NorCal OAUG: eCommerce

1
NorCal OAUG eCommerce the Oracle Applications

• Jeffrey Hutchins
• Senior Principal Product Manager eCommerce
  Strategy
• SOA Suite Product Management

2
AgendaeCommerce

• Oracle's Vision
• What does a gateway provide?
• What is Oracle B2B?
• What is missing from the equation?
• How does Oracle addresses eCommerce ?
• Putting it all into context

3
eCommerceWhat is Oracles Vision ?

• The success of any value chain is that It is
  driven by the business requirements not the
  technology
• The focus must be Business Process Management
• It is an integral component of an enterprises
  integration strategy
• It is the entire business process, not the
  gateway
• The gateway software is becoming a commodity

4
eCommerceWhat does a gateway provide?

• A transaction set is a single document over the
  internet
• There are 6 components. The concepts are no more
  difficult then sending a packaged via DHL, FedEx,
  UPS, US Postal Service

Layer Question to Ask Shipping Analogy E-Commerce Protocol
Document What is the item ? Cell Phone EDI, HL7, HIPAA, UCCnet, OAG, UBL, cXML, xCBL, RosettaNet
Packaging How is the item packaged ? Box, bubble wrap MIME, SMIME, XMLDSig, XMLEncrypt
Transport How is the item sent / received ? Truck, Ship, Plane HTTPs, File, FTPs, TCP/IP, SMTP, MLLP
Messaging System Who is the carrier ? DHL, FedEx, UPS, USPS RNIF, AS1, AS2, AS3, ebMS
What carrier services are required ? Requirements Signed receipt Overnight / next day Delivery attempts Requirements Non-Repudiation Time to Acknowledge / Respond Retry Counts
Profile What are the Trading Partners capabilities ? What are the senders / receivers capabilities ? Trading Partner Profile
Agreement What did we agree ? What did we agree ? Trading Partner Agreement
5
Oracle B2BThe Gateway

• Comprehensive Document Mgmt and Trading Partner
  Mgmt
• Extensive B2B protocol support

• Secure reliable message exchange
• Enabling complete end-to-end processes with all
  assets

6
Oracle B2BDocument Management Powered by
EDIFECSTM

• EDIFECSTM
• Provides a robust translation validation engine
  as an integral part of Oracle B2B.
• The development platform for GS1 EDI

• This solution provides
• A library of ALL EDIFACT, X12, X12N, HL7, HIPAA,
  EANCOM, NCPDP Script transaction sets
• Data file validation
• Data Migration
• Tests data generation
• De-Identification
• Dictionary generation
• Batching

7
Oracle B2BTransports / Messaging Systems

• Transports
• File Transport Protocol (FTP / FTPs / sFTP)
• Hypertext Transfer Protocol (HTTP / HTTPs)
• Simple Mail Transfer Protocol (SMTP)
• Minimum Lower Layer Protocol (MLLP)
• Messaging Systems (Automatic generation /
  consumption of acknowledgment)
• Applicability Statement 1 (AS1)
• Applicability Statement 2 (AS2)
• ebXML Messaging System (ebMS)
• RosettaNet Implementation Framework (RNIF)

8
Oracle B2B Trading Partner Management

• Trading Partner Profiles
• Defining Trading Partner capabilities
  Identification, supported standards, transports,
  exchanges, ..
• Trading Partner Agreements
• Customizable configurations for each agreements
• Standards based protocols
• Encryption, Compression, Non-Repudiation, Digital
  Certificates, Secure Transports, ..
• Service Level settings
• Time to Perform, Time to Acknowledge, Retry
  Counts, ..

9
Oracle B2BManagement and Reporting

• Business Activity Monitoring
• Monitor state of messages
• Monitor BPEL and B2B processes
• throughput and execution times.
• Details through hierarchy time based sliding
  views.
• B2B Runtime Reports
• Wire Messages
• Business Messages
• Collaborations
• Errors
• Application Server Control
• Modify properties
• View log files
• Manage components

10
eCommerceWhat is missing from the equation?

• The barriers between A2A, C2A, and B2B
  integration are disappearing. We have endpoints
  and require business process integration. You
  must
• Orchestrate processes
• Mitigate errors
• Define a canonical
• Translate / transform data
• Address Security / Compliance / Visibility /
  Management

11
How Oracle addresses eCommerce Oracle BPM
Business Solutions
Process Templates
Industry specific
A/R, A/P, TE, HR, 2-layer BPM, imaging solutions

Process Portal (Web center)
Optimization
BPA Suite
Process Analytics Alerts
Collaboration (forums, wiki..)
Process Dashboards
Office
E-Forms
Model, Simulate Publish

SOA Suite
JDeveloper
BPEL
Human WF
Rules
BAM
OWSM
B2B
Implement Processes services
Enterprise Service Buss (ESB)
Legacy systems
Messaging ECM systems Packaged apps
Content/Image Servers
Packaged apps, external services
User, Role directory
12
How does this apply to you? A platform that
enables your business requirements

• Integrated Composition Platform
• Process Driven Design Methodology- Top Down
• Re-Usable Enterprise Business Services
• Service Repository to Provision, Deploy Manage
• Integrated Analytics to track and re-act
• Business User Toolkit to configure, extend
  optimize
• A Governance model to support change control

13
Putting it all into context Use Case Outbound
Purchase Order
14
Business Process integrationUse Case Outbound
Purchase Order

• E-Business Suite (eBiz)
• Purchase Order process initiated
• Enterprise Service Bus (ESB)
• Gets PO from E-Business Suite
• Adapter validates Translates to XML
• Transforms to target (XSLT)
• Converts codes
• Routes message to BPEL PM
• BPEL Process Manager (BPEL)
• Receives PO
• Executes Business Processes
• Human Workflow
• Business Rules
• Error Handing
• Sends PO to ESB
• Enterprise Service Bus (ESB)

Trading Partner
E-Biz Adapter
B2B Protocol
15
ApplicationIntegration Repository - Local and
Hosted

• Catalog of all E-Business Suite Integration
  Points
• Source of truth for all integration projects for
• Customers
• Consultants Integrators
• Assurance that you are using public supported and
  certified interfaces
• Powerful UI for searching and viewing available
  Interfaces
• Better planning
• Lower integration costs
• http//Irep.oracle.com

16
Connectivity eBusiness Suite Adapter - Service
enables Oracle Applications

• Version Awareness
• Interfaces with Integration Repository
• Integrates via Open Interfaces and Stored
  Procedures for inserting data into Oracle
  Applications.
• Bi-directional XML integration with XML and EDI
  Gateway for exchanging OAG based XML/EDI
  documents.

EDI Gateway
Oracle E-Business Suite Adapter
XML Gateway
Workflow BES
Interface Tables, Concurrent Mgr
Stored Procedures
17
Connectivity Web Service Provider

• Web Service Provider is an engine which enables
  Service Beans XML Gateway to be exposed as Web
  Services.
• Admin utility to create and deploy Web Service
• Run time Web Service engine
• Integrated into Repository for Service discovery
• Enables any eBusiness Suite Web Service to
  participate in a BPEL process
• WS-I compliant,
• XML Schema 1.0
• SOAP 1.1(inbound and outbound attachments)
• WSDL 1.1
• WS-Security
• XML Gateway Web Services
• Available as a WS-I compliant Web Service from
  11i.10

18
ConnectivityDeployment

• Step 1 Discover
• Pull up the Java Service Interface in Integration
  Repository
• Step 2 Deploy
• Use the Web Service Tab to generate bindings and
  deploy the Web Service
• Step 3 Secure
• Grant access on a method to a User or a Group
• Step 4 Advertise
• Deploy the WSDL to any UDDI compliant platform

19
Service Oriented Architecture Components

• Orchestrate processes, Mitigate errors, Define a
  canonical, Translate / transform data, Address
  Security / Compliance / Visibility / Management
• Business Activity Monitoring
• Monitor Optimize
• Business Process Manager
• Orchestrate Processes. Human Workflow, Business
  Rules
• Web Services Manager
• Manage Govern Services
• Oracle B2B
• Manage Trading Partner
• Enterprise Service Bus
• Connectivity, Transformation, translation Route

20
A Service Oriented ArchitectureOrchestrate
processes, Mitigate errors, Define a canonical,
Translate / transform data, Address Security /
Compliance / Visibility / Management
Trading Partner
B2B Protocols
Web Services
eBiz Suite Adapter Web Service Provider
Siebel Adapter
PSFT Adapter
SAP Adapter
Legacy
21
AS11gR1Oracle B2B

• A component of the SOA Suite
• eCommerce BPM opens vertical requirements
• Healthcare
• Retail
• Automotive
• Public Sector
• High Tech
• Chemical
• Petroleum

22
B2B UI Next Generation
23
Oracle B2BFeatures

• Core Platform Integration
• B2B runtime j2EE component
• MDS Integration B2B metadata
• RCU Integration
• MaD Integration
• JMX - MBean Support
• SOA Mesh Integration

• E-Business Suite Integration
• Support for XML Gateway attributes
• Support for e-Commerce Gateway attributes
• Complete functionality support for XML
  eCommerce Gateways
• Enhanced OAG standard support

• Richer User Interface
• B2B Document Editor all versions of EDI X12,
  EDIFACT, HL7, HIPAA, VICS, RN, VDA, Odette
• ADF/DHTML based UI framework
• Partner Self Service
• Protocol based metadata management
• Partner specific Reporting

• Trading Partner (TP) Mgmt
• Partner specific document definitions
• Partner specific message/ack processing
• Document auto retry
• Document re-submission
• Large Document Support

• New Protocol Support
• Healthcare standards support
• ebXML CPP/CPA Import/Export

• Security Integration
• OSDT Integration for S/MIME, XML Dsig, XML
  Encrypt, Zlib Compression
• Partner Certificates in common store
• SSO Support
• B2B users in App Server security store LDAP,
  VD,etc
• Role based authorization for Users

24
(No Transcript)
25
For more information

• Business Process Management
• http//www.oracle.com/technologies/bpm/index.html
• Fusion Middleware
• http//www.oracle.com/technology/products/middlew
  are/index.html
• Service-Oriented Architecture
• http//www.oracle.com/technologies/soa/index.html

• Oracle B2B
• http//www.oracle.com/technology/products/integra
  tion/b2b/index.html
