Faster Suffix Tree Construction With Missing Suffix Links

1
Faster Suffix Tree Construction With Missing
Suffix Links

• By Richard Cole and Ramesh Hariharn
• Present by B89502027??? ???
• B89705013??? ???

2
What is Missing Suffix Link

• The definition of suffix link implies str(
  link(x) ) is str(x) with 1st symbol removed
• Where link(x) must be a NODE.
• When link(x) is not a node. The suffix link is
  missing!
• 2 situations
• Parameterized string
• Suffix tree for 2-Dimension array

3
The problem is

• Parameterized strings and 2D array
• The node degree may not be bound by constant,
  i.e., some polynomial of n
• Farach 5 solved polynomial but not missing
  suffix link
• Baker1, Kosaraju11 solved parameterized
  string but not polynomial (n logn)
• Giancarlo7 solved 2D array but still in (n
  logn)
• We can solve both with O(n)!!!

4
Our contribution tools

• Putting additional nodes and suffix links to the
  suffix tree but still in space O(n) and time O(n)
• Providing a failure probability of inverse
  exponential, i.e., hashing
  scheme.

5
General Settings

• Quasi-suffix collection
• An ordered collection of strings s1, s2, sn iff
  the following hold
• s1 n, and si si-1 -1, therefore sn1
• No si is a prefix of another sj
• Suppose si and sj have common prefix of length L
  gt0, then si1 and sj1 have a common prefix of
  length at least L 1.
• aabb
• abb
• bb
• b

6
General Settings(contd)

• Multiple quasi-suffix collection
• Several quasi-suffix collections have L strings
  in all
• Any pairs of strings si, sj hold conditions 2 3
  of quasi-suffix collection
• Character Oracle
• Supply the ith character of the jth string of the
  collection on demand in O(1) time

7
Suffix trees for parameterized strings

• Each s of string s is transformed to num(s),
  e.g., ?b?b? gt 0b2b2
• How is condition 1 hold?
• How is condition 2 hold?
• How is condition 3 hold?
• 0bb3b2
• bb0b2
• b0b2
• 0b2
• b0
• 0

8
Suffix trees for 2D arrays

• There are mn-1 diagonals in m x n array
• For each diagonal form a square array
• For each square array, decomposing in a
  shapes,
• Each is mapped to a number (Giancarlo7),
  and a square is a string num(s), forming
  quasi-suffix collection (each with different
  ending symbol)
• since mn-1 diagonals, mn-1 square for a
  multiple quasi-suffix collection

9
First! McCreights Algorithm

• Definition of suffix link
• Since condition 3 must satisfied with equality,
  suffix link is defined for each node x and
  link(x) is defined to be a node.
• Two stages rescanning and, possibly, scanning
• Rescan down from link( par(x) ) until position
  for link(x) found
• If node not present, insert one and an edge for
  the leaf (no scan)
• Otherwise, just scan down (as we did in ukkonen)
• In either case, link(x) is well defined!

10
Two problems

• Link( par(x) ) may not be defined
• The lack of node at link(x)!
• Since condition 3 need not satisfied only with
  equality, i.e., in our parameterized string case!

11
Our Algorithm

• Two modifications to McCreights
• Traversing up to find an ancestor with suffix
  link
• Copy nodes backwards from the destination found
  above
• Re-definition of suffix link
• link(x) is node y such that if str(x) is the
  longest common prefix of si and sj, then str(y)
  must be the longest common prefix of si1 and
  sj1, where str(y) str(x) -1.
• link(x) need not be defined for every node x!

12
Some definition

• nanc(x), nearest ancestor of x with suffix link
• Real/imaginary node
• If new scanning stage begin within an edge,
  (condition 3 with gt property) we use an imaginary
  node.
• Imaginary node has only 1 child, whereas real
  node has at least 2!
• At most O(n) real nodes and imaginary nodes
  (since leaves at most n)

13
Some facts

• Number of real and imaginary node is O(n)
• Total number of children of real and imaginary
  nodes are O(n)
• Total length of scanned portion is O(n)

14
More features

• Back propagation nodes
• Must have suffix link
• Only one child
• When scanning down from link(nanc(x)) to link(x),
  every 2 node (not including the first and the
  last) are back-propagated.

15
Invariant 1

• If a node x is back-propagated in direction u,
  then its parent is not back-propagated in
  direction u where u is a prefix of u.

16
Time Complexity

• Two to be analyze
• Finding nanc(x)
• Rescanning down
• Creating a new back-propagated node
• Upgrade imaginary node to back-propagated node,
  by adding suffix link to it!
• Adding a real/imaginary node for link(x)
• Time O(1) 1 2

17
Bounding back-Propagated node

• Defining BP tree
• All node except root are back-propagated node
• BP forest
• Trees rooted at various real/imaginary nodes that
  are back-propagated. (Imagine the suffix tree as
  BP forest!)
• Decomposing BP tree into paths
• From root down to a node y such that either
• 1. no valid direction for y
• 2. there exist a direction u but in which y has
  not been back propagated!
• Decomposing recursively

18
Bounding back-Propagated node (contd)

• Extend paths on suffix tree backward (on
  direction not imply by back-propagation node)
  until either
• 1. a node is reached
• 2. no valid direction is available
• Lemma 1 two distinct extended path cannt
  intersect.
• Lemma 2 if an extended path terminated at node y
  (not by running out of valid direction), y cannot
  be back-propagated node.
• Lemma 3 total number of path is O(n), and hence
  total number of pack-propagated node is O(n)

19
Time Complexity (contd)

• The process of finding nanc(x) is just the same
  way discussed in Ukkonen bounded by O(n)
• Combining with lemma 3, we have the theorem

20
The Hashing Scheme

• Goal
• Hash O(n) pairs node, following symbol
• ????? O(n), ????? O(1) query
• ??? inverse exponential

21
FKS Perfect Hashing

• Fredman, Komlos, Szemeredi
• Refer to textbook for Algorithm
• Hash n items from range 0poly(n) into 0T(n)
• Ensure probability without collision gt ½

22
The Static Hashing Scheme

• Choose positive constante
• When e?0, failure probability ?
• Total time space of DS will be linear with
  factor 1/e
• ??????1 nc ?n?items hash??? imaginary array A
  of size nc

23
The Static Hashing Scheme(contd)

• Step 1 (??partition tree)
• of node O(n)
• Has ne children
• Each children associate with a distinct subarray
  of A of size nc-e
• Each leaf (subarray) with more than neitems is
  recursively partitioned
• Total size O(n)

24
The Static Hashing Scheme(contd)

• Step 2
• Using FKS Perfect Hashing
• Several trials will be required since only ½
• ??total time complexity
• Total size of sub problem is n
• Each sub problem is ne

25
The Static Hashing Scheme(contd)

• Size categories
• Divide leaves into O(logn) categories
• For a categories i , the leaves size are in the
  range ne/(4i1) ne/(4i) for igt0
• We will show that
• time for this category is proportional to the sum
  of size of the leaves in this category O(n/2i)
• With failure probability
• It follows that total time O(n) with failure
  probability

26
The Static Hashing Scheme(contd)

• Succeed
• Items in a leaf are perfect hashed
• Round
• One trials for each of the relevant leaves
• Group
• Organization of rounds

27
The Static Hashing Scheme(contd)

• How to grouping rounds?
• 0th Group ???category???unsuccessful
  leaves??n1-e2i / (log n)????rounds
• jth Group???category???unsuccessful
  leaves?n1-e2i / (2j log n)?n1-e2i / (2j-1 log
  n)?????rounds (j gt 1)

28
The Static Hashing Scheme(contd)

• We will show failure probability of rounds in
  group
• 0th of rounds O( i log log n) with failure
  probability
• jth of rounds O( 2j ) with failure probability
• Failure probability (over all groups)
• First of all, we show that total time taken in j
  groups

29
The Static Hashing Scheme(contd)

• Secondary we show rounds in 0th group
• Leaves in ith category are at most n / (ne/4i1)
• n / (ne/4i1) (1/2)x n1-e2i / log n
• gt x 2 i log log n (the rounds in 0th
  group)
• In Chernoff bound 2, If u unsuccessful
  leaves, at some instance of time, then half these
  leaves succeed in the next 2k rounds, with
  failure probability 1/(2T(uk) )
• Failure probability at end of 0th group is thus
  (k1)

30
The Static Hashing Scheme(contd)

• we show rounds in jth group
• K 2j
• Has 22j rounds
• u n1-e2i / (2j log n)
• With failure probability
• Totally O(log n) groups, thus total failure
  probability
