Gasoline/Electric Hybrid Vehicle Update 06
2
What is a hybrid vehicle?

• A vehicle using both a gasoline engine
• and an electric motor for drive power

3
(No Transcript)
4
1st generation hybrids
5
2nd generation Prius
6
Newest Honda hybrids Accord Camry
7
Hybrid SUV
8
Ford Escape hybrid SUV
9
Future minivan hybrid
10
Subaru concept hybrids
11
Subaru R1e concept hybrid
12
Honda Insight Hybrid Hyundai Accent Hybrid Lexus
RX400h Hybrid Lexus 450h GS Hybrid Mazda Tribute
SUV Hybrid Mazda Ibuki Hybrid Mazda RX-8
Hybrid Mazda Senku Concept Mercedes Smart
ForTwo Mercury Hybrid SUV Nissan Altima Hybrid
Saturn VUE Hybrid Subaru B9 SC Hybrid Toyota
Prius Hybrid Toyota Camry Hybrid Toyota
Highlander SUV Hybrid

• Audi Q7 SUV Hybrid
• BMW X5 SAV
• Chevy S3X Hybrid
• Chevy Equinox Hybrid
• Chevy Tahoe Hybrid
• Chevy Malibu Hybrid
• Dodge Durango SUV Hybrid
• Dodge ESX3 Hybrid
• Ford Escape Hybrid
• Ford Explorer Hybrid
• Ford Fusion Hybrid
• GM Opel Astra Hybrid
• GMC Graphyte Concept
• GMC Yukon Hybrid
• Honda Civic Hybrid
• Honda Accord Hybrid

Hybrids of today tomorrow
13

• HYBRID TRUCKS
• Dodge Ram Hybrid
• Chevy Silverado Hybrid
• GMC Sierra Hybrid
• HYBRID MINIVANS
• Toyota Estima Minivan Hybrid
• Toyota Alphard Minivan Hybrid
• Toyota Sienna Minivan Hybrid
• HYBRID CROSSOVERS
• Hyundai Portico Hybrid
• Nissan Tino Hybrid

14
Similarities Differences in Todays
Hybrids
Hybrids become mainstream
15
The heart of a hybrid
16
A small gasoline engine an electric motor
17
(No Transcript)
18
(No Transcript)
19
12-volt Electrical system
 Every hybrid vehicle contains two electrical
systems a 12 volt system and a high voltage
system   Each vehicle has two separate batteries
a 12 volt battery and a high voltage battery
20
12-volt battery locations
21
Ford Escape Hybrid
300 volts
High-voltage battery in trunk, under rear floor,
or behind back seat
22
New Prius battery with metal cover removed
Liquid inside battery almost totally absorbed
Prius Ni-MH Battery
23
The loaf of bread high voltage battery
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
The D cell style high voltage battery
28
(No Transcript)
29
Honda battery pack consists of 120 cells
that  resemble D-cell flashlight batteries
30
All high voltage batteries contain
potassium hydroxide(KOH) solution   The
electrolyte gel has a pH of 13.5   Potassium
hydroxide(KOH) is highly alkaline(base)   Hazmat
information on potassium hydroxide solution
listed in Emergency Response Guidebook Guide
154
31
High voltage runs from the high-voltage battery
to the electric motor
32
(No Transcript)
33
Through 2007 model year, all high voltage wiring
connectors are bright orange
34
(No Transcript)
35
(No Transcript)
36
Never handle any orange wiring or the orange
components connected to it!
37
Opening the hood of a hybrid may reveal a hybrid
engine label and large diameter orange wiring
Honda Accord Hybrid
38
The 1st step to dealing with a hybrid is knowing
you are dealing with a hybrid!
39
Interior appears mainstream
40
Safety Features

• Dual frontal airbags-
• Seat airbags-
• Roof airbags
• Pre-tensioners-

41
Lexus RX 400h
42
Only consistent badging will be at rear of
vehicle
43
06 Prius has additional side badging
44
The Silent Hybrid
Hybrid vehicle SLEEP mode
45
Vehicle appears to be OFF except for one
ready light which will be illuminated
46
Turn ignition OFF and remove ignition Key
47
The SMART key a keyless ingition system
48
16 FEET
49
The SMART key may be inserted into slot in dash
50
1st push accessory, 2nd On, 3rd Off
51
Emergency Response Guides also suggest pulling
fuses for emergency shutdown
52
Hybrids with collision damage
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
Vehicle Fire- Follow normal vehicle
firefighting procedures for fire involving
a hybrid vehicle
59
Fire crews will not be shocked or electrocuted
60
High-voltage battery fire testing
61
(No Transcript)
62
Burn test of 2001 Toyota Prius
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
The GM hybrid pickup
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
The 42v battery is under the rear seat
75
42v battery
76
110 volt electrical receptacle inside cab
77
High-voltage line runs under bed of pickup
78
Another 110v receptacle in bed of pickup
79

•
• Hybrid vehicle Lock Out-Tag Out protocols
•
• Identify vehicle as hybrid . . .
• Stabilize vehicle. . .
• Access passenger compartment . . .
• Shift gear selector/ parking brake lever . . .
• Turn ignition OFF
• Check that dash indicator light goes out . .
• Disconnect/shutdown 12v battery . . .

80
Our Hybrid Vehicle ChallengesToday and
in the future
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87

• hood will contact ground
• in a roof-resting incident

• engine compartment
• access will be difficult

88
06 Toyota Highlander gasoline- electric hybrid
vehicle

• Power Cables
• Orange and yellow colored power cables carry
  high voltage Direct Current (DC) between the HV
  battery pack and inverter/converter. Also carries
  3-phase Alternating Current (AC) between
  inverter/converter, motor, generator, and A/C
  compressor.

89
Future General Motors(GM) gasoline-electric
hybrid vehicles

• Power Cables will be
• Orange,
• Yellow,
• and/or Blue

90
Fire Department Field Research Work McKinney,
Texas Two 2003 Honda Civic Hybrids August 2006
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
The Crash Recovery System
101
(No Transcript)
102
Please refer to Emergency Response Guides for
specific details on handling each make and model
hybrid vehicle
103
Rmoore_at_firehouse.com
104
University of Extrication
