Heat and Temperature

1
Heat and Temperature
2
Temperature

• Temperature measures the speed of the molecules
• Celsius Scale
• 00C water freezes, 1000C water boils
• Fahrenheit Scale
• 320F water freezes, 2120F water boils
• Kelvin Scale0K
• 2730K water freezes, 3730K water boils
• ABSOLUTE Zero 00K

3
First Law of Thermodynamics

• The first law of thermodynamics is the
  application of the conservation of energy
  principle to heat and thermodynamics

4
Enthalpy

• Enthalpy is a quotient or description of
  thermodynamic potential of a system, which can be
  used to calculate the heat transfer
• H U(internal energy) pV (pressure Volume)
• The new variables often make the analysis of a
  system much simpler. For a gas, a useful
  additional state variable is the enthalpy which
  is defined to be the sum of the internal energy U
  plus the product of the pressure p and volume V.
  Using the symbol H for the enthalpy .

5
Entropy

• Entropy is central to the second law of
  thermodynamics
• that over time, ignoring the effects of
  self-gravity, differences in temperature,
  pressure, and density tend to even out in a
  physical system that is isolated from the outside
  world.
• Entropy is a measure of how far along this
  evening-out process has progressed.

6
Heat

• Internal Energy of a system
• Q amount of heat in joules
• Specific Heat (c)
• Cal/grams (Chemistry/Earth Science)
• Joule per gram per 0C (Physics)
• ( J/Kg 0C )

Formula Q m c D Tc
7
Sample Problem

• How much heat is needed to raise the temperature
  of 30 kilograms of liquid water from 10 0C to 20
  0C ?

8
Solution to heat problem

• Q m c D Tc (Physics)
• 30 Kg x 4.19 J/kg 0C x (20-10)0C
• 1,257J
• Q m c D Tc ( Earth Science Chemistry)
• 30,000 x 1.0 cal/g 0C x (20-10)0C
• 30,000 gm x 1.0 cal/g 0C x (20-10)0C
• 300,000 cal

9
Changes in state
10
Changes in State terms
Sublimation
Evaporation
Condensation
Melting
Freezing
11
Heating and Changes in Phase
HVAC systems transfer energy using phase changes
to absorb and radiate HEAT
12
Changes in State

• Heat of Fusion (Hf)
• Conversion from Solid Liquid
• Heat of Vaporization (Hv)
• Conversion from Liquid Gas
• Formula Q m Hf or m Hv
• Hf 80 cal/g or 334 J/g
• Hv 540 cal/g or 2260 J/g

13
Change in State Graph
1. Copy this graph2. Identify specific heat,
heat of fusion, and heat of vaporization.
14
Change in State Areas
15
Calculate Heat of Fusion from a graph
Time in minutes
mass 2.0 kg rate of loss 2.0 kJ/minute
Q mHf 8,000 J 2,000 g Hf 4 J/kg Hf
16
Boiling and Freezing Points
What is the boiling point?
140 degrees Celsius
60 degrees Celsius
What is the freezing point?
17
Sample Heat of Fusion

• How much heat energy is needed to melt 5.0
  kilograms of water at its melting point?

Q m Hf (Physics) 5 Kg x 334 J/Kg
1,670J
Q m Hf (Earth Science) 5.0 kg x 80 cal/g
5000 g x 80 cal/g 400,000 cal
18
Summary

• Temperature is a measure of the activity of
  molecules.
• Heat is a measure of energy
• Specific Heat determines the amount of energy
  that a substance stores
• Heat of Fusion or Vaporization is a measure of
  the energy stored in the physical state of matter
