An Oxygenated Presentation Manager

1
An Oxygenated Presentation Manager

• Larry Rudolph
• Oxygen Workshop, January, 2002

2
Goals Overview

• Integrate Many Oxygen Technologies
• Application Driven
• Use an application that we understand
• Personally use often
• Would help if were more human-centric
• Develop Architectural Infrastructure
• Exposes new requirements
• Identify some important, basic issues
• Infrastructure
• Critique of Presentation Manager
• What is wrong with it

3
Application Scenario
4
An Oxygen Application

• Components
• Input
• Vision
• Speech
• Touch
• Processing
• Changing configuration
• Output
• Projector
• Handheld
• Archive

5
Camera watching laser point on screen

• Camera Challenges
• Inexpensive ones have wrong focal length
• Alignment issues use edge of screen, display
  pattern, figure out from what is known to be
  visible
• We ended up displaying a pattern of concentric
  circles
• Relative size of laser point depends on distance
• Beyond ten feet, had to use only certain types of
  lasers
• Could slow-down camera and let pixels saturate
  (too complicated)
• Camera Interface
• Click at point (x,y)
• Hold laser at same location for 5 seconds
• Select horizontal line ( (x1,y1) , (x1,y2) )
• Sweep laser back and forth, line is diameter of
  ellipse
• Select object centered at point (x,y)
• Sweep laser in circle, point is center of circle
• Previous or Next
• Click in left (right) 1/8 of screen

6
Microphone listening to speaker

• Microphone
• Many technologies Current approach ipaq
• Push to speak
• Audio server on ipaq
• Detects start and stop
• Best results when human pushes to start and
  releases to stop
• Audio wave file sent to Galaxy speech system
• Galaxy output (HTTP Post cmd) to CGI-script
  Server
• Action are
• Powerpoint
• Next slide, Previous slide, Goto slide n, Goto
  slide named ltxxxgt
• Next item, Previous item, Goto item n, Goto item
  named ltxxxgt
• Next animations, previous animation, goto
  animation n
• Presentation
• Start presentation ltnamegt, End presentation,
  Pause presentation
• Session
• Initialize Camera, test microphone

7
Speaker controlling presentation via ipaq

• Ipaq output (HTTP Post cmd) to CGI-script Server
• Same actions as from speech server
• Action are
• Powerpoint
• Next slide, Previous slide, Goto slide n, Goto
  slide named ltxxxgt
• Next item, Previous item, Goto item n, Goto item
  named ltxxxgt
• Next animations, previous animation, goto
  animation n
• Presentation
• Start presentation ltnamegt, End presentation,
  Pause presentation
• Session
• Initialize Camera, test microphone
• Handheld (Ipaq) display
• GUI generated from speechbuilder grammar
• List of slides, items per slides
• Currently use ad-hoc solution where power-point
  sends lists to ipaq. Need more automatic
  solution

8
Processing controlling session

• Easy to embed movies into presentation
• Add rule that is invoked on slide n
• Switch output producer from powerpoint to media
  player
• Remove interrupting technologies
• Dynamically disconnect any input / output source
• All done via core language

9
Output to projector, handheld, archive

• Unlimited number of video / audio output
  producers
• E.g. powerpoint just one producer of output
• At any time, each output device has an associated
  producer
• This producer can receive input from several
  producers
• Handheld has proxy
• To reduce bandwidth to ipaq
• Current slide, list of slides, list of commands
• Archive
• Each slide shown, audio (from a different
  microphone) sent to archive
• Currently just gif of current slide

10
CORE Communication Oriented Routing Environment

• Part of ORG (Oxygen Research Group)
• Assumptions
• Actuators / Sensors (I/O) in the environment
• Many are shared by apps users
• Many are flaky / faulty
• User does not know much about them
• Environment, application, users desires change
  over time

11
An Oxygen Application

• Interconnected Collection of Stuff
• Who specifies the stuff?
• I dont know, but its mostly virtual stuff
• Many layers of abstraction
• Dont ask, its turtles all the way down
• Two main layers of programming
• Professionals
• Users, e.g. grandmother

12
Communications-Oriented Programs

• Connecting the (virtual) stuff done by user
• Home stereo / theater analogy
• Plug Stuff together unplug it if doesnt work
• Dont like it, unplug it
• Device drivers, services, clients, dont know to
  whom or to what they connect
• In client/server model,
• server knows a lot about the client,
• the client knows even more about the server
• Extend Unix Pipes

13
CORE
Other COREs
Larry Bear
14
Message Flow

• Messages flow between nodes core
• Core is both language and router
• Within Core Router, some messages
• are interpreted and may trigger actions
• other messages get routed to other nodes
• Request-Reply message strategy
• Even number of messages
• No reply within time period, means error

15
CORE Language Elements

• Four elements
• Nodes,
• Links,
• Messages,
• Rules
• Features
• Interpreted Language
• Statement is a message reply
• Each element has an inverse

16
Nodehandler (nickname, specifier)
Nodes Specify via INS
Cam deviceweb-cam location518
PTRvision deviceprocess OSLinuxFileLaser
Vision, ..
CORE
Laser Vision
17
Node Statement Handler

• When node message arrives
• Verified for correctness (statements allowed)
• Routed to Node Manager (just another node)
• Node Manager
• INS lookup, verifies if allowed, creates if
  needed
• Creates core thread to manage communication with
  node
• Bookkeeping reply message with handle/error

18
Links
Lcamera,vision (Cam,PTRvision)
Slide Speech
Presentation Speech
Command Speech
CORE
Laser Vision
19
Link Statement Handler

• Message routed to link manager
• Two queries to node mng for thread cntl
• Message to thread controller of source node
• Specifying destination thread controller
• Message to thread controller of dest node
• Specifying source thread controller
• Bookkeeping reply message handler/error

20
Messages
Messages flow over the links
Next Slide!
Slide Speech
Presentation Speech
Command Speech
CORE
Laser Vision
21
Message Handling

• Messages can be encrypted
• Core statement messages have fixed format
• Everything else is data message
• Each node thread has two unbounded buffers
• Core to node Node to core
• Logging, rollback, fault-tolerance

22
Rules
RULES (trigger,action)
( MESSQuestion , Lslide,lcd -- Lslide,qlcd )
Slide Speech
Presentation Speech
Questions
Command Speech
CORE
Questions
Questions
Laser Vision
23
Rule Statement Handler

• ( trigger , consequence )
• Both are event sets
• Eight basic events
• Node, -Node, Link, -Link
• Message, -Message, Rule, -Rule
• Event set is a set of events
• Trigger is true when events are true
• Consequence makes events true

24
Rules A link is a rule

• A message event is of form
• (node, message specifier)
• ( message specifier , node )
• Message came from or going to node
• A link (x,y) is just shorthand for the rule
• ( x , m ) ? ( - (x, m) , (m , y) )
• If a message m arrives at node x, then make that
  event false (remove the message) and make the
  event of m arriving at y from core true.

25
Rules Access Control Lists

• An access control list is just a rule
• When messages arrive at node, if they arrive from
  valid node, then allowed to continue to flow.
• Modifying access control lists is just adding or
  removing rules.

26
Rules

• Rule statement gets sent to rule manager
• Event set is just another shorthand for rules
• Rule manager sends command to trigger node thread
  that tells it about the consequence
• Rules are reversible

27
Reversibility

• Each statement is invertible (reversible)
• If there is an error in the application
  specification, then can undo it all.
• General debugging is possible with reversible
  rules and message flow

28
Critique of Presentation Manager
29
Vision / Gesture Recognition

• Laser Pointer
• Great for drawing attention to content
• Audience is primary consumer
• Secondary use to control presentation
• But it is not a mouse
• Semantics are tied to slide context
• Differs from Intelligent-room use
• Small number of identified gestures
• Gestures easily punctuated
• Low computational overhead
• Soon will be handled with a H21

30
Critique of Vision / Gesture Recognition

• Laser Pointer
• Great for drawing attention to content
• Cheap technology but mostly distracting
• Too shaky, imprecise
• But it is not a mouse
• More awkward to use than mouse
• Another gadget to hold in the hand, button to
  identify, batteries to maintain
• Small number of identified gestures
• There are better ways of drawing attention to
  slide content
• I rarely use it and dont like it when others do
• Low computational overhead
• Dumb vs Intelligent Device Discussion

31
Speech Recognition

• Initially seems like great idea
• Speaker is already speaking, so can use it to
  control presentation
• Want passive, intelligent listener
• Not a dialog
• No prompt alienating distraction
• Want no mistakes
• For dialog, better to guess than ignore
• For us, high cost for incorrect guess
• Most words are not relevant to speech system
• More trouble than it is worth
• But may be good for real-time search of content

32
More useful aspect Output modalities

• Presenter has put the time and effort into the
  production
• Simplier is better
• Audience has harder task
• Understand material being presented
• Record thoughts, impressions, connections
• Filter for later review
• Process in real-time
• Keep-up with presentation
• Do all this with minimal distractions
• Output modalities
• Content for live audience
• Content for speaker (superset of audience)
• Content for retrieval
• Correlate notes with content

33
Record and correlate notes with presentation
