) policy for the environment
• Ex play 100 moves, you loose
• In an MDP the agent has a complete model f the
  evironment
• Now the agent has not such a model
• Passive learning the agent policy is fixedThe
  tesk is to learn the utilities of states (or
  state-action pairs)
• Active learning the agent must aso learn what
  to do exploitation/exploration

25
26

• (a) Passive reinforcement learning
• Policy is fixed in state s always execute ?(s)
• Goal learn how good the policy is learn U?(s)
• Does not know T(s,a,s), does not know before
  R(s)
• ADP (Adaptive Dynamic Programming) learning
• The problem of calculating an optimal policy in
  an accessible, stochastic environment.
• ADP plug the learned T(s, ?(s),s) and the
  observed rewards R(s) into the Bellman equations
  to calculate the utility of states
• Supervised learning input state-action pairs
• output resulting state
• Estimate transition probabilities T(s,a,s) from
  frequencies with which s is reached after
  executing a in s
• (1,3) Right 2 times (2,3), 1 time in (1,3)
  gt
• T((1,3),Right,(2,3))2/3

26
27

• ADP (Adaptive Dynamic Programming) learning
• function Passive-ADP-Agent(percept) returns an
  action
• inputs percept, a percept indicating the current
  state s and reward signal r
• variable ?, a fixed policy
• mdp, an MDP with model T, rewards R, discount ?
• U, a table of utilities, initially empty
• Nsa, a table of frequencies for state-action
  pairs, initially zero
• Nsas, a table of frequencies of
  state-action-state triples, initially zero
• s, a, the previous state and action, initially
  null
• if s is new then Us ? r, Rs ? r
• if s is not null then
• increment Nsas,a and Nsass,a,s
• for each t such that Nsass,a,t ltgt0 do
• Ts,a,t ? Nsass,a,t / Nsas,a
• U ? Value-Determination(?,U,mdp)
• if Terminals then s,a ? null else s,a ? s,
  ?s
• return a
• end

according to MDP (value iteration or policy
iteration)
27
28

• Temporal difference learning
• (TD learning)
•  The value function is no longer implemented by
  solving a set of linear equations, but it is
  computed iteratively.
•
• Used observed transitions to adjust the values of
  the observed states so that they agree with the
  constraint equations.
•
• U?(s) ? U ?(s) ?(R(s) ? U ?(s) U ?(s))
•   ? is the learning rate.
• Whatever state is visited, its estimated value is
  updated to be closer to R(s) ? U ?(s)
• since R(s) is the instantaneous reward received
  and
• U ?(s') is the estimated value of the actually
  occurring next state.
• simpler, involves only next states
• ? decreases as the number of times the state is
  visited increases

28
29

• Temporal difference learning
• function Passive-TD-Agent(percept) returns an
  action
• inputs percept, a percept indicating the current
  state s and reward signal r
• variable ?, a fixed policy
• U, a table of utilities, initially empty
• Ns, a table of frequencies for states,
  initially zero
• s, a, r, the previous state, action, and
  reward, initially null
• if s is new then Us ? r
• if s is not null then
• increment Nss
• Us ? Us ?(Nss)(r ? U s U s)
• if Terminals then s, a, r ? null else s, a, r
  ? s, ?s, r
• return a
• end

29
30

• Temporal difference learning
• Does not need a model to perform its updates
• The environment supplies the connections between
  neighboring states in the form of observed
  transitions.
• ADP and TD comparison
• ADP and TD try both to make local adjustments to
  the utility estimates in order to make each state
   agree  with its successors
• TD adjusts a state to agree with the observed
  successor
• ADP adjusts a state to agree with all of the
  successors that might occur, weighted by their
  probabilities

30
31

• (b) Active reinforcement learning
• Passive learning agent has a fixed policy that
  determines its behavior
• An active learning agent must decide what action
  to take
• The agent must learn a complete model with
  outcome probabilities for all actions (instead of
  a model for the fixed policy)
• Compute/learn the utilities that obey the Bellman
  equation
• U (s) R(s) ? maxa?s (T(s, ?t(s),s)
  U(s))
• using value iteration r policy iteration
• - If value iteration then look for the action
  that maximze utility
• - If policy iteration you already have the action
• - Exploration/exploitation
• - The representative problem is the n-armed
  bandit problem
• Solutions
• 1/t time choose random actions, rest follow ?
• give weights to actions that have not been
  explored, avoid actions with low utilities
• Exploratory function f(u,n) how greedy
  (prefer high utility vales r not (exploration)
  the agent is

31
32

• Q-learning
• Active learning of action-value functions
• action-value function assigns an expected
  utility to taking a given action in a given
  state, Q-values
• Q(a, s) the value of doing action a in state s
  (expected utility)
• Q-values are related to utility values by the
  equation
• U(s) maxaQ(a, s)
• Approach 1
• Q(a,s) R(s) ? ?s (T(s, a,s) maxa
  Q(a,s))
• This requires a model
• Approach 2
• Use TD
•  The agent does not need to learn a model model
  free

32
33

• Q-learning
•
• TD learning, unknown environment
•
• Q(a,s) ? Q(a,s) ?(R(s) ? maxaQ(a, s)
  Q(a,s))
•
• calculated after each transition from state s to
  s.
•
•
• Is it better to learn a model and a utility
  function or to learn an action-value function
  with no model?

33
34

• Q-learning
• function Q-Learning-Agent(percept) returns an
  action
• inputs percept, a percept indicating the current
  state s and reward signal r
• variable Q, a table of action values index by
  state and action
• Nsa, a table of frequencies for state-action
  pairs
• s, a, r the previous state, action, and reward,
  initially null
• if s is not null then
• increment Nsas,a
• Qa,s ? Qa,s ?(Nsas,a)(r ? maxaQ
  a,s Q a,s)
• if Terminals then s, a, r ? null
• else s, a, r ? s, argmaxa f(Qa, s,
  Nsaa,s), r
• return a
• end

s, a, r ? s, argmaxa (Qa, s), r
34
35

• Generalization of RL
•  The problem of learning in large spaces large
  no. of states
• Generalization techniques - allow compact storage
  of learned information and transfer of knowledge
  between "similar" states and actions.
• Neural nets
• Decision trees
• U(state)U(most similar sate in memory)
• U(state) average U(most similar sates in memory)
•

35
36
3 Learning in MAS

• The credit-assignment problem (CAP) the problem
  of assigning feed-back (credit or blame) for an
  overall performance of the MAS (increase,
  decrease) to each agent that contributed to that
  change
• inter-agent CAP assigns credit or blame to the
  external actions of agents
• intra-agent CAP assigns credit or blame for a
  particular external action of an agent to its
  internal inferences and decisions
• distinction not always obvious
• one or another

36
37
3.1 Learning action coordination

• s current environment state
• Agent i determines the set of actions it can do
  in s Ai(s) Aij(s)
• Computes the goal relevance of each action
  Eij(s)
• Agent i announces a bid for each action with
• Eij(s) gt threshold
• Bij(s) (? ?) Eij(s)
• ? - risk factor (small) ? - noise term (to
  prevent convergence to local minima)

37
38

• The action with the highest bid is selected
• Incompatible actions are eliminated
• Repeat process until all actions in bids are
  either selected or eliminated
• A selected actions activity context
• Execute selected actions
• Update goal relevance for actions in A
• Eij(s) ? Eij(s) Bij(s) (R / A)
• R external reward received
• Update goal relevance for actions in the previous
  activity context Ap (actions Akl)
• Ekl(sp) ? Ekl(sp) (?Aij?A Bij(s)/ Ap)

38
39
3.2 Learning individual performance

• The agent learns how to improve its individual
  performance in a multi-agent settings
• Examples
• Cooperative agents - learning organizational
  roles
• Competitive agents - learning from market
  conditions

39
40
3.2.1 Learning organizational roles (Nagendra,
e.a.)

• Agents learn to adopt a specific role in a
  particular situation (state) in a cooperative
  MAS.
• Aim to increase utility of final states
• Each agent may play several roles in a situation
• The agents learn to select the most appropriate
  role
• Use reinforcement learning
• Utility, Probability, and Cost (UPC) estimates of
  a role in a situation
• Utility - the agent's estimate of a final state
  worth for a specific role in a situation world
  states mapped to smaller set of situations
• S s0,,sf
• Urs U(sf), s0 ? ? sf

40
41

• Probability - the likelihood of reaching a final
  state for a specific role in a situation
• Prs p(sf), s0 ? ? sf
• Cost - the computational cost of reaching a final
  state for a specific role in a situation
• Potential of a role - estimates the usefulness of
  a role, discovering pertinent global information
  and constraints (ortogonal to utilities)
• Representation
• Sk - vector of situations for agent k, SK1,,SKn
• Rk - vector of roles for agent k, Rk1,,Rkm
• Sk x Rk x 4 values to describe UPC and
  Potential

41
42

• Functioning
• Phase I Learning
• Several learning cycles in each cycle
• each agent goes from s0 to sf and selects its
  role as the one with the highest probability
• Probability of selecting a role r in a situation
  s
• f - objective function used to rate the roles
• (e.g., f(U,P,C,Pot) UPC Pot)
• - depends on the domain

42
43

• Use reinforcement learning to update UPC and the
  potential of a role
• For every s ? s0,,sf and chosen role r in s
• ? Ursi1 (1-?)Ursi ?Usf
• i - the learning cycle
• Usf - the utility of a final state
• 0???1 - the learning rate
• ? Prsi1 (1-?)Prsi ?O(sf)
• O(sf) 1 if sf is successful, 0 otherwise

43
44

• ? Potrsi1 (1-?)Potrsi ?Conf(Path)
• Path s0,,sf
• Conf(Path) 0 if there are conflicts on the
  Path, 1 otherwise
• The update rules for cost are domain dependent
• Phase II Performing
• In a situation s the role r is chosen such that

44
45
3.2.2 Learning in market environments(Vidal
Durfee)

• Agents use past experience and evolved models of
  other agents to better sell and buy goods
• Environment a market in which agents buy and
  sell information (electronic marketplace)
• Open environment
• The agents are self-interested (max local
  utility)
• g - a set of goods
• P - set of possible prices for goods
• Qg - set of possible qualities for a good g

45
46

• information has a cost for the seller and a value
  for the buyer
• information is sold at a certain price
• a buyer announces a good it needs
• sellers bid their prices for delivering the good
• the buyer selects from these bids and pays the
  corresponding price
• the buyer assesses the quality of information
  after it receives it from the seller
• Profit of a seller s for selling the good g at
  price p
• Profitsg(p) p - csg
• csg - the cost of producing the good g
  by s p - the price
• Value of a good g for a buyer b
• Vbg(p,q) p - price b paid for g
• q - quality of good g
• Goal seller - maximize profit in a transaction
• buyer - maximize value in a
  transaction

46
47

• 3 types of agents
• 0-level agents
• they set their buying and selling prices based on
  their own past experience
• they do not model the behavior of other agents
• 1-level agents
• model other agents based on previous interactions
• they set their buying and selling prices based on
  these models and on past experience
• they model the other agents as 0-level agents
• 2-level agents
• same as 1-level agents but they model the other
  agents as 1-level agents

47
48

• Strategy of 0-level agents
• 0-level buyer
• - learns the expected value function, fg(p), of
  buying g at price p
• - uses reinforcement learning
• fgi1(p) (1-?)fgi(p) ?Vbg(p,q), ?min? ? ?
  1, for i0, ? 1
• - chooses the seller s for supplying a good g
• 0-level seller
• - learns the expected profit function, hg(p),if
  it offers good g at price p
• - uses reinforcement learning
• hgi1(p) (1-?)hgi(p) ?Profitbg(p)
• where Profitbg(p) p - csg if it
  wins the auction, 0 otherwise
• - chooses the price ps to sell the good g so as
  to maximize profit

48
49

• Strategy of 1-level agents
• 1-level buyer
• - models sellers for good g
• - does not model other buyers
• - uses a probability distribution function qsg(x)
  over the qualities x of a good g
• - computes expected utility, Esg, of buying good
  g from seller s
• - chooses the seller s for supplying a good g
  that maximizes this expected utility

49
50

• 1-level seller
• - models buyers for good g
• - models the other sellers s for good g
• Buyer's modeling
• - uses a probability distribution function mbg(p)
  - the probability that b will choose price p for
  good g
• Seller's modeling
• - uses a probability distribution function
  ns'g(y) - the probability that s' will bid price
  y for good g
• - computes the probability of bidding lower than
  a given seller s' with the price p
• Prob_of_bidding_lower_than_s'
• ?p'(Prob of bid of s' with p' for which s wins)

• ?p' N(g,b,ss',p,p')
• N(g,b,ss',p,p') ns'g(p') if mbg(p') ?
  mbg(p)
• 0 otherwise

50
51

• - computes the probability of bidding lower than
  all other sellers with the price p
• Prob_of_bidding_lower_with_p
• ? (Prob_of_bidding_lower_than_s')
• s'?S - s
• - chooses the best price p to bid so as to
  maximize profit

51
52
3.3 Learning to communicate

• What to communicate (e.g., what information is of
  interest to the others)
• When to communicate (e.g., when try doing
  something by itself or when look for help)
• With which agents to communicate
• How to communicate (e.g., language, protocol,
  ontology)

52
53
Learning with which agents to communicate (Ohko,
e.a. )

• Learning to which agents to ask for performing a
  task
• Used in a contract net protocol for task
  allocation to reduce communication for task
  announcement
• Goal acquire and refine knowledge about other
  agents' task solving abilities
• Case-based reasoning used for knowledge
  acquisition and refinement
• A case consists of
• (1) A task specification
• (2) Information about which agents solved a task
  or similar tasks in the past and the quality of
  the provided solution

53
54

• (1) Task specification
• Ti Ai1 Vi1, , Aimi Vimi
• Aij - task attribute, Vij - value of attribute
• Similar tasks
• Sim(Ti, Tj) ?r ?s Dist(Air, Ajs)
• Air?Ti, Ajs?Tj
• Dist(Air, Ajs) Sim_Attr(Air, Ajs)
  Sim_Vals(Vir, Vjs)
• Set of similar tasks
• S(T) Tj Sim(T, Tj) ?0.85

54
55

• (2) Which agents performed T or similar tasks in
  the past
• Suitability of Agent k
• Perform(Ak, Tj) - quality of solution for Tj
  assured by agent Ak performing Tj in the past
• The agent computes
• Suit(Ak, T), Suit(Ak, T)gt0 and selects the
  agent k such that
• or the first m agents with best suitability
• After each encounter, the agent stores the tasks
  performed by other agents and the solution
  quality
• Tradeoff between exploitation and exploration

55
56
3.4 Layered learning

• (Stone Veloso)
• A hierarchical machine learning paradigm in MAS
• Used simulated robotic soccer RoboCup
• Learning
• Input ? Output Intractable
• Decompose the learning task L into subtasks L1,
  , Ln
• Characteristics of the environment
• Cooperative MAS
• Teammates and adversaries
• Hidden states agents have a partial world view
  at any given moment
• Agents have noisy sensory data and actuators
• Perception and action cycles are asynchronous
• Agents must make their decisions in real-time

56
57

• Problem the agent receives a moving ball and
  must decide what to do with it dribble, pass to
  a teammate, shoot towards the goal
• Decompose the problem into 3 subtasks
• Layer Behavior type Example
• L1 Individual Ball interception
• L2 Multiagent Pass evaluation
• L3 Team Pass selection
• The decomposition into subtasks enables the
  learning of more complex behaviors
• The hierarchical task decomposition is
  constructed bottom-up, in a domain dependent
  fashion
• Learning methods are chosen to suit the task
• Learning in one layer feeds into the next layer
  either by providing a portion of the behavior
  used for training (ball interception pass
  evaluation) or by creating the input
  representation and pruning the action space (pass
  evaluation pass selection)

57
58

• L1 Ball interception
• behavior individual
• Aim
• Blocks or intercepts opponents shots or passes or
• Receive passes from teammates
• Learning method a fully connected
  backpropagation NN
• Repeatedly shooting the ball towards a defender
  in front of a goal.The defender collects t.e. by
  acting randomly and noticing when it successfully
  stops the ball
• Classification
• Saves successful interceptions
• Goals unsuccessful attempts
• Misses shoots that went wide of the goal

58
59

• L2 Pass evaluation
• behavior multiagent
• Uses its learned ball-interception skills as part
  of the behavior for training MAS behavior
• Aim the agent must decide
• To pass (or not) the ball to a teammate and
• If the teammate will successfully receive the
  ball (based on positions abilities of the
  teammate to receive or intercept a pass)
• Learning method decision trees (C4.5)
• Kick the ball towards randomly placed teammates
  interspread with randomly placed opponents
• The intended pass recipient and the opponents all
  use the learned ball-interception behavior
• Classification of a potential pass to a receiver
• Success, with a c.f. ? (0,1
• Failure, with a c.f. ? -1,0)
• Miss, ( 0)

59
60

• L3 Pass selection
• behavior team
• Uses its learned pass-evaluation capabilities to
  create the input and output set for learning pass
  selection
• Aim the agent has the ball and must decide
• To which teammate to pass the ball or
• Shoot on goal
• Learning method Q-learning of a function that
  depends on the agents position on the field
• Simulate 2 teams playing with identical behavior
  others than their pass-selection policies
• Reinforcement total goals scored
• Learns
• Shoot the goal
• The teammate to which to pass

60
61
4 Conclusions

• There is no unique method or set of methods for
  learning in MAS
• Many approaches are based on extending ML
  techniques in a MAS setting
• Many approaches use reinforcement learning, but
  also NN or genetic algorithms

61
62

• References
• S. Sen, G. Weiss. Learning in Multiagent systems.
  In Multiagent Systems - A Modern Approach to
  Distributed Artificial Intelligence, G. Weiss
  (Ed.), The MIT Press, 2001, p.257-298.
• T. Ohko, e.a. - Addressee learning and message
  interception for communication load reduction in
  multiple robot environment. In Distributed
  Artificial Intelligence Meets Machine Learning,
  G. Weiss, Ed., Lecture Notes in Artificial
  Intelligence, Vol. 1221, Springer-Verlag, 1997,
  p.242-258.
• M.V. Nagendra, e.a. Learning organizational roles
  in a heterogeneous multi-agent systems. In Proc.
  of the Second International Conference on
  Multiagent Systems, AAAI Press, 1996, p.291-298.
• J.M. Vidal, E.H. Durfee. The impact of nested
  agent models in an information economy. In Proc.
  of the Second International Conference on
  Multiagent Systems, AAAI Press, 1996, p.377-384.
• P. Stone, M. Veloso. Layered Learning, Eleventh
  European Conference on Machine Learning,
  ECML-2000.

62
63

• Web References
• An interesting set of training examples and the
  connection between decision trees and rules.
• http//www.dcs.napier.ac.uk/peter/vldb/dm/node11.
  html
• Decision trees construction
• http//www.cs.uregina.ca/hamilton/courses/831/not
  es/ml/dtrees/4_dtrees2.html
• Building Classification Models ID3 and C4.5
• http//yoda.cis.temple.edu8080/UGAIWWW/lectures/C
  45/
• n       Introduction to Reinforcement Learning
• http//www.cs.indiana.edu/gasser/Salsa/rl.html
•  n       On-line book on Reinforcement Learning
• http//www-anw.cs.umass.edu/rich/book/the-book.ht
  ml

63
