Title: Experimental Aspects of Extra Dimensions


1
Experimental Aspects of Extra Dimensions
  • Andy Parker
  • Cambridge University

2
Outline
  • Experimentalists view of the theory
  • Gravity experiments
  • Other limits
  • Large extra dimensions at LHC
  • Real and virtual effects
  • Tevatron limits
  • NLC
  • Warped extra dimensions
  • Black hole production

3
An experimentalists view of the theory
  • SM is wonderful!
  • All experimental data is explained to high
    precision
  • Theory checked at distance scales of 1/MW 2.5 x
    10-18 m
  • Only one state is unaccounted for - the Higgs
  • There is only one free parameter which is unknown
    - MH
  • No contradiction between the best fit Higgs mass
    and search limit.
  • But theorists dont agree!
  • Higgs mass is unstable against quantum
    corrections
  • Hierarchy problem - MW80 GeV, MHlt1 TeV, MPl1019
    GeV

4
Higgs search limit at LEP
  • In SM framework, Higgs mass is well constrained.
  • Only a matter of time .
  • In SUSY models, very difficult to raise lightest
    higgs mass

5
Two views of the world.
  • Supersymmetry . Extra dimensions.

different scales
.hidden perfection
6
Epicycles
  • Typical Ptolemaic planetary model
  • Symmetry is assumed all orbits are based on
    circles
  • But the Earth is not at the centre of the circle
    (the eccentric)
  • The planet moves on an epicycle
  • The epicycle moves around the equant

From Michael J. Crowe, Theories of the World
from Antiquity to the Copernican Revolution.
7
Supersymmetry
  • Conventional method to fix Higgs mass
  • Invoke SUSY
  • Double the number of states in model
  • Invoke SUSY breaking
  • Fermion/boson loops cancel (GIM)
  • Higgs mass stabilised!
  • 105 new parameters (MSSM)
  • 48 more free parameters if RP not conserved

gt SUSY is a good pension plan for
experimentalists!
8
Extra Dimensions
  • Hypothesize that there are extra space dimensions
  • Volume of bulk space gtgt volume of 3-D space
  • Hypothesize that gravity operates throughout the
    bulk
  • SM fields confined to 3-D
  • Then unified field will have diluted gravity,
    as seen in 3-D
  • If we choose n-D gravity scaleweak scale then
  • Only one scale -gt no hierarchy problem!
  • Can experimentally access quantum gravity!
  • But extra dimension is different scale from
    normal ones
  • -gt new scale to explain

Extra dimensions are more of a lottery bet than a
pension plan!
9
Scale of extra dimensions
  • For 4n space-time dimensions
  • For MPl(4n) MW
  • n1, R1013 cm ruled out by planetary orbits
  • n2, R100 mm-1mm OK (see later)
  • -gt Conclude extra dimensions must be compactified
    at lt1mm

10
Kaluza Klein modes
  • Particles in compact extra dimension
  • Wavelength set by periodic boundary condition
  • States will be evenly spaced in mass
  • tower of Kaluza-Klein modes
  • Spacing depends on scale of ED
  • For large ED (order of mm) spacing is very small
    - use density of states
  • For small ED, spacing can be very large.

M
4-D brane
1/R
r
Compactified dimension
11
Why are SM fields confined to 3-D space?
  • Interactions of SM fields measured to very high
    precision at scales of 10-18 m
  • If gauge forces acted in bulk, deviations would
    have been measured
  • KK modes would exist for SM particles
  • For large ED, mass splitting would be small.

12
H1 results on excited fermions
95 cl
  • Many channels examined no evidence for f.

13
Gravity in 3-D space
  • Gausss theorem
  • Field at r given by

M
r
m
14
Gravity in 4-D space
4-sphere
  • Compute volume of 4-sphere

r
r sinq
q
3-sphere
15
ED signature in Gravity experiments
  • r gt R Get 3-D result
  • r lt R Get 4-D result

F
Gaussian surfaces
r
R
16
Measuring Gravity in the lab
  • Torsion balance
  • Henry Cavendish 1778 (apparatus by Michell)
  • Measured mean density of Earth (no definition of
    the unit of force).
  • Sir Charles Boys inferred G6.664x10-11Nm2/kg2
    from Cavendishs data a century later.
  • Modern value
  • G (6.6726 0.0001)x10-11 Nm2/kg2.

17
Measuring Gravity in the lab
  • Recent experiment of Long et al
  • hep-ph/0009062
  • Source mass oscillates at 1kHz
  • Signal is oscillation of test mass
  • Must isolate masses from acoustic vibrations, EM
    coupling
  • Run in vacuum
  • Isolation stacks
  • Conducting shield
  • Low temperature

Capacitor
Detector
1 kHz
Shield
Source mass
18
Deviations from Newtonian gravity
  • Gravity experiments present results in terms of
    Yukawa interaction of form
  • l gives range of force
  • a gives strength relative to Newtonian gravity.
  • a depends on geometry of extra dimensions
  • Sensitive to forces of 4x10-14 N
  • Limited by thermal noise next step, cool
    detector

19
Limits on deviations from Newtonian gravity
  • Planetary orbits set very strong limits on
    gravity at large distances.
  • but forces many orders of magnitude stronger
    than gravity are not excluded at micron scales.
  • Parameterized as a Yukawa interaction of strength
    a relative to gravity and range l
  • moduli scalars in string theories

hep-ph/0009062
1mm
20
Submillimetre gravity measurements Eot-Wash
  • Torsion pendulum experiment
  • Masses are 10 holes in each ring
  • Lower attractor has two rings with displaced
    holes, rotates slowly
  • Geometry designed to suppress long range signals
    without affecting shortrange ones
  • Membrane shields EM forces
  • All surfaces gold plated.
  • Separation down to 218mm

21
Torsional pendulum data
  • Data from one turn of base plate, with fitted
    expected curve
  • Angular precision 8nrad
  • Signal would have higher harmonic content and
    different dependence on distance.

22
Deviations in data
  • Measured torques at 3 frequencies
  • Deviations from Newtonian prediction

a3 l250mm
23
Limit from torsional pendulum
  • New limit sensitive to scales lt3.5 TeV for n2

n2
24
Casimir effect
r
  • Casimir (1948) predicted force between 2 plates
    from field fluctuations
  • This will become a background at distances around
    1mm
  • Scan gold probe across surface
  • Fgrav varies as probe moves, but Fc is constant.

Plate area A
Gold probe
d
d
2d
25
Pioneer 10
  • Pioneer 10 is leaving the solar system after 30
    years in flight.
  • Orbit shows deccelaration from force of 10-10 g
  • Radiation pressure?
  • Solar?
  • Antenna?
  • Heat?
  • Gas leaks
  • Time dependence?

26
Limits from g-2 experiments
  • g-2 is best measured number in physics
  • Theory
  • aSM (g-2)/2
  • 11659159.7(6.7)x10-10
  • Experiment (PDG)
  • 11659160(6)x10-10
  • LED can give contributions from KK excitations of
    W, Z, g, O(10-10)
  • (Cirelli, Moriond)
  • Brookhaven experiment hep-ph/0105077

27
Astrophysical Constraints
  • Supernova remnants lose energy into ED, but
    production of KK states restricted to O(10MeV)
  • Remnant cools faster
  • Data from SN1987A implies
  • MD gt 50 TeV for n2
  • PRL 83(1999)268

28
Neutrino oscillations
  • Neutrino oscillations could occur into sterile
    neutrinos
  • KK excitations of SM fermion singlets can mix
    with neutrinos to form sterile states
  • Oscillation data (SNO, Super-Kamiokande) are
    well fitted by oscillations into standard
    neutrino states
  • -gt little room for sterile states
  • -gt bound on ED models
  • -gt model dependent limits on parameters
  • Eg LBNL-49369 gives Rlt0.82 mm

29
Signatures for Large Extra Dimensions at Colliders
  • ADD model (hep-ph/9803315)
  • Each excited graviton state has normal
    gravitational couplings
  • -gt negligible effect
  • LED very large number of KK states in tower
  • Sum over states is large.
  • gt Missing energy signature with massless
    gravitons escaping into the extra dimensions

G
30
LEP Searches for Extra Dimensions
  • Search for real graviton production
  • Cross section
  • No evidence for excess rate in photonEtmiss -gt
    Set limits
  • Search for deviations in di-lepton and di-boson
    production

31
LEP Limits on direct graviton production
32
LEP limits on virtual graviton interactions
  • Search for deviations from SM in dilepton and
    diboson production
  • MS 1TeV? Set 95 CL
  • l depends on quantum gravity theory

MS limits
33
Signatures at the LHC
  • Good signatures are LBNL-45198
  • Jet missing energy channels ATL-PHYS-2001-012
  • gg -gt gG
  • qg -gt qG
  • qq -gt Gg
  • Photon channels
  • qq -gt Gg
  • pp -gt ggX Virtual graviton exchange
  • Lepton channels
  • pp -gt l l X Virtual graviton exchange

34
Real graviton production
  • Cross section
  • Note ED mass scale and n do not separate -gt
  • difficult to extract n
  • Can use cutoff in MD from parton distributions
  • For ngt6, cross section unobservable at LHC
  • Quantum gravity theory above MD unknown -gt
  • Calculation only reliable at energies below MD

35
Missing ET analysis
  • pp -gt jet ETMiss Jet energies gt 1 TeV
  • Dominant backgrounds
  • Jet Z -gt n n
  • Jet W-gt t n
  • Jet W-gt e n
  • Veto isolated leptons (lt10 GeV within DR0.2)
  • Instrumental background to ETMiss is small


Use lepton veto
36
High PT jet cross section
  • ETJet gt 1 TeV
  • h Jet lt 3
  • 100fb-1 of data expected
  • SM Background 500 events
  • No prediction for ngt4

SM Background
37
Lepton veto and trigger
  • Veto efficiency 98 per lepton
  • Reject
  • 0.2 signal
  • 23.3 JWt
  • 74.3 JWe
  • 61.1 JWm

38
Jet multiplicity - signal scenarios
  • Jet multiplicity in signal increased by gg
    production process and higher mass
  • Mean 2.5

39
Jet multiplicity background
  • Background lower jet multiplicity
  • Lower mass
  • Less gg production
  • Mean 2.0
  • But at high ET, mean 4 is similar

40
PT and h distributions
  • PT of jet is harder in signal
  • Discrimination in h is too poor to be useful

41
Rejection of W(tn) background
  • W(tn) background has jet near missing ET
  • Cut at df0.5
  • Reject
  • 6 signal
  • 27 W(tn)
  • 11 total background

42
Final missing ET distributions
  • Signal and backgrounds after cuts for 100fb-1

43
Missing ET signal
  • Signal
  • Excess of events at high ET
  • Dominant background
  • Z-gtnn

44
Calibration of Z-gt nn background
  • Use Z-gt ee
  • Two isolated electrons, PTgt15, Mee within 10 GeV
    of MZ
  • Account for acceptance differences e, m, n
  • BRs differ by factor 3, so calibration sample
    has less statistics

45
Background estimates
46
Signal event numbers ETgt1TeV
47
Discovery potential
5s discovery limits, ETgt1 TeV, 100fb-1
48
Single photon signal at LHC
  • Potential confirmation of discovery
  • Main background
  • Other backgrounds from W small, not simulated.
  • Require Etggt60 GeV and hlt2.5 for trigger
  • Signal in region Etggt500 GeV
  • Calibrate background with gZ-gt ee sample
  • pTegt20 GeV, invariant mass within 10 GeV of Z
  • Sample is 6x smaller than sample, use S/sqr(6B)

49
Significance of single photon signal
Background
Signal
Only useful if n and MD small
50
Extracting n and MD
Cannot separate n and MD at fixed energy Run LHC
at 10 TeV as well as 14 TeV MD limited
kinematically by pdfs -gt can separate n and MD
with precise cross section measurement
51
Variation with ECM at LHC
  • Cross section ratio
  • (10 TeV/14TeV)
  • Need to measure to 5 to distinguish n2,3
  • Need O(10) more L at 10 TeV
  • Need luminosity to lt5

52
Virtual graviton processes at LHC
  • s-channel graviton exchange contributes to
  • Potential information from angular distribution
    differences and interference between SM
    background and graviton exchange
  • ATL-PHYS-2001-012

53
Diphoton production at LHC
  • SM background peaks at high h
  • Signal events central

54
Diphoton signals at LHC
  • gg invariant mass distributions
  • (log scale)
  • Signal can be optimised with cut on MgggtMmin

55
Diphoton reach at LHC
Cut value
  • 5s reach for diphoton signal for
  • 10 fb-1 and 100 fb-1
  • Can optimise reach at any n with cut on Mmin

56
Dilepton signals at LHC
  • Invariant mass of ll- pair
  • (log scale)

57
Forward-backward asymmetry in dileptons
  • Interference between G and SM modifies predicted
    FB asymmetry
  • 100fb-1

58
Dilepton reach at LHC
  • 5s reach for diphoton signal for
  • 10 fb-1 and 100 fb-1
  • Can optimise reach at any n with cut on Mmin

59
Limits from the Tevatron
  • Searches performed by D0 and CDF
  • D0 Run I data taken without B field
  • -gt use EM clusters only
  • Fake background from miss id jets
  • No evidence for excess events
  • hep-ex/0108015

60
D0 data
  • Compare data and MC in
  • Mass/cosq plane
  • Data compatible with expected backgrounds from SM
    and miss ID jets
  • hep-ex/0103009

61
D0 LED Signature
  • Dedicated MC generator includes SM, ED and
    interference terms.
  • Signal appears at large M, low cosq
  • MDgt1.44 TeV for n3
  • MDgt0.97 TeV for n7
  • Run II will extend reach to
  • 3-4 TeV
  • Luminosity? 2? 10? 30 fb-1

62
Single photons at the NLC
  • Finding signal is one thing
  • interpreting it is another
  • Single photonETMiss signal at NLC
  • SM background from

n2,4,6
63
Single photon angular distribution at NLC
  • Assume
  • 500 GeV LC
  • Pol(e-)80
  • Pol(e)60
  • Cross-section measured to 1 precision
  • (gt270fb-1 required)
  • Distinguish n2 from n3 up to MD4.6 TeV
  • Gravitino production is indistinguishable from
    n6!

64
Warped 5-d spacetime
Higgs vev suppressed by Warp Factor
Gravity
Planck scale brane
Our brane
5th space dimension r
65
Warped Extra dimensions
  • Consider Randall and Sundrum type models as test
    case
  • Gravity propagates in a 5-D non-factorizable
    geometry
  • Hierarchy between MPlanck and MWeak generated by
    warp factor
  • Need no fine tuning
  • Gravitons have KK excitations with scale
  • This gives a spectrum of graviton excitations
    which can be detected as resonances at colliders.
  • First excitation is at
  • where
  • Analysis is model independent this model used
    for illustration

66
Implementation in Herwig
  • Model implemented in Herwig to calculate general
    spin-2 resonance cross sections and decays.
  • Can handle fermion and boson final states,
    including the effect of finite W and Z masses.
  • Interfaced to the ATLAS simulation (ATLFAST) to
    use realistic model of LHC events and detector
    resolutions.
  • Coupling
  • Worst case when giving smallest couplings.
  • For m1500 GeV, Lp13 TeV
  • Other choices give larger cross-sections and
    widths

67
Angular distributions
  • Angular distributions expected of decay products
    in CM are
  • qq -gt G -gt ff
  • gg -gt G -gt ff
  • qq -gt G -gt BB
  • gg -gt G -gt BB
  • This gives potential to discriminate from
    Drell-Yan background with

68
Angular distributions of ee- in graviton frame
  • Angular distributions are very different
    depending on the spin of the resonance and the
    production mechanism.
  • gtget information on the spin and couplings of
    the resonance

69
ATLAS Detector Effects
Best channel G-gtee- Good energy and angular
resolution Jets good rate, poor energy/angle
resolution, large background Muons worse mass
resolution at high mass Z/W rate and
reconstruction problems. Main background
Drell-Yan Acceptance for leptons hlt2.5
Tracking and identification efficiency included
Energy resolution Mass
resolution
70
Graviton Resonance
  • Graviton resonance is very prominent above small
    SM background, for 100fb-1 of integrated
    luminosity
  • Plot shows signal for a 1.5 TeV resonance, in the
    test model.
  • The Drell-Yan background can be measured and
    subtracted from the sidebands.
  • Detector acceptance and efficiency included.

71
  • Signal and background for increasing graviton mass

1000 GeV
500 GeV
1.5 TeV
2.0 TeV
72
Events expected from Graviton resonance
Signal
Background
100fb-1
Limit
Mass window is 3x the mass resolution
73
Production Cross Section
10 events produced for 100fb-1 at mG2.2 TeV.
With detector acceptance and efficiency, search
limit is at 2080 GeV, for a signal of 10 events
and S/vBgt5
10 events
74
  • Angular distribution changes with graviton mass
  • Production more from qq because of PDFs as
    graviton mass rises

75
Angular distribution observed in ATLAS
  • 1.5 TeV resonance mass
  • Production dominantly from gluon fusion
  • Statistics for 100fb-1 of integrated luminosity
    (1 year at high luminosity)
  • Acceptance removes events at high cos q

76
Determination of the spin of the resonance
  • With data, the spin can be determined from a fit
    to the angular distribution, including background
    and a mix of qq and gg production mechanisms.
  • Establish how much data is needed for such a fit
    to give a significant determination of the spin
  • 1. Generate NDY background events (with
    statistical fluctuations)
  • 2. Add NS signal events
  • 3. Take likelihood ratio for a spin-1 prediction
    and a spin-2 prediction from the test model
  • 4. Increase NS until the 90 confidence level is
    reached.
  • 5. Repeat 1-4 many times, to get the average
    NSMIN needed for spin-2 to be favoured over
    spin-1 at 90 confidence
  • 6. Repeat 1-5 for 95 and 99 confidence levels

One ATLAS run
77
Angular distribution observed in ATLAS
  • Model independent minimum cross sections needed
    to distinguish spin-2 from spin-1 at 90,95 and
    99 confidence.
  • Assumes 100fb-1 of integrated luminosity
  • For test model case, can establish spin-2 nature
    of resonance at 90 confidence up to 1720 GeV
    resonance mass

78
Graviton discovery contours
  • Confidence limits in plane of Lp vs graviton mass
  • Coupling 1/ Lp
  • Test model has k/MPl0.01, giving small coupling.
  • For large k/MPl coupling is large enough for
    width to be measured.
  • (Analysis assumes widthltltresolution)

79
Muon analysis
  • Muon mass resolution much worse than electron at
    high mass ?
  • Discovery reach in muon channel for MGlt1700 GeV
  • Muons may be useful to establish universality of
    graviton coupling

80
Measurement of the graviton coupling to mm-
  • Confidence limits in plane of Lp vs graviton mass
  • Coupling 1/ Lp
  • Test model has k/MPl0.01, giving small coupling.
  • For large k/MPl coupling is large enough for
    width to be measured.
  • (Analysis assumes widthltltresolution)

Ds.B/s.B
81
Photon analysis
  • Photon pair mass resolution as good as electrons
  • But background uncertain. For standard model
    (ptmin150 GeV)
  • sHERWIG0.36 pb
  • Included
  • Not included
  • for example
  • FNAL data indicates sHERWIG is 5x too small ? use
    1.8 pb
  • Do not trust cosq distribution for background.

Graviton mass (GeV)
82
Measurement of the graviton coupling to gg
  • Confidence limits in plane of Lp vs graviton mass
  • Coupling 1/ Lp
  • Test model has k/MPl0.01, giving small coupling.
  • For large k/MPl coupling is large enough for
    width to be measured.
  • (Analysis assumes widthltltresolution)

83
Graviton to jet-jet backgrounds
  • k/MPl 0.08
  • (64x higher cross-section)

84
Graviton to jet-jet signal at 1.9 TeV
  • Significant signal after background subtraction
  • k/MPl 0.08
  • (64x higher cross-section)

85
Graviton to jet-jet search reach
  • Reach is limited because of high background

86
Graviton to WW
  • Look for
  • Select 1e, 0 m, 2 jets, PTmiss from ATLFAST
  • hjet lt2
  • Require Mjj compatible with W mass
  • take highest pT pair in mass window
  • Solve for pzn using W mass constraint
  • Plot MWW look for resonance above SM background
  • SM background from WW, WZ and ttbar

87
Graviton to WW signal and background
  • WW channel is viable for graviton

88
Graviton to WW channel
Efficiency drops at very high jet ET
  • Reach of Wjets channel - low cuts

89
Exploring the extra dimension
  • Check that the coupling of the resonance is
    universal measure rate in as many channels as
    possible mm,gg,jj,bb,tt,WW,ZZ
  • Use information from angular distribution to
    separate gg and qq couplings
  • Estimate model parameters k and rc from resonance
    mass and s.B
  • For example, in test model with MG1.5 TeV, get
    mass to 1 GeV
  • and s.B to 14 from ee channel alone (dominated
    by statistics).
  • Then measure

90
Black hole production
  • Low scale gravity in extra dimensions allows
    black hole production at colliders.
  • Decay by Hawking radiation (without eating the
    planet)
  • 8 TeV mass black hole decaying to leptons and
    jets in ATLAS
  • 8 partons produced with
  • pTgt500 GeV
  • Work in progress Richardson, Harris

91
Black hole production cross-sections at LHC
10000 evs/yr
  • Classical approximation to cross-section
  • (Controversial)
  • Very large rates for n2-6 hep-ph/0111230

92
Black hole decay
  • Decay occurs by Hawking radiation
  • Hawking Temperature TH
  • Black Hole radius rh
  • Use observed final state energy spectrum to
    measure TH and hence n?

93
Particle spectra from black hole decays
  • Example
  • n6 extra dimensions
  • MD 2 TeV
  • Mh 7-7.5 TeV
  • Hawking Temperature TH 400 GeV
  • Multiplicity N Mh/2 TH 9
  • Electron spectrum deviates from Black body
  • effect of isolation cut?
  • recoil effect?
  • Fit gives 388 GeV

All jets
Isolated es
Black body
Fit
94
Extracting n from Black Holes
Preliminary!
  • Fit TH against Black Hole mass
  • No experimental resolution yet (500 GeV bins)
  • Effect of heating?
  • Input n6
  • Fit gives
  • n5.7-0.2

95
Black hole production at the Tevatron
pb
105
  • Rate expected to be large at Tevatron
  • n4 extra dimensions
  • Cross-section drops rapidly at high mass
  • Assume 10fb-1
  • Non-observation implies MDgt1.4 TeV
  • hep-ph/0112186

Events/yr
102
100
s
10-2
10-5
1.0
1.3
1.6
0.7
MD
96
Conclusions
  • Extra dimensional theories provide an exciting
    alternative to the normal picture of physics
    beyond the standard model
  • A wide variety of new phenomena are predicted
    within reach of experiments.
  • Time to bet on the lottery!
Write a Comment
User Comments (0)
About PowerShow.com
