Title: PISCO Atmospheric Dispersion Compensator


1
PISCO Atmospheric Dispersion Compensator
  • Will High
  • Harvard University
  • December 2006

2
An ADC for PISCO
  • ADC placeholder in blue below
  • After shutter (green below)
  • Before collimator
  • Mounted on PISCOs optical bench

3
An ADC for PISCO
r
i
D3
g
z
D1
D2
ADC placeholder
4
An ADC for PISCO
r
i
D3
g
z
D1
D2
ADC placeholder
5
Our ADC from the Ground Up
6
2 Prisms
  • 18 mm apart
  • 130 mm diam
  • 18 mm thick

7
Stainless Steel Housings
  • Gear teeth 360 groove for timing belt
  • Another 180 groove for zero-pointing with
    microswitches
  • Lip precision machined chamfer with
    semi-circular cross section

8
Stepper-Driven Non-slip Timing Belts
  • McMaster
  • Non-slip, double sided timing belts (teeth
    groove)
  • 2 specialty pulleys
  • Oriental Motor steppers
  • Custom axles and stepper mounting flanges

9
Stepper-Driven Non-slip Timing Belts
180 groove (zero-pointing)
Teeth 360 groove (timing belt)
10
2 Microswitches to Mark Zero-point
11
2 Microswitches to Mark Zeropoint
180 groove (zero-pointing)
Teeth 360 groove (timing belt)
12
3 V-groove Track Rollers per Prism
13
3 V-groove Track Rollers per Prism
14
Aluminum Case
15
Aluminum Case
16
Purely Rectangular Profile
Beam toward you
Beam away from you
17
Zero-pointing
  • McMaster-Carr Long Roller Lever Snap-Acting
    Switches
  • 2 x 8.50
  • 0.95" x 1.94" x 0.69
  • Max ratings
  • 15 Amps
  • 250 Volts AC/DC (Screw terminals)
  • 186 Watts
  • 3 terminals (SPDT)
  • Rising edge means zero, falling edge can mean
    anti-zero if machined precisely

18
Rollers
  • McMaster-Carr Adjustable-Height Perma-Lube
    V-Groove-Guided Track Rollers
  • 6 x 62.93
  • 1/32" adjustable height play
  • Ball bearings
  • Permanently lubricated and sealed maintenance
    free
  • 90 groove
  • Smallest available
  • About 1 2/3 long
  • 1 ½ roller diameter

19
Timing Belts
  • McMaster-Carr Double-Sided Flexi-Timing Belts and
    Pulleys
  • 2 x 29.66 (belts) 2 x 23.56 (pulleys)
  • Single stranded (one groove)
  • 0.20" wide
  • 24 outer circumfrence belts
  • 1 ½ diam pulleys
  • Anodized aluminum pulleys

20
Steppers
  • Oriental Motor 5-Phase Microsteppers (CRK513PAP)
  • 2 x 367, in stock
  • 0.72 Basic Step
  • 24 Volts, 1/4 Amp
  • lt 80 C operating temperature... BUT
  • We dont need high speeds nor long run times
  • Can turn off current if we install friction
    devices on prism housing
  • High torque motor current is reduced to suppress
    heat generation. Eg, to avoid temperature rise
    in precision machinery. I think this means a
    lower current gives the same torque as the
    standard model
  • We make the flanges
  • Want to use the same focus stepper drivers
  • 5 pins per stepper

Stock Driver
21
Wiring
  • Goal single cable
  • Wires
  • 3 x 2 microswitches
  • 5 x 2 steppers
  • 16 wires
  • Run wires along inside case surfaces to single D
    connector
  • ADC cable runs to on-board PISCO driver rack
    (water cooled)
  • Drivers controlled downstairs

Single D Connector
22
Summary
  • About 18 lbs
  • 4 ½ deep x 11 wide x 10 tall
  • Goals
  • Single cable from ADC to driver rack
  • Use focus stepper driver instead of stock
  • Minimize stepper heat dissipation by switching
    off current and using simple friction devices
  • Heat dissipation by ADC negligible
  • Assumed by drivers
  • Driver rack water cooled
  • To do
  • Mounting holes
  • Internal wire guides
  • Microswitch mounts
  • Alignment (tolerances)
