Equilibrium

1
Equilibrium
2
Equilibrium

• State of balance.
• Condition in which opposing forces exactly
  balance or equal each other.
• Need a 2-way or reversible situation.
• Need a closed system.

3
Dynamic Equilibrium

• Macroscopic level looks like nothing is
  happening.
• Microscopic level lots going on.

4
Equilibrium

• Rate of forward process rate of reverse
  process.
• Hallmark Looks like nothing is happening.
  Variables describing system are constant.

5
3 Kinds of Equilibria

• Phase equilibrium physical
• Solution equilibrium physical
• Chemical equilibrium - chemical

6
Phase Equilibrium

• Phase changes are reversible processes.
• H2O(l) ? H2O(g)
• H2O(l) ? H2O(s)
• Same substance on both sides. Phase is different.

7
Examples - Phase Equilibrium

• Water water vapor in a sealed water bottle.
• Perfume in a partially full, sealed flask.
• Ice cubes water in an insulated container.
• Dry ice CO2(g) in a closed aquarium.

8
Solution Equilibrium Solids

• Saturated solution dynamic equilibrium.
• Dissolving Solidification occur at equal rates.

9
Solid in Liquid

• NaCl(s) ? NaCl(aq)
• Favored a little bit by higher temperature.

10
Solution Equilibrium Gases
CO2 in water unopened. CO2(g) ? CO2(aq) Favored
by high pressure low temperature.
11
Reversible Reactions

• N2(g) 3H2(g) ? 2NH3(g)
• Forward N2 H2 consumed. NH3 produced.
• 2NH3(g) ? N2(g) 3H2(g)
• Reverse NH3 consumed. N2 H2 produced.

12
Reversible Reactions, 1 Equation

• N2(g) 3H2(g) ? 2NH3(g)
• Forward rxn, reactants are on left. Read left to
  right.
• Reverse rxn, reactants are on right. Read in
  reverse right to left.
• Rxns run in both directions all the time.

13
N2(g) 3H2(g) ? 2NH3(g)
Why is this point significant?
Concentration
H2
NH3
N2
Time
14
Reaction Rate

• Depends on concentration of reactants.
• As concentration of reactants decreases, rate
  decreases.
• As concentration of NH3 increases, rate of
  reverse rxn increases.

15
Chemical Equilibrium

• State in which forward reverse rxns balance
  each other.
• Rateforward rxn Ratereverse rxn
• Does it say anything about the concentrations of
  reactants products being equal?

NO!
16
Chemical Equilibrium

• Rateforward rxn Ratereverse rxn
• At equilibrium, the concentrations of all species
  are constant. They stop changing.
• They are hardly ever equal.

17
Reversible Reactions vs. Reactions that Go to
Completion

• If your goal is to maximize product yield
• Easier in a reaction that goes to completion.
• Use up all the reactants.
• Left with nothing but product.
• Reversible reactions are different.
• Look at ?Conc/?time picture again.

18
N2(g) 3H2(g) ? 2NH3(g)
Original Equilibrium Point
Concentration
H2
NH3
N2
Time
19
Reversible Reactions

• Once you reach equilibrium, you dont produce any
  more product.
• This is bad news if the product is what youre
  selling.
• How can you change the equilibrium
  concentrations? For example, how can you
  maximize product?

20
How can you get from here
21
New equilibrium point
Lots of product as fast as possible.
To here?
22
Affecting Equilibrium

• Equilibrium can be changed or affected by any
  factor that affects the forward and reverse
  reactions differently.

23
What factors affect rate of rxn?

• Concentration/Pressure
• Temperature
• Presence of a catalyst

24
Catalyst

• Has the same effect on the forward reverse
  reactions.
• Equilibrium is reached more quickly, but the
  equilibrium point is not shifted.
• The equilibrium concentrations are the same with
  or without a catalyst.

25
Concentration, Pressure, Temperature

• Changes in concentration, pressure, temperature
  affect forward reverse rxns differently.
• Composition of equilibrium mixture will shift to
  accommodate these changes.

26
LeChateliers Principle

• If a system at equilibrium is subjected to a
  stress, the system will act to reduce the
  stress.
• A stress is a change in concentration, pressure,
  or temperature.
• System tries to undo stress.

27
N2(g) 3H2(g) ? 2NH3(g)
Original Equilibrium
New Equilibrium
H2
NH3
N2
Stress Increased N2
28
System

• Only 2 possible actions
• Shift to the right form more product. The
  forward rxn speeds up more than the reverse rxn.
• Shift to the left form more reactant. The
  reverse reaction speeds up more than the forward
  rxn.

29
A B ? C D, at equil.

• If I increase the concentration of A, how will
  the system react?
• How does the new equilibrium mixture compare to
  the original equilibrium mixture?
• Use logic. If you increase A, the system wants
  to decrease A. It has to use A up, so it
  speeds up the forward reaction.

30
A B ? C D
31
Changes in Temp

• Exothermic rxn
• A B ? C D heat
• If you increase the temperature, the system
  shifts to consume heat. So here, it shifts to
  the left.
• Endothermic rxn
• A B heat ? C D
• If you increase the temperature, the system
  shifts to consume heat. So here, it shifts to
  the right.

32
Changes in Pressure

• N2(g) 3H2(g) ? 2NH3(g)
• If you increase pressure, the system shifts to
  the side with fewer moles of gas. Here, the
  right hand side has only 2 moles of gas while the
  LHS has 4. Increasing pressure will cause a
  shift to the right.
• If you decrease pressure, the system shifts to
  the side with more moles of gas.

33
H2(g) I2(g) ? 2HI(g)

• This system has 2 moles of gas on the LHS 2
  moles of gas on the RHS.
• Systems with equal moles of gas on each side
  cannot respond to pressure changes.
