HighPerformance Computing on the Windows Server Platform

1
High-Performance Computing on the Windows Server
Platform

• Marvin Theimer
• Software ArchitectWindows Server HPC
  Grouphpcinfo _at_ microsoft.com
• Microsoft Corporation

2
Session Outline

• Brief introduction to HPC
• Definitions
• Market trends
• Overview of V1 version of Windows Server 2003 CCE
• Features
• System architecture
• Key challenges for future HPC systems
• Too many factors affect performance
• Grid computing economics
• Data management

3
Brief Introduction to HPC
4
Defining High Performance Computing (HPC)
HPC Definition Using compute resources to solve
computationally intensive problems
Different Platforms for Achieving Results
HPC Role in Science
Computational Modeling
Sensors
Persist (DB, FS, ..)
Technical andScientificComputing
HPC Use
Mining
Interpretation
5
Cluster HPC Scenario
Head Node
User Mgmt
Cluster Mgmt
Resource Mgmt
Job Mgmt
Web service
Job
Policy, reports
User
Web page
Admin
Management
Input
Cmd line
Job
Sensors, Workflow, Computation
Data
Data mining, Visualization, Workflow Remote query
DB or FS
Cluster Node
High speed, low latency interconnect (1GE,
Infiniband, Myricom)
Job Mgr
User App
MPI
Resource Mgr
Node Mgr
6
Top 500 Supercomputer Trends
Clusters over 50
Industry usage is rising
GigE is gaining
IA is winning
7
Commoditized HPC Systems are Affecting Every
Vertical

• Leverage Volume Markets of Industry Standard
  Hardware and Software.
• Rapid Procurement, Installation and Integration
  of systems
• Cluster Ready Applications Accelerating Market
  Growth
• Engineering
• Bioinformatics
• Oil Gas
• Finance
• Entertainment
• Government/Research

The convergence of affordable high performance
hardware and commercial apps is making
supercomputing a mainstream market
8
Supercomputing Yesterday vs. Today
9
Cheap, Interactive HPC Systems Are Making
Supercomputing Personal
Grids of personal departmental clusters
Personal workstations departmental servers
Minicomputers
Mainframes
10
The Evolving Nature of HPC
11
Windows Server HPC
12
Windows based HPC Today

• Technical Solution
• Partner Driven Solution Stack

LSF
PBSPro
DataSynapse
MSTI
Management
Parallel Applications
Applications
MPI/Pro
MPICH-1.2
WMPI
MPI-NT
Middleware
WINDOWS
Visual Studio
OS
TCP
Protocol
Gigabit Ethernet
Fast Ethernet
Interconnect
Intel (32bit 64bit) AMD x64
Platform

• Ecosystem
• Partnerships with ISV to develop on Windows
• Partnership with Cornell Theory Center

13
What Windows-based HPC needs to provide

• Users require
• An integrated supported solution stack leveraging
  the Windows infrastructure
• Simplified job submission, status and progress
  monitoring
• Maximum compute performance and scalability
• Simplified environment from desktops to HPC
  clusters
• Administrators require
• Ease of setup and deployment
• Better cluster monitoring and management for
  maximum resource utilization
• Flexible, extensible, policy-driven job
  scheduling and resource allocation
• High availability
• Secure process startup and complete cleanup
• Developers Require
• Programming environment that enables high
  productivity
• Availability of optimized compilers (Fortran) and
  math libraries
• Parallel debugger, profiler, and visualization
  tools
• Parallel programming models (MPI)

14
V1 Plans

• Introduce compute cluster solution
• Windows Server 2003 Compute Cluster Edition based
  on Windows Server 2003 SP1 x64 Standard Edition
• Features for Job Management, IT Admin and
  Developers
• Build partner eco-system around the Windows
  Server Compute Cluster Edition from day one
• Establish Microsoft credibility in the HPC
  community
• Create worldwide Centers of Innovation

15
Technologies

• Platform
• Windows Server 2003 SP1 64 bit Edition
• x64 processors (Intel EM64T AMD Opteron)
• Ethernet, Ethernet over RDMA and Infiniband
  support
• Administration
• Prescriptive, simplified cluster setup and
  administration
• Scripted, image-based compute node management
• Active Directory based security, impersonation
  and delegation
• Cluster-wide job scheduling and resource
  management
• Development
• MPICH-2 from Argonne National Labs
• Cluster scheduler accessible via DCOM, http, and
  Web Services
• Visual Studio 2005 Compilers, Parallel Debugger
• Partner delivered compilers and libraries

16
Windows HPC Environment
Microsoft Operations Manager
Head Node
Active Directory
User Mgmt
Cluster Mgmt
Resource Mgmt
Job Mgmt
Web service
Job
Policy, reports
User
Web page
Admin
Management
Input
Cmd line
Job
Sensors, Workflow, Computation
Windows Server 2003, Compute Cluster Edition
Data
Data mining, Visualization, Workflow Remote query
DB or FS
Cluster Node
High speed, low latency interconnect (Ethernet
over RDMA, Infiniband)
Job Mgr
User App
MPI
Resource Mgr
Node Mgr
17
Architectural Overview
User Workstation
Cluster
Application
Job Scripts
Data
WSE
Head Node
COM
Windows XP
Job Sched UI
Job Scheduler
HTTP
GigE
X86/64
Disk
IIS6
WSE3
MSDE
RIS
AD
Whidbey
Developer Workstation
Windows Server 2003 CCE
Application
SFU
HPC SDK MPI Sched WS Policy API
COM
Compilers
Libs
WSE
Whidbey
WSE
HTTP
Cluster Nodes
Cluster Nodes
Windows XP
Node Manager
Node Manager
GigE
X86/64
Disk
HPC Application
HPC Application
MPI-2
MPI-2
Legend
MPI-2
MPI-2
TCP
SHM
WSD/SDP
TCP
SHM
WSD/SDP
Application
Windows Server 2003 CCE
Windows Server 2003 CCE
3rd Party
GigE/RDMA
Infiniband
GigE/RDMA
Infiniband
Windows OS
MS Component
HPC Component
18
Key Challenges for Future HPC Systems
19
Difficult to Tune Performance

• Example Tightly-coupled MPI applications
• Very sensitive to network performance
  characteristics
• Communication times measured in microseconds
  O(10 usecs) for interconnects such as Infiniband
  O(100 usecs) for GigE
• OS network stack is a significant factor Things
  like RDMA can make a big difference
• Excited about the prospects of industry-standard
  RDMA hardware
• We are working with InfiniBand and GigE vendors
  to ensure our stack supports them
• Driver quality is an important facet
• We are supporting the OpenIB initiative
• Considering the creation of a WHQL program for
  InfiniBand
• Very sensitive to mismatched node performance
• Random OS activities can add millisecond delays
  to microsecond communication times

20
Need self-tuning systems

• Application configuration has a significant
  impact
• Incorrect assumptions about hardware/communication
  s architecture can dramatically affect
  performance
• Choice of communication strategy
• Choice of communication granularity
• Tuning is an end-to-end issue
• OS support
• ISV library support
• ISV application support

21
Computational Grid Economics

• What 1 will buy you (roughly)
• Computers cost 1000 (roughly)
• ? 1 cpu day ( 10 Tera-ops) 1
• (roughly, assuming 3 yr use cycle)
• ? 10TB network transfer costs 1
• (roughly, assuming 1Gbps interconnect)
• Internet bandwidth costs roughly 100
  /mbps/month (not including routers and
  management)
• ? 1GB network transfer costs 1 (roughly)
• Some observations
• HPC cluster communication is 10,000x cheaper
  than WAN communication
• Break-even point for instructions computed per
  byte transferred
• Cluster O(1) instrs/byte
• WAN O(10,000) instrs/byte

22
Computational Grid Economics Implications

• Small data, high compute applications work well
  across the Internet, such as SETI_at_home and
  Folding_at_home
• MPI-style parallel, distributed applications work
  well in clusters and across LANs, but are
  uneconomic and do not work well in wide-area
  settings
• Data analysis is usually best done by moving the
  programs to the data, not the data to the
  programs.
• Move questions and answers, not petabyte-scale
  datasets
• The Internet is NOT the cpu backplane (Internet-2
  will not change this)

23
Exploding Data Sizes

• Experimental data TBs ? PBs
• Modeling data
• Today 10s to 100s of GB is the common case
• Tomorrow TBs
• Near-future example CFD simulation of a turbine
  engine
• 109 mesh nodes, each containing 16
  double-precision variables
• ? 128 GB / time-step
• Simulate 1000s of time steps ? 100s TBs /
  simulation
• Archived for future reference

24
Whole-System Modeling and Workflow

• Today mostly about computation
• Stand-alone static simulations of individual
  parts/phenomena
• Mostly batch
• Simple workflows short, deterministic pipelines
  (though some are massively parallel)
• Future mostly about data that is produced and
  consumed by computational steps
• Dynamic whole-system modeling via multiple,
  interacting simulations
• More complex workflows (don't yet know how
  complex)
• More interactive analysis
• More sharing

25
Whole-System Modeling Example Turbine Engine

• Interacting simulations
• CFD simulation of dynamic airflow through turbine
• FE stress analysis of engine wing parts
• "Impedance" issues between various simulations
  (time steps, meshes, ...)
• Serial workflow steps
• Crack analysis of engine wing parts
• Visualization of results

26
Interactive Workflow Example

• Base CFD simulation produces huge output
• Points of interest may not be easy to find
• Find and then focus on important details
• Data analysis/mining of output
• Restart simulation at a desired point in
  time/space.
• Visualize simulation from that point forward.
• Modify simulation from that point forward (e.g.
  higher fidelity)

27
Data Analysis and Mining

• Traditional approach
• Keep data in flat files
• Write C or Perl programs to compute specific
  analysis queries
• Problems with this approach
• Imposes significant development times
• Scientists must reinvent DB indexing and query
  technologies
• Results from the astronomy community
• Relational databases can yield speed-ups of one
  to two orders of magnitude
• SQL application/domain-specific stored
  procedures greatly simplify creation of analysis
  queries

28
Combining Simulation with Experimental Data Drug
Discovery

• Clinical trial database describes toxicity side
  effects observed for tested drugs.
• Simulation searches for candidate compounds that
  have a desired effect on a biological system.
• Clinical data searched for drugs that contain a
  candidate compound or "near neighbor" toxicity
  results retrieved and used to decide if the
  candidate compound should be rejected or not.

29
Sharing

• Simulations (or ensembles of simulations) mostly
  done in isolation
• No sharing except for archival output
• Some coarse-grained sharing
• Check-out/check-in of large components
• Example automotive design
• Check-out component
• CAE-based design simulation of component
• Check-in with design rule checking step
• Data warehouses typically only need
  coarse-grained update granularity
• Bulk or coarse-grained updates
• Modeling simulations done in the context of
  particular versions of the data
• Audit trails and reproducible workflows becoming
  increasingly important

30
Data Management Needs

• Cluster file systems and/or parallel DBs to
  handle I/O bandwidth needs of large, parallel,
  distributed applications
• Data warehouses for experimental data and
  archived simulation output
• Coarse-grained geographic replication to
  accommodate distributed workforces and workflows
• Indexing and query capabilities to do data mining
  analysis
• Audit trails, workflow recorders, etc.

31
Windows HPC Roadmap
32
Call To Action

• IHVs
• Develop Winsock Direct drivers for your RDMA
  cards
• Automatically let our MPI stack take advantage of
  low latency
• Develop support for diskless scenarios (e.g.
  iScsi)
• OEMs
• Offer turn-key clusters
• Pre-wired for management and RDMA networks
• Support boot from net diskless scenarios
• Support WS-Management
• Consider noise and power requirements for
  personal and workgroup configurations

33
Community Resources

• Windows Hardware Driver Central (WHDC)
• www.microsoft.com/whdc/default.mspx
• Technical Communities
• www.microsoft.com/communities/products/default.msp
  x
• Non-Microsoft Community Sites
• www.microsoft.com/communities/related/default.mspx

• Microsoft Public Newsgroups
• www.microsoft.com/communities/newsgroups
• Technical Chats and Webcasts
• www.microsoft.com/communities/chats/default.mspx
• www.microsoft.com/webcasts
• Microsoft Blogs
• www.microsoft.com/communities/blogs

34
Related WinHEC Sessions

• TWNE05005 Winsock Direct Value
  Proposition-Partner Concepts
• TWNE05006 Implementing Convergent
  Networking-Partner Concepts

35
To Learn More

• Microsoft
• Microsoft HPC website http//www.microsoft.com/hp
  c/
• Other Sites
• CTC Activities http//cmssrv.tc.cornell.edu/ctc/w
  inhpc/
• 3rd Party Windows Cluster Resource Centre
  www.windowsclusters.org
• HPC related-links web site http//www.microsoft.c
  om/windows2000/hpc/miscresources.asp
• Some useful articles presentations
• Supercomputing in the Third Millenium, by
  George Spix  http//www.microsoft.com/windows2000
  /hpc/supercom.asp
• Introduction of the book Beowulf Cluster
  Computing with Windows by Thomas Sterling,
  Gordon Bell, and Janusz Kowalik
• Distributed Computing Economics, by Jim Gray
  MSR-TR-2003-24  http//research.microsoft.com/res
  earch/pubs/view.aspx?tr_id655
• Web Services, Large Databases, and what
  Microsoft is doing in the Grid Computing Space,
  presentation by Jim Gray http//research.microsof
  t.com/Gray/talks/WebServices_Grid.ppt
• Send questions to hpcinfo _at_ microsoft.com
