Plasmaspheric Bulge

1
(No Transcript)
2
Ionospheric EffectsduringSevere Geomagnetic
StormsJohn FosterMIT Haystack Observatory
NASA CDAW Mar. 14, 2005
3
Ionosphere / Storm Effects

• Ionospheric Conductivity (E F Region) Affects
  Magnetospheric Currents
• Cold Plasma Redistribution Alters I-T Flywheel
  Coupling and Energy Dissipation
• Cold Plasma in Msph Alters W-P Interactions
• Plasmaspheric Material Injected into Tail and
  Plasma Sheet as Erosion Plumes Enter Cusp
• I-M Coupling in SAPS Affects Ring Current
  Development

4
Visualizing the Initial Stages of an Ionospheric
Storm
5
GPS samples the ionosphere and plasmasphere to an
altitude of 20,000 km
TEC is a measure of integrated density in a 1 m2
column 1 TEC unit 1016 electrons m-2
6
Stormtime Ionosphere

• The low and mid-latitude ionosphere is strongly
  perturbed during geomagnetic disturbances
• Low-latitude cold plasma is carried throughout
  the M-I system by disturbance electric fields.
• Storm Enhanced Density (SED) forms at Equatorward
  Edge of Ionospheric Trough
• Ionospheric conductance shapes magnetospheric
  electric fields (e.g. SAPS Sub-Auroral
  Polarization Stream)

7
Todays Weather NEXRADObservations of Storm
Front over N. America
8
Analysis Understanding are Well Developed
9
Space Weather Storm Fronts (GPS TEC Observations)
Foster et al. GRL 2002
10
IS Radar Observes Storm Enhanced Density
Millstone Hill IS Radar
Foster, JGR, 1993
11
Ionos Storm Characteristics are Repeatable
12
WG3 Questions Ionospheric Storms

• 1) What Happens during the first 60 min of a
  Storm?
• 2) What is the Source of the SED at Mid
  Latitudes?
• 3) What are the Impacts of Neutral Wind Effects?
• 4) How is the Plasma Bulge Created?
• 5) Can Models Describe the O/N2 Changes?
• 6) Why is there a Longitude Dependence of the TEC
  response to storms?

13
WG3 Data Sets Characterize Ionospheric Effects
and Address the Mechanisms Behind Them
14
Spin Up of Neutrals in E Region during
SuperstormsMillstone Hill Lower Thermosphere
Observations
Goncharenko et al, JGR, 2004
(cf. G. Siscoe CDAW tutorial)
15
Space Weather Effectsof Ionospheric Cold Plasma
Redistribution

• Steep Mid Latitude TEC Gradients
• Radiation Belt Modification - Greatly Eroded
  Plasmasphere - Loss of Radiation Belt Particles
• Ionospheric Irregularities Scintillation
• Equatorial / Low-Latitude Ionospheric
  Perturbation (Spread F)
• Ionospheric Perturbation at Polar Latitudes -
  Polar Tongue of Ionization

16
SED Plume forms Polar Tongue of Ionization
GPS TEC Map
Merged SuperDARN/DMSP Convection
Foster et al., JGR 2004
17
Space Weather Severe TEC Gradients over CONUS
18
IMAGE EUV observationsSED Plumes accompany
Plasmasphere Erosion
April 11, 2001
19
Extreme Space WeatherOct 2003
SuperstormSevere Plasmasphere Erosion
(EUV images courtesy J. Goldstein)
20
TEC Plume Mapped to Equatorial Plane
21
Space Weather Radiation Belt ModificationHigh-En
ergy Electrons 17 Oct.-1 Dec.
(Courtesy D. Baker)
22
Regions of Wave-Particle Interactions
(Courtesy D. Baker)
23
Energetic Ion Precipitation on Plume Field Line
SAPS
plasmapause
EMIC Waves
24
Destabilization of Ion Wavesin Detached Plasma
Regions
Sub-Auroral Polarization Stream
N Hemis L2.5
6 sec period
25
What Drives the Erosion Plume?Sub-Auroral
Polarization Stream (SAPS)

• Strong Stormtime Electric Fields appear
  between the plasmasheet and the plasmapause
• Statistical Studies indicate the Persistence and
  Predictability of the Polarization Stream
• Storm Enhanced Density is formed where the
  Polarization Stream overlaps the Plasmasphere
• Polarization Electric Fields Structure the Outer
  Plasmasphere forming Plasmaspheric Tails

26
Sub-Auroral Polarization Stream
DMSP F15 6 April 2000
21 MLT
Plasmapause
Plasmasheet
2-Cell Convection
27
Magnetospheric DriverDisturbed Ring
Currentdrives FAC intoSub-Auroral Ionosphere
EXTENDING TO PLASMASHEET
28
Ring Current / SAPS/ SED Plume(Sub Auroral
Polarization Stream Electric Field)

• Duskside Region-2 FACs close poleward across
  low-conductance gap
• SAPS Strong poleward Electric Fields are set up
  across the sub-auroral ionosphere
• SAPS erodes the outer plasmasphere

AURORAL OVAL
LOW SSAPS E FIELD
29
Millstone Hill Radar Scans Span Auroral and
Polarization Stream Convection 20-Year Database
used to Determine Statistical Features
30
(No Transcript)
31
Average Latitude of SAPS
32
(No Transcript)
33
Geo-effective Convection PatternTwo-Cell
Auroral Convection SAPS
34

March 31, 2001DMSP F13
35
Where does the SED Plasma Come From?Inner
Magnetosphere Low Latitude View
36
Low-Latitude Ionosphere PlasmasphereEffects
of Sub-AuroralDisturbance Electric Fields

• Undershielded eastward electric field Strong
  uplift at equator redistributes plasma to higher
  latitudes
• Mid-Latitude TEC Spread EA BulgeDownwelling
  poleward/sunward plasma transport increase TEC
  at low mid latitudes
• SED/TEC plumes plasma tailsSAPS overlaps
  outer plasmasphere (PBL) carrying thermal plasma
  sunward

37
References Greenspan et al. (March 1989 storm)
Basu et al. (July 2000 storm)
38
Spread F (Bubbles) in Enhanced TEC
RegionFoster Rich, 1998
(Courtesy J. Makela)
39
Equatorial Anomalies Spread Poleward
40
(No Transcript)
41
October 30, 2003 Plasma Redistribution
TEC hole
Similar Structure
42
(No Transcript)
43
Another Example - Similar Structure
44
(No Transcript)
45
Watch for formation of Bulge at 1930 UT(6
hours later Bulge remains at 285 E longitude)
46
Space-Based View of May 2003 Event
47
(No Transcript)
48
Bulge seen from Ground by GPS TEC
49
(No Transcript)
50
March 31, 2001 1908 UT
51
Ionosphere / Storm Effects

• Ionospheric Conductivity (E F Region) Affects
  Magnetospheric Currents
• Cold Plasma Redistribution Alters I-T Flywheel
  Coupling and Current Dissipation
• Cold Plasma Alters W-P Interactions
• Plasmaspheric Material Injected into Tail and
  Plasma Sheet as Erosion Plumes Enter Cusp
• I-M Coupling in SAPS Affects Ring Current
  Development

52
(No Transcript)
53
Mid-Latitude SED forms a source for thePolar
TOI(as Dst Falls)
54
October 29/30, 2003 StormGlobal Thermal
PlasmaRedistribution
Northern Hemisphere
Global TEC (Noon in center)
Southern Hemisphere
55
Points to Remember

• Electric Fields Map between Altitude Regimes
  Independent of their Source (This is especially
  true in the Inner Magnetosphere where parallel
  electric fields usually can be ignored)
• The Bulk of Thermal Plasma is of Ionospheric
  Origin (Solar production at low
  altitude/latitude)
• Thermal Plasma Dynamics is Controlled by the
  Electric Field (ExB)
• Ionospheric effects Map into the Magnetosphere

56
Ionospheric Storm Fronts

• During strong geomagnetic disturbances,
  greatly-enhanced ionospheric total electron
  content (TEC) develops at mid latitudes in the
  post-noon sector
• Plumes of storm-enhanced density (SED) are swept
  toward the cusp ionosphere by the sub-auroral
  (SAPS) electric field
• Plasma Redistribution Spans Equatorial Mid -
  Auroral and Polar Latitudes

57
Why the Big Effect in the Atlantic
Sector?Polarization E Field at Conductivity
Gradient(Sunset Terminator 21 UT)
18LT 00LT 06LT
S
Pre-reversal enhancement
Vz E/B
East West E Field
B 30 smaller near SAA
