Tatum Tapered Implant Placement Instructions

1
Tatum Tapered Implant Placement Instructions
2
When acceptable attached Gingiva is present, use
an appropriate tissue punch at implant site.
3
Start osteotomy with pointed pilot drill
(1.5mm) to proper depth using irrigation.
4
Enlarge osteotomy with second pilot drill
(2.0mm) to proper depth using irrigation.
5
Finish osteotomy with tapered drill to proper
depth using irrigation. Laser mark indicates
crest of bone location.
6
Using your handpiece and HT.09 driver, place
implant into osteotomy slightly above desired
depth at low RPM.
7
Using your Tatum Ratchet and either the HT.06 or
HT.07 extension , finish placing the implant to
the desired depth leaving the neck of the implant
slightly above the tissue.
8
Example of implant placed at desired depth.
9
Determine proper abutment angulation using
color-coded post guides.
10
Using HT.10, HT.11, or HT.04 place the Healing
Screw into the Implant Body by turning it
Counter-Clockwise .
