Route Surveying - Slope Stakes

1
Route Surveying - Slope Stakes
The University of British Columbia Departments
of Civil Engineering

• Instructor A. Bebamzadeh
• Civil 235 Plane Surveying

2
Introduction
Centre-line layout is one of the first steps in
constructing a road. The road is broken into
stations. At each station, the location of the
centre-line, shoulders and slope stakes are
identified.
Slope stakes To guide the construction
process Earthwork calculation
Picture taken from http//www.tpub.com/engbas/14-3
1.htm
3
Introduction
Terminology Grade Centre-line Shoulder Side-slope
Slope stake Side-hill section
Grade Rod H.I. elevation of the grade
Ground Rod reading of the rod at any point
Cut/fill Grade Rod Ground Rod
4
Cut/Fill
1. Cut section
Ground rod gt 0 Grade rod gt 0
H.I. gt Grade Elev.
Grade rodgt Ground rod
2. Fill section
Grade rod lt Ground rod
5
Cut Cross-section
6
Cut-Fill Transition
The cross section that passes from cut to fill is
referred to as side-hill section.
Transition line is the intersection of the grade
and the natural ground.
7
Side-hill Cross-section
(Side-hill section is where cross-section passes
from cut to fill)
Shoulder Stake
Centerline Stake
c
1
s
Slope Stake
f
Road Grade
w/2
d
Natural Ground
Cut Section
Fill Section
8
Cross-Section Data
9
Example
10
Example Slope Stake
H.I. 241.90 m , grade elevation 240.36 m rod
reading on centerline 2.65 m
centerline elevation 239.25 m grade rod
H.I. grade elevation 241.90 240.36 1.54
m first trial at point 1 ground rod
3.23 f1 grade rod ground rod 1.54 3.23
-1.69 m (the negative
sign indicates a fill) Slope stake distance from
the centre-line, d1 3.5 (1.69)(2) 6.88
m measured d1 6.2 m
The rod must be moved farther from the
centerline
11
Example Slope Stake
second trial at point 2
ground rod 3.62 m f2 1.54 3.62
-2.08 m d2
3.5 (2.08)(2) 7.66 m
measured distance d2 8.2 m
The rod is out too
far Eventually, by trial, the rod is held at
3 ground rod 3.40
fr 1.54-3.40 -1.86 m
dr 3.5 (1.86)(2) 7.22
m This distance agrees with the measured
distance dr hence, point 3 is the correct
location for the slope stake. The notes for this
slope stake will be
12
Volume of Earthwork
Cross-sectional area is calculated from the
cut/fill data.
1. Average End Area Method (exact for A1A2)
2. Prismoidal Method
(Am obtained by averaging the linear dimensions
of the end section)
13
Example Volume Calculation
For the following two stations, calculate the
volume of earthwork using the Average End Area
method and the Prismoidal method. The width of
the road-bed is 20 m and the side-slope ratio is
1.5 to 1.
14
Example Volume Calculation
m2
Similarly, for station 135200
Volume from the Average End Area method
m3
15
Field Exercise
Centreline stations
Shoulder stakes El.
Obtain grade El. at st. 5
Slope stakes
Transition line
16
Field Books
To be included in the field books
Leveling notes
Location sketch of the road
Centreline profile of the ground and grade
Plan view of the road layout
Cut/fill data for two adjacent stations
Cross-section sketches area calculations
Volume calculation of the segment
Total volume of earthwork
