Title: Management Science


1
Management Science
QM 6433 -- Spring 2007
  • Decision Analysis Overview

Instructor John Seydel, Ph.D.
2
This Weeks Student Objectives
  • Upon completion of this weeks course
    activities, you should be able to
  • Formulate problems involving single decision
    variables with finite sets of alternatives as
    decision analysis problems
  • Model decision analysis problems using payoff
    matrices
  • Use Excel to support the modeling and solution of
    payoff matrices
  • Incorporate the following into spreadsheet models
    where applicable
  • The SUMPRODUCT() function
  • Mixed absolute cell referencing in formulae

3
Refer to Our Course Outline
  • Spreadsheet modeling techniques
  • Reinforce/strengthen this week
  • Basic decision modeling concepts
  • Reinforce/strengthen this week
  • Specific modeling/solution techniques
  • Decision analysis
  • Introduce this week
  • Linear programming
  • Simulation modeling analysis
  • Multicriteria decision making
  • Project management concepts tools

4
Introducing Decision AnalysisConsider
Essentially Any Decision
  • Two problem aspects involved
  • Courses of action
  • What choices we have
  • Examples which job, how many papers, . . .
  • States of nature
  • Events out of our control (hence, uncontrollable
    inputs)
  • Examples whos elected, weather, court
    decisions, economy
  • Example vending machine problem
  • Typically states of nature (e.g., daily demand)
    are described by probability distributions
  • We can use decision analysis approaches to assist
    us with many problems we encounter
  • Structuring problems with finite sets of
    alternatives
  • Evaluating and comparing complex alternatives

5
The Payoff Matrix Approach
  • For a single decision (hence one decision
    variable) develop a table
  • Create a row for each decision alternative (i.e.,
    choice)
  • Create a column for each state of nature
  • The vending machine problem
  • Decision alternatives are the possible number of
    papers to stock
  • The state of nature refers to the daily demand
    that occurs
  • Each cell in the table represents the criterion
    outcome (i.e., payoff) for the corresponding
    decision alternative and state of nature e.g.,
    the vending machine problem
  • It should be obvious here that the criterion of
    interest here is profit, and the objective is to
    maximize profit
  • For example, consider what happens if 11 papers
    are stocked, and demand that day is 10
  • The value to go into that table cell is a
    positive profit of 4.50
  • Revenue 10 _at_ 1.00 10.00
  • Cost 11 _at_ 0.50 5.50

6
Payoff Matrix for the Vending Machine Problem
7
Now, What to Do With the Payoff Matrix
  • At first glance, it might seem to be an obvious
    choice to stock the machine with 13 papers and to
    sell all 13
  • However, thats not an option
  • That is, the number sold is subject to demand, an
    uncontrollable input
  • Look again the table is telling us that, for
    example, if we stock 13 papers, the outcome could
    be a profit of 3.50, 4.50, 5.50, or 6.50,
    depending upon demand
  • Heres where the historical demand data enter in
    we treat the relative frequencies for each of the
    demand levels as their respective probabilities
  • We then use the probabilities to discount (i.e.,
    weight) the outcomes and calculate a weighted
    average outcome for each stock level
  • This is known as using mathematical expectation
    or EMV, which is just a weighted average outcome
  • Alternatives are compared by means of their EMVs
    . . .

8
Comparing Alternatives (via EMV)
  • This is really what decision analysis is all
    about
  • That is, we need to compare to two or more
    alternatives, where each alternative has multiple
    possible outcomes, each associated with a
    probability of occurrence
  • We do this by converting the multiple outcomes to
    a single value, its mathematical expectation
    (EMV), which we treat as a certainty equivalent
    for a given alternative
  • Once certainty equivalence values are calculated
    for each alternative, that with the best value is
    chosen
  • For example, the EMV for the decision to stock 12
    papers is
  • (4.00 x 0.05) (5.00 x 0.40) (6.00 x 0.30)
    (6.00 x 0.25) 5.50

9
Decision Analysis A Summary of the Procedures
  • Determine alternatives
  • For each alternative
  • Determine outcomes (e.g., monetary values)
    possible
  • Determine probabilities for those outcomes
  • Create model matrix or tree (stay tuned)
  • Determine EMV for each alternative
  • Make choice (alternative with best EMV)
  • Note the application of
  • The scientific problem-solving framework
  • The modeling process
  • Lends itself to Excel support . . .

10
Modeling with Excel
  • Lets make Excel do what its good at doing
    saving us from lots of work two opportunities
    here
  • Calculating payoffs
  • Determining EMV
  • Consider the logic for the payoffs in the vending
    machine problem calculate a few cells manually
    first
  • Payoff is dependent upon
  • Stock, S (the row indicator on the payoff
    matrix), the controllable input
  • Demand, D (the column indicator on the payoff
    matrix)
  • Sale revenue/unit, p, non-sale revenue/unit, q,
    and cost/unit, c
  • Note that S is the only controllable input
    (i.e., decision variable)
  • A relationship can be stated such that payoff
    (profit) is either
  • S x (p c ) ? if stock lt demand
  • D x p (S D ) x q S x c ? if stock gt demand
  • Implement this on a worksheet (see example) . . .

11
The Excel Worksheet Payoffs
  • This requires a fairly complex formula involving
  • Named cells
  • Cost per unit cost
  • Sale revenue/unit sale
  • Nonsale revenue/unit nonsale
  • An IF() function
  • Mixed absolute references (the challenging part)
  • Assume the top left payoff cell is B9
    (corresponding to stocking 10 units and a demand
    of 10 units)
  • The formula for B9 would then be
  • IF(A9ltB8,A9(sale-cost),B8sale(A9-B8)n
    onsale-A9cost)
  • This formula can then simply be copied down the
    column and then across the columns
  • It may be tempting just to calculate each payoff
    manually and enter the result, but you lose the
    functionality and flexibility that makes Excel
    such a valuable tool if any of the inputs
    change, you would need to go back through and
    recalculate everything.

12
The Excel Worksheet EMV
  • Calculating EMV is the easy part
  • We use the SUMPRODUCT() function
  • This multiplies corresponding elements of two
    arrays and adds the results
  • Recall that EMV involves multiplying the payoffs
    in a given row of a matrix by their corresponding
    probabilities
  • Assume the top right payoff cell is E9
    (corresponding to stocking 10 units and a demand
    of 13 units) and that probability values are in
    cells B14E14
  • The formula for G14 (EMV for a choice to stock 10
    papers) would then be
  • SUMPRODUCT(B9E9,B14E14)
  • This could then be copied down the column

13
Finally, the Solution
  • Refer again to the example worksheet
  • First, the solutions not 5.50
  • Thats just the criterion outcome if we implement
    the best course of action
  • The solution is thus the course of action we
    recommend
  • The real solution
  • We recommend that 12 papers be stocked daily in
    the vending machine at this location
  • If that is done, well see a long-term average
    profit of 5.50 per day from this location
  • Note how this is (and should be) stated in
    sentence form its a managerial problem
  • Recommendation is stated
  • Consequences should be stated
  • Qualifications are also of concern
  • This last item is not to be taken lightly . . .

14
Looking a Bit Further into Decision Analysis
  • Postoptimality (e.g., sensitivity) analysis?
  • Once a decision has been made, we analyze the
    quality of the decision
  • Final stage in the Scientific Problem-Solving
    Process
  • Allows us to test how robust our decision is
  • If the uncontrollable inputs change, how much
    does that affect the decision (i.e., the
    controllable input values) involved?
  • and/or
  • Whats Plan B (i.e., and alternative set of
    controllable input values) if the uncontrollable
    inputs change?
  • Note sensitivity analysis does not tell us the
    best values for the uncontrollable inputs
  • Consider risk (another criterion)
  • Think about how this might be done
  • Separately or in conjunction with profit
  • Well address these concerns next week, along
    with an interesting practical application
    involving pricing decisions

15
One Final Item Decision Trees as an Alternative
to Payoff Matrices
  • Decision tree approach
  • Accomplishes the same as payoff matrices
  • Can provide more intuitive maps of the decision
    process
  • Must be used in complex and/or multi-stage
    decision problems
  • Can get messy very quickly
  • Doesnt lend itself to native Excel capabilities
    we need add-ons (e.g., TreePlan)
  • We wont be doing much with decision trees but
    you should understand the basic concepts
  • Note that the symbols are not arbitrary
  • Squares (decision nodes) represent decision
    alternatives (choices)
  • Circles (event nodes) represent possible outcomes
  • Refer to the example spreadsheet (from Handouts
    page)
  • Starts with basic tree model
  • Progresses to complete model
  • Solution shows EMV calculated for each event node

16
Summary of Objectives
  • Formulate problems involving single decision
    variables with finite sets of alternatives as
    decision analysis problems
  • Model decision analysis problems using payoff
    matrices
  • Use Excel to support the modeling and solution of
    payoff matrices
  • Incorporate the following into spreadsheet models
    where applicable
  • The SUMPRODUCT() function
  • Mixed absolute cell referencing in formulae

17
Appendix
18
Spreadsheet Design Guidelines
  • Organize the data, then build the model around
    the data.
  • Do not embed numeric constants in formulas.
  • Things which are logically related should be
    physically related.
  • Use formulas that can be copied.
  • Column/rows totals should be close to the
    columns/rows being totalled.
  • The English-reading eye scans left to right, top
    to bottom
  • Use color, shading, borders and protection to
    distinguish changeable parameters from other
    model elements.
  • Use text boxes and cell notes to document various
    elements of the model.

19
Newspaper Vending Machine Case
  • Scenario
  • For a given location, you need to determine how
    many newspapers to stock weekdays in a
    coin-operated vending machine
  • Monetary information
  • Cost per paper 0.50
  • Revenue per paper
  • 1.00 if sold
  • Nothing otherwise disposal fees are negligible
  • Decision determine best value for S, how many
    papers to stock for any given weekday
  • Alternatives (i.e., choices)?
  • Criteria (objectives)?
  • Model
  • Payoff matrix
  • Note Not necessarily all papers will be sold
  • Whats missing . . . ?

20
Consider the Historical Demand Data
21
The Probability Distribution
22
Recall the Scientific Problem-Solving Framework
(SPSF)
  • Define the problem
  • Define decision variables
  • One number of papers to stock
  • Determine criteria of importance
  • One profit
  • Specify whether criteria are associated with
    goals or with objectives
  • Objective maximize profit
  • Identify constraints (no explicit constraints)
  • Consider alternatives
  • Identify them
  • Stock 10, 11, 12, or 13 papers (since demand
    varies from 10 to 13)
  • Evaluate them
  • Calculate EMV for each alternative
  • Select best one
  • Implement solution
  • Monitor and revise solution re-solve if
    appropriate

23
Recall Components of Decision Models
  • Model components
  • Inputs
  • Uncontrollable (e.g., costs) also known as data
  • Cost value
  • Sales price
  • Demand distribution
  • Possible demand amounts
  • Corresponding probabilities
  • Controllable also known as decision variables
  • Solution procedure
  • Use payoff matrix approach with EMV
  • Outputs i.e., the results
  • Array of payoffs associated with each decision
    alternative
  • EMV for each decision alternative
  • The solution (not just an answer) applying the
    results
  • The course of action to be taken
  • That is, the values chosen for the decision
    variables

24
An Excel Worksheet for the Example
Write a Comment
User Comments (0)
About PowerShow.com
