Chapter 5' TCP ClientServer Example

1
Chapter 5. TCP Client-Server Example
2

• Contents
• Introduction
• TCP Echo Server
• TCP Echo Client
• Normal Startup and Termination
• Posix Signal Handling
• Handling SIGCHLD Signals
• Data Format
• and so on...

3
5.1 Introductioon

• 1. The Client reads a line of text from its
  standard input and writes the line to the server.
• 2. The server reads the line from its network
  input and echoes the line back to the client.
• 3. The client reads the echoed line and prints it
  on its standard output.

4
5.2 TCP Echo Server

• main function str_echo function
• for ( )
• clilen sizeof(cliaddr)
• connfd Accept(listenfd, (SA ) cliaddr,
  clilen)
• if ( (childpid Fork()) 0) / child
  process /
• Close(listenfd)/ close listening socket /
• str_echo(connfd)/ process the request /
• exit(0)
• Close(connfd) / parent closes connected
  socket /

5
(No Transcript)
6
void str_echo(int sockfd) ssize_t n char
lineMAXLINE for ( ) if ( (n
Readline(sockfd, line, MAXLINE)) 0) return
/ connection closed by other end /
Writen(sockfd, line, n)
7
5.4 TCP Echo Client

• main function str_cli function
• Connect(sockfd, (SA ) servaddr,
• sizeof(servaddr))
• str_cli(stdin, sockfd) / do it all /
• exit(0)

8
(No Transcript)
9
void str_cli(FILE fp, int sockfd) char sendlin
eMAXLINE, recvlineMAXLINE while
(Fgets(sendline, MAXLINE, fp) ! NULL)
Writen(sockfd, sendline, strlen(sendline)) if
(Readline(sockfd, recvline, MAXLINE)
0) err_quit("str_cli server terminated prematu
rely") Fputs(recvline, stdout)
10
Normal Startup

• How the client and server start, how they end
• What happens when something goes wrong
• the client host crashes, the client process
  crashes, network connectivity is lost
• Test method
• tcpserv
• netstat -a
• tcpcli 127.0.0.1 (local test)
• netstat -a
• ps -l

11
Normal Termination

• tcpcli 127.0.0.1
• hello, world
• hello, world
• good bye
• good bye
• D
• netstat -a grep procID
• ps
• 19130 p1 Ss -ksh
• 21130 p1 I ./tcpserv
• 21132 p1 Z (tcpserv) (Zzombie process)

12
5.8 Posix Signal Handling

• A signal (software interrupt) a notification to
  a process that an event has occurred.
• Signals can be sent
• by one process to another process(or itself)
• by the kernel to a process
• SIGCHLD signal a signal sent by the kernel
  whenever a process terminates, to the parent of
  the terminating process

13

• Every signal has a disposition (action associated
  with the signal)
• We can provide a function hat is called whenever
  a specific signal occurs. This function is called
  a signal handler and this action is called
  catching the signal. (SIGKILL(x) and SIGSTOP(X)),

• void handler(int signo)
• We can ignore a signal by setting its disposition
  to SIG_IGN. (SIGKILL(x) and SIGSTOP(X)),
• We can set the default disposition for a signal
  by setting its disposition to SIG_DFL. (terminate
  a process on the receipt of a signal)
• SIGCHLD(X), SIGURG(x)

14
5.8 Posix Signal Handling

• signal Function
• Sigfunc signal(int signo, Sigfunc func)
• struct sigaction act, oact
• act.sa_handler func
• sigemptyset(act.sa_mask)
• act.sa_flags 0
• if (signo SIGALRM)
• ifdef SA_INTERRUPT
• act.sa_flags SA_INTERRUPT / SunOS 4.x /
• endif
• else
• ifdef SA_RESTART
• act.sa_flags SA_RESTART / SVR4, 44BSD /
• endif
• if (sigaction(signo, act, oact) lt 0)
  return(SIG_ERR)
• return(oact.sa_handler)

15
5.8 Posix Signal Handling

• 2-3
• normal function prototype
• void (signal(int signo, void (func) (int) ) )
  (int)
• define Sigfunc type in unp.h header
• typedef void Sigfunc(int)
• The function prototype
• Sigfunc signal(int signo, Sigfunc func)
• 6 The sa_handler member of the sigaction
  structure is set to the func argument.
• members of sigaction structure
• void () (int) sa_handler
• sigset_t sa_mask
• int sa_flag

16
5.8 Posix Signal Handling

• 7 Set signal mask for handler
• Posix allow us to specify a set of signals that
  will be blocked when our signal handler is
  called. Any signal that is blocked cannot be
  delivered to the process.
• include ltsignal.hgt
• int sigaddset(sigset_t set, int signo)
• int sigemptyset(sigset_t set)
• int sigfillset(sigset_t set)
• int sigdelset(sigset_t set, int signo)
• int sigismember(sigset_t set, int signo)
• int sigprocmask(int how, const sigset_t set,
  sigset_t oset)
• SIG_BLOCK
• SIG_SETMASK
• SIG_UNBLOCK

17
5.8 Posix Signal Handling

• SIGALRM
• place a timeout on an I/O operation
• SA_RESTART
• a system call interrupted by this signal will be
  automatically restarted by the kernel

18
5.8 Posix Signal Handling

• Posix Signal Semantics
• Once a signal handler is installed, it remains
  installed.
• While a signal handler is executing, the signal
  being delivered is blocked.
• If a signal is generated one or more times while
  it is blocked, it is normally delivered only one
  time after the signal is unblocked. That is, by
  default Unix signals are not queued.
• It is possible to selectively block and unblock a
  set of signals using the sigprocmask function.

19
Handling SIGCHLD Signals

• Zombie State
• maintain information about the child for the
  parent to fetch at some later time
• the process ID of the child, its termination
  status, the resource of the child(CPU time,
  memory)
• the parent process ID of all the zombie children
  1(init process)-inherit the children and clean
  them up
• ltdefunctgt
• Handling Zombies
• space waste of the kernel, out of process
• wait for the children to prevent them from
  becoming zombies

20
Handling SIGCHLD Signals

• We establish the signal handler by adding the
  function call
• Signal (SIGCHLD, sig_chld)
• in Figure 5.2, after the call to listen.
• include "unp.h"
• void sig_chld(int signo)
• pid_t pid
• int stat
• pid wait(stat)
• printf("child d terminated\n", pid)
• return
• Figure 5.7 Version of SIGCHLD signal handler that
  calls wait

21

• Tcpserv02
• tcpcli01 127.0.0.1
• hi, there
• hi, there
• D
• child 16942 terminated
• accept error Interrupted system call
• // the parent is blocked in its call to accept
  when the SIGCHLD is delivered
• //sig_chld function executes, wait fetches the
  childPID and termination status, printf
• // kernel causes the accept to return an error of
  EINTER

22
5.9 Handling SIGCHLD Signals

• Handling Interrupted System Calls
• for ( )
• clilen sizeof(cliaddr)
• if( (connfdaccept(listenfd,(SA )
  cliaddr,clilen)) lt 0)
• if( errno EINTER )
• continue
• else
• err_sys(accept error)

23
5.10 wait and waitpid Functions

• pit_t the process ID of the terminated child
• statloc the termination status of the child(an
  integer) is returned through the statloc pointer.
• pid specify the process ID that we want to wait
  for.
• A value of -1 say to wait for the first of our
  children to terminate.
• option specify additional option.
• The most common option is WNOHANG.

24
(No Transcript)
25
gttcpserv03 gttcpcli03 206.62.226.35 hello
hello D child 21288 terminated
21282 p1 S ./tcpserv03 21284 p1 Z
(tcpcli03) 21285 p1 Z (tcpcli03) 21286 p1 Z
(tcpcli03) 21287 p1 Z (tcpcli03)
26
5.10 wait and waitpid Functions

• Difference between wait and waitpid
• the problem is that all five signals are
  generated before the signal handler is executed,
  and the signal handler is executed only one time
  because Unix signals are normally not queued.
• waitpid
• we must specify the WNOHANG option this tells
  waitpid not to block if there exist running
  children that have not yet terminated.

27
(No Transcript)
28
5.11 Connection Abort before accept Returns

• The three-way handshake completes, the connection
  is established, and then the client TCP sends an
  RST(reset). On the server side the connection is
  queued by its TCP, waiting for the server process
  to call accept when the RST arrives. Some time
  later the server process calls accept.

29

• Implementation
• BSD kernel
• SVR4 return an errno of EPROTO
• Posix.1g return an errno of ECONNABORTED
• EPROTO returned when some fatal
  protocol-related events occur on the streams
  subsystem.
• In the case of the ECONNABORTED error, the server
  can ignore the error and just call accept again.

30
5.12 Termination of Server Process

• Our client is not expecting to receive an
  end-of-file at this point so it quits with the
  error message server terminated prematurely.

31
SIGPIPE Signal

• What happens if the client the error return from
  readline and writes more data to the server ?
• When a process writes to a socket that has
  received an RST, the SIGPIPE signal is sent to
  the process

Default action of SIGPIPE terminate the process
32
gttcpcli11 206.62.226.34 hi there hi there bye
Nothing is echoed for bye data Reason the
default action of SIGPIPE is terminate the
process.
33

• What happens when the server host crashes,
  reboots, shutdowns
