Fractional Distillation Products

Description:

30 Theoretical Plates with Teflon Spinning Band. Boiling Flasks from 5 ml to 50 ml ... Boiling Flasks from 50 ml to 1 liter. Column Hold up less than 0.5 ml ... – PowerPoint PPT presentation

Number of Views:1914
Avg rating:3.0/5.0
Slides: 55
Provided by: paulvan50
Category:

less

Transcript and Presenter's Notes

Title: Fractional Distillation Products


1
(No Transcript)
2
Fractional DistillationProducts
  • Presented with the Cooperation
  • Of our Partners
  • Sigma Delta Technologies

3
(No Transcript)
4
  • Founded 1966

5
  • Founded 1966
  • Laboratory Distillation Equipment

6
  • Founded 1966
  • Laboratory Distillation Equipment
  • Design, Manufacturing, Sales and Service

7
(No Transcript)
8
Fractional DistillationOrigins
9
Fractional DistillationToday
10
Our Fractional DistillationProduct Range
11
Fractional Distillation Products
800 Micro-Still 5-50 ml
36-100 50-1000 ml
9600 1-100 liters
12
Common Applications of Fractional Distillation
  • Flavor and Fragrance Purification
  • Essential Oil Purification
  • Petroleum Distillation
  • Solvent Recycling
  • Chemical Purification

13
800 Micro-Distillation
  • 30 Theoretical Plates with Teflon Spinning Band
  • Boiling Flasks from 5 ml to 50 ml
  • Column Hold up less than 0.5 ml
  • Manual or Automatic Operation

14
36-100 Features
  • 200 Theoretical Plates with Teflon Band
  • Boiling Flasks from 50 ml to 1 liter
  • Column Hold up less than 0.5 ml
  • Manual or Automatic Operation

15
(No Transcript)
16
36-100 Distillation System
Magnified View of the Spinning Band
17
Optional Vacuum Control System
  • Automatically Controls Vacuum Level
  • Vacuum Levels from 760 to 0.1 mm Hg
  • Digital Display of Vacuum Level
  • Cold Trap Protects Vacuum Pump and Vacuum Sensor

18
36-100 with Automatic Fraction Collector
  • 4 or 8 Place Models
  • Automatically Collects Fractions Based on Vapor
    Temperature
  • Graduated Receivers of various sizes

19
Close-Up of Fraction Collector
20
Close-Up of Fraction Collector
21
Distillation System in a Mounting Module
22
Distillation System in a Enclosure Cabinet
23
9600 Distillation Systems
  • Spinning Band and Packed Columns
  • 15 to 50 Theoretical Plates
  • 1 to 50 liter Capacities
  • Automatic and Manual Models

24
9600 Spinning Band Distillation System
25
9600 Rack Mount Spinning Band Distillation
26
50 Liter Distillation System
27
Distillation Column
Fill Port
Temperature Probe
Boiling Flask
Heating Mantle
28
Spinning Band Motor
Condenser
Reflux Valve
Vapor Temperature
29
Controller
Secondary Cooler
Two Fraction Collector
Receivers
30
Ready for Distillation
31
Vapor Rising
32
Total Reflux
33
Low Boiling Fraction
34
Transition
35
High Boiling Fraction
36
9600 Spinning Band Distillation System
Magnified View of the Spinning Band
37
Packed Column Distillation
Packed columns are packed with a material that
creates surface area within the distillation
column. Vapors rise through the column, are
condensed by the condenser and fall back down the
column. This material is called condensate. The
condensate wets the packing. Ascending vapors
rise through the wet packing and are force into
intimate contact with the condensate. This
intimate contact causes the vapor to become
enriched in the lower boiling material. This
process is called rectification.
38
Spinning Band Distillation
  • Ascending vapors are forced into intimate contact
    with descending condensate by the mechanical
    force of the spinning band. This forceful
    contact between the liquid and vapor creates a
    very high degree of rectification. This is why
    spinning band distillation gives so many
    theoretical plates in such a short column.

39
Recycling Acetonitrile
CH3CN
  • Waste Reduction
  • Solvent Reuse

H20
40
Get the water out!
  • Most HPLC waste contains 70-90 water
  • Distill off the Acetonitrile Azeotrope
  • Water residue can be put down the drain
  • Big reduction in volume and disposal cost

41
Reuse the Acetonitrile
  • Recycled Acetonitrile is the Azeotrope 8416
  • Can be reused in most HPLC analyses

42
(No Transcript)
43
(No Transcript)
44
Palm Oil Upgrading
  • Malaysian Agricultural RD Institute, Kuala
    Lumpur
  • Malaysian Agricultural RD Institute (second
    unit)
  • Malaysian Institute of Nuclear Technology
  • Malaysian Palm Oil Board

45
Essential Oil Purification
  • ADC Vietnam Patchouli Oil
  • SC Botanicals Australia Tea Tree Oil
  • Central Institute of Medicinal Aromatic Plants
    India General Research
  • Green Flavors General Research

46
Essential Oil Purification
  • Korea Ginseng Tobacco Research Institute
  • Chemical Research Institute at Ratjamangala
    Indigenous Plants
  • Ubon Ratchathani University General Research
  • Chiang Mai University Medicinal Plants

47
Flavor and Fragrance
  • Givaudan Roure, Lakeland, FL
  • Givaudan Roure, Ohio (2 units)
  • Givaudan Roure, NJ
  • Firmenich, Inc., Plainsboro, NJ
  • Florasynth, Grasse, France

48
Flavor and Fragrance
  • International Flavors and Fragrances, Union
    Beach, NJ (5 units)
  • AJMALs Perfume, UAE
  • Beijing University, Beijing, China
  • China Science Academy, Hubei, China
  • Institute for RD, Jakarta, Indonesia

49
Other B/R Product Lines
50
Crude Oil Distillation
51
Petroleum Testing
52
Histology Solvent Recycling
53
Questions?
