PowerLogic revenue metering for utilities

1
PowerLogic revenue metering for utilities

• Take charge of grid metering
• quickly and accurately

2
PowerLogic revenue metering

• Schneider Electric helps you exceed the
  traditional boundaries of energy information
  management.
• Our energy monitoring and control systems are
  designed to unite your entire enterprise, from
  end-to-end.
• All systems work together to help reveal new
  energy opportunities.

3
Grid metering a serious business

• PowerLogic metering systems help
• Meet high-accuracy metering needs at key
  interchange points
• Improve metering accuracy at existing inter- or
  intra-ties
• Reduce communication costs
• Streamline billing and administration
• Customise templates and metering algorithms

4
Key metering solutions

• Utilities must measure and manage all aspects of
  their commodity and control its affect on
  customers, operations and profits.
• PowerLogic offers
• Seamless data sharing between high-accuracy
  meters and automated billing systems
• Wholesale energy transaction management across
  wide-geographic areas
• Real-time pricing, posted rates, and available
  capacity accommodation
• Simple, easy allocation of energy costs

5
Metering flexibility

• PowerLogic metering systems offer
• Open protocols
• Advanced communication options
• Gateways
• Customised solutions
• Integration into existing infrastructure
• Accommodation of third-party equipment

6
Metering system communications

• PowerLogic technology offers
• Local mastering
• Gateway functionality
• Browser-based accessibility
• Email data transfers
• Ethernet support of metering, SCADA, and PQ
  protocols

7
From billing to operations

• PowerLogic supports precise billing transactions
  across the grid, using meters that exceed the
  worlds most stringent accuracy standards.
• We offer individual and packaged features
  designed to enhance billing systems and guarantee
  full accountability.
• Energy usage
• Automated alarming control
• Communication ports I/O
• Power quality IEC 61000 4-30 Class A confidence
• Data management
• Automated reporting

8
Intelligent communications

• PowerLogic metering systems can drastically
  reduce communication costs while increasing the
  number of monitored points and improving network
  awareness.
• These communication links provide
• Billing data
• Operational data to SCADA systems
• Regulatory-compliant power quality information
• A single device can meet the needs of multiple
  departments.

9
Key measurements

• PowerLogic meters register
• Time-of-Use (TOU)
• Active, reactive and apparent energy
• Energy consumption at different tariff rates
• Remote communications options (fixed network or
  wireless)
• Automated Meter Reading (AMR) Local mastering

10
Customised viewing

• Managers can easily design their own data
  presentment
• Load profiles
• Power quality information or alarms
• Pager alerts
• Emailed reports
• Web-accessible graphical views
• Other utility departments may view intelligent
  meter information
• via secure web server on the device, so
  authorised personnel
• can access critical data in real-time from any
  computer,
• anywhere in the world.

11
End to end accuracy

• Typical metering system

12
Certifications and approvals

• International
• CFE (LAPEM, Mexico)
• CAM (Chile)
• Inmetro (Brazil)
• INTI (Argentina)
• CIDET (Colombia)
• SENCAMER (Venezuela)
• KEMA Labs (Netherlands)
• KERI Labs (Korea)
• EPRI (China)

MARIA (New Zealand) OFGEM (UK) GOST (Russia)
IESO (Ontario) Measurement Canada Hydro Quebec
(Canada) California ISO (USA) ERCOT (Texas ISO)
MET Labs (Independent Lab) NY State PUC
(USA) PJM (USA)
13
Meet the meters and real-time software

• Recommended products
• Software
• PowerLogic ION Enterprise
• PowerLogic ION Setup
• Power and energy meters
• PowerLogic ION8800
• PowerLogic ION8600
• PowerLogic ION7650
• PowerLogic ION7550
• PowerLogic ION7350
• PowerLogic ION7330

• PowerLogic systems support
• Power quality
• Operations management
• Billing
• Distributed generation
• Value-added services
• Load curtailment
• and more...

14
For further information on PowerLogic revenue
metering systems for utilities...

• Please visit www.powerlogic.com
