Tomas E' Canty ServerCare, Inc'

1
Tomas E. CantyServerCare, Inc.
Oracle Real Application Clusters Best Practices
Tuning in 11g
2
Speaker Qualifications

• Thomas E. Canty, President, ServerCare, Inc.
• Nearly 20 years of Oracle experience, starting
  with version 5
• Has presented at IOUG, OpenWorld, NoCOUG, and
  IASA
• Has been a DBA, Developer, Architect, and IT
  Manager
• Has worked with Fortune 100 companies in
  Healthcare, Technology, Pharmaceuticals, and
  Telecom, as well as Major Universities
• Has been running ServerCare for almost 10 years,
  specializing in on-shore Remote DBA, Remote
  Sysadmin, Implementation, and Consulting

888-918-6309 http//www.ServerCare.com
3
Todays Agenda

• RAC Overview, Architecture, Cache Fusion
• Configuration Monitoring
• Tuning Areas
• Best Practices
• New Features Other Notes
• Conclusion

4
Objectives

• Identify areas requiring tuning
• How to obtain metrics
• How to resolve bottlenecks
• Cover tuning areas with the most benefit
• Only RAC specific items will be covered

5
RAC Overview

• RAC is highly availability, flexible, and
  scalable
• Shared database is accessible from all nodes in
  the cluster
• Can runs on commodity hardware such as
  Linux-based x86
• Requires proper monitoring and tuning
• Capabilities and limitations should be understood

6
Glossary Of Terms

• ADDM - Automatic Database Diagnostic Monitor,
  tuning advice
• AWR - Automatic Workload Repository, performance
  statistics
• Cache Fusion - Shares data in memory across nodes
• GCS - Global Cache Service, guarantees cache
  coherency
• GRD - Global Resource Directory, maps data in
  memory
• HBA Host bus adapter, connects host to network
  and storage

7
Glossary Of Terms (cont.)

• Interconnect - High speed, low latency private
  network
• Jumbo Frames - Network Maximum Transfer Unit
  (MTU)
• LMS - Lock Manager Service, transports blocks
  across nodes
• NIC Bonding - Logically combining 2 or more
  physical NICs
• UDP - User Datagram Protocol, supported for the
  Interconnect
• VIP - Virtual Internet Protocol, allows failover
  for high availability
• Well see more as we go

8
RAC Architecture

• Clustered nodes CRS
• crsd
• ocssd
• evmd
• Shared storage
• OCRs (1 or 2)
• Voting Disks (3 or more)
• Network
• Public IPs
• Private Interconnect
• VIPs

9
Overview of Cache Fusion

• Major component of RAC, and a key difference from
  OPS
• Enables sharing of data in memory across nodes
• Performed by Lock Manager Service (LMS)
• Maintained in Global Resource Directory (GRD)
• Guarantees cache coherency, read consistency

10
SGA Structure Processes

• Details of Interconnect and Cache Fusion processes

11
Configuration Monitoring
12
Interconnect

• Interconnect is non-routable, private network
• Dedicated switch, gigabit or faster
• Protocols UDP (RDS new for use in 10.2.0.3 and
  higher)
• Typical bandwidth utilization
• Normal 20 30
• Saturated gt70

13
Verify Interconnect IP Addresses

• Ensure Interconnect IP is not using public
  network
• oracle_at_rac1 oifcfg getif
• bond0 10.10.10.0 global
  cluster_interconnect
• eth0 172.16.150.0 global public
• oracle_at_rac2 oifcfg getif
• bond0 10.10.10.0 global
  cluster_interconnect
• eth0 172.16.150.0 global public
• Database instance alert log posts Interconnect
  and protocol
• Query from the database
• vcluster_interconnects, vconfigured_interconnec
  ts

14
Network Statistics

• Use ifconfig -a
• Check configuration, RX TX errors, overruns
• oracle_at_rac2 /sbin/ifconfig -a
• bond0 Link encapEthernet HWaddr
  001125A86C35
• inet addr10.10.10.2 Bcast10.10.10.3
  Mask255.255.255.252
• . . . . . . . . . .
• RX packets657830061 errors0 dropped0
  overruns0 frame0
• TX packets527418621 errors0 dropped0
  overruns0 carrier0
• collisions0 txqueuelen0
• RX bytes579340506510 (539.5 GiB) TX
  bytes430094970294 (400.5 GiB)
• eth0 Link encapEthernet HWaddr
  001125A86C34

15
Network Packet Info by Protocol

• Use netstat s
• Contains details of network with packet
  information
• oracle_at_rac1 netstat -s
• Ip . . . .
• Tcp . . . .
• Udp
• 137338287 packets received
• 7376 packets to unknown port received.
• 0 packet receive errors
• 148822392 packets sent
• Use the ping utility to determine packet loss and
  timing

16
Verify Cluster Configuration

• Make sure cluster connection configuration is
  correct
• oracle_at_rac1 cluvfy comp nodecon n rac1
• Verifying node connectivity...
• Checking node connectivity...
• Node connectivity check passed for subnet
  10.10.10.0 with nodes(s) rac1.
• Node connectivity check passed for subnet
  172.16.150.0 with node(s) rac1.

17
System Monitoring

• CPU utilization top, mpstat
• Disk I/O times iostat
• Memory free
• Kernel messages - /var/log/messages,
  /var/log/dmesg
• Obtain cluster statistics crs_stat, srvctl

18
Tuning
19
General

• Stress test application on single instance
  database first
• Simulate I/O load (tools such as Orion and
  Database Replay (11g))
• Modify OS parameters
• Modify Clusterware parameters
• Modify Database parameters

20
AWR Report

• Global Cache Load Profile
• Global Cache Efficiency Percentages
• Messaging Statistics
• Consistent Read (CR) and Current Block Segments
• Concentrate on top 5 wait events
• Use AWR (and Statspack is still useful too)

21
Cache Fusion data block messaging traffic

• Global Cache Load Profile
•
  Per Second Per Transaction
•
  ---------------- --------------------
  -
• Global Cache blocks received
  4.30 3.65
• Global Cache blocks served
  23.44 19.90
• GCS/GES messages received 133.03
  112.96
• GCS/GES messages sent
  78.61 66.75
• DBWR Fusion writes
  0.11 0.10
• Est Interconnect traffic (KB)
  263.20
• Calculate Network Traffic from AWR report
• Network traffic received Global Cache blocks
  received DB block size 4.3 8192 .01
  Mb/sec
• Network traffic generated Global Cache blocks
  served DB block size 23.44 8192 .20
  Mb/sec

22

• Global Cache Efficiency Percentages
• Data blocks retrieved from local cache or remote
  instance
• Global Cache Efficiency Percentages (Target
  localremote 100)?
• Buffer access - local cache 99.12
• Buffer access - remote cache 0.75
• Buffer access - disk 0.13
• Messaging Statistics
• Statistics on messages sent
• Should be less than 1 millisecond
• Global Cache and Enqueue Services - Messaging
  Statistics
• Avg message sent queue time (ms)
  0.4
• Avg message sent queue time on ksxp
  (ms) 0.2
• Avg message received queue time (ms)
  0.0

23

• Segments by CR Blocks Received
• -gt Total CR Blocks Received 329
• -gt Captured Segments account for 84.2 of
  Total
•
  CR
• Tablespace
  Subobject Obj. Blocks
• Owner Name Object Name
  Name Type Received Total
• ---------- -------- -------------------
  ---------- --------- ------------ ----------
• PAYMENTECH DATA BATCH
  TABLE 90 27.36
• SYS SYSTEM SMON_SCN_TIME
  TABLE 25 7.60
• PAYMENTECH DATA IDX_BATCH_ORDER_ID
  INDEX 21 6.38
• SYS SYSAUX SYS_IOT_TOP_8782
  INDEX 16 4.86
• SYS SYSAUX WRI_ADV_PARAMETERS_
  INDEX 16 4.86
• Segments by Current Blocks Received
• -gt Total Current Blocks Received 2,667
• -gt Captured Segments account for
  96.7 of Total


• Current

24
RAC Wait Events

• Broader category called Cluster Wait Class
• Characterized as Current or CR
• Current - blocks read into memory for the first
  time
• Consistent Read (CR) - denotes block for read
  access

25
GC Current Block 2-way

• Occurs during cache fusion process
• Instance A requests block from master instance B
• If the block is available on B then it is sent to
  A

26
GC Current Block 3-way

• Maximum three hops, not dependent on number of
  nodes in cluster
• Instance A requests block from master instance B
• B does not have block, directs to instance
  holding block or
• B directs request to disk

27
More Global Cache Waits

• GC CR/current block congested
• LMS not keeping up under heavy load
• Block transfer process delayed, indicates low CPU
  resources
• GC CR/current block busy
• Delay before block is sent, indicates write
  contention
• GC current grant busy
• Permission to access block is granted, but is
  blocked
• GC CR/current block request
• Placeholder event, active while waiting for a
  block

28
Block Access Cost

• Cost of retrieving the block, made up of the
  following
• Message propagation delay
• Inter process CPU
• Block Server Load

29
Block Access Latency

• Factors affecting request processing time
• Operating System
• Oracle processing time
• Available Interconnect network throughput
• CPU load on other nodes

30
Operating System

• Block latency related to CPU utilization
• LMS process is CPU intensive
• Typically one LMS for every 2 CPUs
• Waits - GC CR/current block congested
• Apply OS and kernel patches

31
I/O Capacity

• High I/O can be a result of
• Node addition, increased usage, database size
• Bad queries always keep a watch for
• Dissimilar disks within disk group - group
  similar disks together
• Wait event gc cr block busy is an indicator
• (Global Cache Consistent Read)

32
Best Practices
33
General

• Ensure adequate resources on surviving nodes
• Benchmark cluster configuration
• Load test on single instance first
• Avoid serialization in application design. Make
  use of Parallelization
• Apply few changes at a time
• Sequences require a little extra thought in RAC

34
Network

• Use Jumbo Frames for Interconnect, increased MTU
• JF lowers CPU utilization, reduces bonding
  overhead
• Fewer frames needed for large I/Os
• All components in network must support JF
• Utilize NIC bonding/pairing for redundancy
  performance
• Monitor dropped packets, timeouts, buffer
  overflows, transmit and receive errors
• Verify that interconnect is not going over public
  network

35
Hardware

• Redundancy at all levels - server, storage,
  network components
• As nodes are added, add HBA cards, switches, disk
  array controllers
• Load balance LUNs across HBA ports
• Enable hyperthreading at the OS level
• Use asynchronous I/O
• Set aio-max-size to 1,048,576, aio-max-ns to
  56k
• If using NFS, OCFS2, QFS, VxFS etc., use direct
  I/O as well
• Check setting for filesystem_io_option. Should be
  setall

36
Monitoring Tuning

• Use OEM Database Control or Grid Control
• Recommend getting the Tuning and Diagnostics
  packs
• View overall system status, status of cluster,
  alert logs
• Monitor throughput across Interconnect
• Make decisions to add or redistribute resources
• Tune SQL plans and schemas for better
  optimization

37
New Features Other Notes
38
New Features in 10gR2 11g

• FAN Fast Application Notification, relies on
  ONS messages to be aware of current cluster
  configuration, connects only to instances able to
  respond
• ASM options sysadm role, new ASMCMD commands
• AWM Automatic Workload Manager, manages
  distribution for optimal performance, services
  restored onto surviving nodes
• Extended distance (stretch) clusters, physically
  separate
• CRS - Now provides HA for non-Oracle applications
• LBA Load Balancing Advisor determines load.
  Works with FAN/ONS

39
Other Notes

• OCFS Oracle Clustered File System available on
  Linux (OCFS2) and Windows (OCFS (v1))
• Commonly used for spfile, archive logs, backups,
  a controlfile, even voting disk OCRs
• When it has problems, it can fence the node.
  Known bugs prior to 10.1.0.4 patch.
• Recommend using the private interconnect to
  minimize fencing
• When using bonding, recommend doubling
  idle_timeout from 30 to 60 seconds (probably a
  good idea even without bonding)
• In a future release, ASM will be able to provide
  a clustered filesystem (on any platform), so
  recommend using OCFS2 only for non-critical
  things such as backups, archive logs, etc.

40
Other Notes (cont.)

• Services Can define a workload type and
  partition that workload. For example, allow HR
  to use only nodes A and B. Future versions will
  use Policies.
• Storage LOTS of options, but RAID-01 still
  king. Storage is cheap per GB, so the argument
  for RAID-3/5/6 is not strong. Fault Tolerant
  (parity) is not the same as Redundant (mirroring)
• TAF FCF are primarily client-side options for
  failover. You need to research the pros cons of
  using them for your environment.
• For the moment, hardware mirroring still beats
  ASM mirroring. That may change. However, if you
  can afford multiple arrays, ASM mirroring allows
  100 redundancy throughout the hardware stack.
• But third voting disk needs to go somewhere NFS
  is supported

41
Other Notes (cont.)

• Licensing Oracle raised license fees in June
  08
• RAC is an add-on in Enterprise Edition
• RAC is no extra charge in Standard Edition, but
  limited to 4 sockets. Most common config is 2
  nodes with 2 dual-cores in each node
• Cores do not count in SE except for current Intel
  quad cores, because they are 2x2s bridged
  together. AMDs are not affected by this, and the
  Intel quads coming out later this year will not
  be either. Multi-core sparcs have some special
  rules too.
• RAC is not available in Standard Edition One,
  Personal Oracle, or Oracle Express
• RAC can be setup in a virtualized environment
  (including now Oracles own Virtual Machines)
  without additional cost.

42
Conclusion
43
Items Learned in this Session

• RAC databases are complex in nature
• Scalability, availability start with initial
  configuration
• Proper configuration is essential
• Monitoring and tuning requires RAC skills and
  knowledge
• DBA needs specialized training, experience

44
Where to Find More Information

• Additional sessions here at OpenWorld 2008
• Plenty of information available on the internet
• Oracle Technology Network
• http//www.oracle.com/technology/index.html
• Ask Diane or me
• tom.canty_at_servercare.com
• dpetersen_at_servercare.com
• 1-888-918-6309

45
Questions?

• Covered many RAC topics today
• Additional questions, please contact me
• tom.canty_at_servercare.com
• 1-888-918-6309

46
Oracle Real Application Clusters Best Practices
Tuning in 11g

• Thank You!
• Please fill out surveys!

tom.canty_at_servercare.com 1-888-918-6309 www.Serve
rCare.com
