Evaluation in Medical Informatics

1
Evaluation in Medical Informatics

• Kevin Johnson, MD, MSVanderbilt University
• Joan Ash, PhD, MLS, MBAOregon Health Science
  University

2
What Questions Would You Like Addressed?
3
Case Report

• 1999 Development of a tool that used speech
  recognition technology to complete an endoscopy
  summary
• 2001 Deployment of this tool in the endoscopy
  suite
• 2003 Developer of the tool, though not needed
  to maintain it, leaves.
• 2004 Tool removed from endoscopy
• 2005 New tool evaluated. You are asked to
  support the purchasing of this tool.

4
Questions

• What do you think happened the first time around?
• What could have been done to prevent this
  outcome?
• What were the issues you would want to resolve
  before purchasing?

5
Issues

• What happened?
• Lack of support
• Poor hardware, software, networking
• Lack of training
• Changing expectations
• Natural history of adopting this technology
• ???

6
Issues (2)

• How to prevent this?
• Recruit new physician champion
• Force use of system
• Recognize foolishness of implementing system in
  the first place
• Could not prevent this without more information!

7
Issues(3)

• Before purchasing
• commitment from users
• commitment from vendor
• costs
• benefits
• in short,

8
Evaluation

• Evaluation is the systematic application of
  social research procedures to judge and improve
  the way information resources are designed and
  implemented.
• Step back and assess value
• rigorous methods, stick to a plan, reduce bias,
  hire an evaluator
• value broadly defined

9
Why We Evaluate
10
Why evaluate information technology?
speech recognition technology
Outcomes research databases
Scanner systems
Personal digital assistants
Decision aids

• Nowadays people know the price of everything
• and the value of nothing.
• Oscar Wilde

The Internet
Computer-based patient records
Expert systems
Physician order-entry
11
Current Issues in IT System Evaluation

• Lack of measurement tools (Friedman and Abbas,
  2003)
• Studies are technical and descriptive (What I did
  last summer) and ignore users/organizations/outcom
  es (Darbyshire, 2004)

Evaluation involves more factors than just
involving technologies such as changing
attitudes, cultures and healthcare practices.
Realistic evaluation could provide configurations
of context-mechanism-outcomes that explain the
underlying relationships to understand why and
how a program or intervention works.
(Oroviogioicoechea, C Jnl Clin Nurs, 2007)
12
Your Expertise is Required!

• You are implementing a PDA-based tool to help
  with deciding what medication to prescribe,
  creating the prescription, and routing it to a
  pharmacy This tool would be integrated with the
  electronic health record. Your institution is
  willing to fund this project for 5 years, and you
  get additional funding to evaluate it over that
  period. Your results will impact whether the
  institution supports this for the long term.
  Note that your institution understands the
  importance of patient safety to their overall
  bottom line.

13
Assignments (5 minutes)

• Row 1 - given 1 month before the tool is built,
  what might you evaluate and how?
• Row 2 - Now that you've seen the tool, there is
  a decision to pilot it for a month with highly
  motivated users. What might you evaluate and how?
• Row 3 - The pilot is over and was successful.
  There were a few pilot users who wished there was
  more training, but by the end they were all good
  at using it. What might you do to help the next
  phase?
• Row 4 - The tool is about to roll out. What would
  you like to evaluate in the next 2 years, and
  how?

14
See you in 10 minutes
15
Results

• Row 1 - given 1 month before the tool is built,
  what might you evaluate and how?
• Row 2 - Now that you've seen the tool, there is
  a decision to pilot it for a month with highly
  motivated users. What might you evaluate and how?
• Row 3 - The pilot is over and was successful.
  There were a few pilot users who wished there was
  more training, but by the end they were all good
  at using it. What might you do to help the next
  phase?
• Row 4 - The tool is about to roll out. What would
  you like to evaluate in the next 2 years, and
  how?

16
Typical Questions

• Does it work with what effect
• Assign a value sell it, decide to buy it
• How to make it better
• Formative vs. summative
• Where does it work best
• What problems does it cause
• Uncover basic principles of medical informatics

17
What can be studied?
Need for resource
Development process
Resource development
Plans for change
Feedback
Deployment
Stabilization in workplace
18
Stead Evaluation Framework
Stead, JAMIA 1994
19
Small Ball!
Results Smallball evaluations have several
important advantages over powerball evaluations
before system development, they ensure that
information resources address real community
needs during deployment, they ensure that the
systems are suited to the capabilities of the
users and to community constraints and, after
deployment, they enable as much as possible to be
learned about the effects of the intervention in
environments where randomized studies are usually
impossible.
20
Why study IT resources?

• Promotional studies demonstrate safety,
  efficacy, benefits
• Scholarly studies increase understanding of
  structure, function, and effects of IT resources
• Pragmatic studies learn what works and what
  doesnt work
• Ethical studies Assure that IT resources are
  safe, cost-justified
• Medicolegal studies Reduce risk of liability

21
Promotional Rationalization

• Safety
• Benefit (and to whom)
• cost-effective
• reengineering impact

22
Scholarly Rationalization

• Potential of technology
• Need for further research
• Uncovering the principles of Medical Informatics

23
Pragmatic Rationalization

• enabling comparisons
• enabling decisions
• defining mistakes

24
A Pragmatic ToolThe Request for Proposals

• Specifies a (business) need and a rationale for
  that need
• Specifies the criteria by which a solution to the
  need will be chosen
• May be sent to all potential solutions
  providers who can choose to reply if they feel
  that their product is aligned with the needs of
  the requestor

The Response is a tool for EVALUATING SOLUTIONS
25
RFP Components

• Detailed requests for information (hardware,
  software specifications, people, process, other)
• specify minimum and mandatory information needed
• specify where additional information may be
  provided

• Introduction and Background
• Invitation to submit proposal and ground rules
• Timeline
• Evaluation methodology

26
Ethical Rationalization

• REALLY understanding safety
• REALLY justifying it over other resources and
  innovations that compete for the same budget

27
Medicolegal

• Reduce liability risk of developer and users
• Establish role of resource in the spectrum of
  decision-support tools
• product liability
• professional services liability

28
Consider the stakeholders

• Developers
• Purchasers
• Users
• Patients
• Payers

29
Study Designs
30
Descriptive study
Acad Med 20047955763

• Uncontrolled
• Look at a single group to assess some property at
  one point in time

intervention
31
Historically controlled

• Before-after studies
• single cohesive unit (ICU alerting system)
• other explanations (new antibiotic, awareness)
• simultaneous control

control
intervention
32
Time series
control
intervention
control
intervention
Ann Intern Med. 2004141196-204.
33
Simultaneous randomized controls

• McDonald CJ. Reminders to physicians from an
  introspective computer medical record. Ann Intern
  Med 1984.
• physicians respond to outpatient reminders
• physician teams were randomized to study and
  control
• can infer causality

intervention
study subjects
control
34
Randomized crossover study

• McDonald CJ. Physician response to computer
  reminders. JAMA 1980.
• randomized crossover
• C-S1(no lit)-S2(lit), S1-C-S2,
• compare subjects to selves better power
• worry about carryover (learning)
• physicians respond to outpatient reminders
• effect is not learned
• never used the associated literature

control
intervention
study subjects
control
intervention
35
Survey research

• Basic survey design
• How important for you is it to know that the
  results of your self-testing can be reviewed in
  the medical center immediately after the test?
• Extremely important Very important Uncertain
  Not important at all
• Measurement
• (paper ruler)

36
Error

• Reliability
• precision (vs. random error)
• are you measuring something
• Validity
• accuracy (vs. systematic error)
• are you measuring what you want

37
Hierarchy of populations
external population (wish to generalize to)
External validity
target population (what you tried to sample)
Internal validity
actual population (what you sampled)
Statistical inference
study population (your actual subjects)
38
(Validity)

• Statistical inference
• is there an association
• p-value
• Internal validity
• are the conclusions (cause and effect) valid
  within the setting of the study
• reminders reduced infection rate by 30
• External validity
• can the conclusions be applied in other settings
• we can expect a reduction in other hospitals

39
(No Transcript)
40
Anything Wrong With This?

• You are studying a new rule in your decision
  support system that should improve
  formulary-based prescribing. You have a set of
  data including, for each row, patient id,
  provider id, order data, and whether or not the
  order was picked up. Your unit of analysis is
  the order. You find no difference in whether the
  prescription was picked up pre and post.

41
Anything Wrong With This?

• You are asked to determine whether a new method
  for information retrieval is superior to older
  methods. You develop a set consisting of 50
  articles that should be retrieved and 50 that
  should not be. You find the new method superior,
  with a positive predictive value of 90 compared
  with the published data from the old method, with
  a PPV of 45.

42
Anything Wrong With This?

• A study conducted over a 6-month period and
  evaluating the impact of CPOE on the mortality
  rate in an Academic Medical Centers Intensive
  Care Unit. You see a 2-fold, statistically
  significant increase in the mortality rate
  compared to the previous 6 months (before CPOE
  was instituted.)

43
What are qualitative methods?

• The design plan is iterative and flexible
• Data are words rather than numbers (usually)
• Larger context is considered

44
Qualitative and quantitative are not in conflict

• Different ways of seeking truth
• Inductive vs. deductive
• Perceptive/Subjective vs. objective
• Contextual vs. generalized

45

• Qualitative research INDUCTIVE
• Purposes
• generate theory from observation
• oriented to discovery, exploration
• Procedures
• emergent design
• flexible timeframe

• Quantitative research DEDUCTIVE
• Purposes
• tests theory through observations
• oriented to cause and effect
• Procedures
• predetermined design (protocol, frozen)
• fixed timeframe

46
Qualitative methods can yield discoveries

• "Not everything that can be counted counts, and
  not everything that counts can be counted."
• - Albert Einstein (1879-1955)

47
Qualitative methods take many forms

• Particularly appropriate for answering certain
  research questions
• Interviews, focus groups, participant
  observation, artifact and document analysis, and
  various combinations like case studies

48
Strategies for rigor enhance trustworthiness

• Reflexivity (know thyself)
• Triangulation
• Member checking
• Saturation in the field
• Audit trail

49
Interviews can be effective

• Interviews are not conversations
• Can be structured, semi-structured, or fairly
  unstructured
• Hear the human voices of assessment
• Discover motives, uncover multiple perspectives

50
Use purposive selection and dont ignore the
curmudgeons

• Seek out the outliers!

51
Focus groups are another way to gather data

• Are more than group interviews
• Benefit from synergy and energy
• Are not easier than interviews

52
Observation is another major method

• "Where observation is concerned, chance favors
  only the prepared mind."
• -- Louis Pasteur

53
Use your antennae

• You can observe a lot just by watching
•   --  Yogi Berra

54
Get others to use their antennae

• I only wish theyd come spend a day with us
• -physician about administrators
• Youre so lucky you get to watch so much
• -chief information officer to me
•

55
Observation can verify interview data

• Can watch typical daily tasks in context
• Can be more or less participative
• Must be planned and rigorous

56
Action research is a mixed methods approach

• Definitions
• A collaborative approach to research that
  provides people with the means to take systematic
  action in an effort to resolve specific problems
• Action research is an approach that aims to both
  take action and create knowledge or theory about
  that action
• Researchers get to do research (publish) and
  insiders get help

57
Rapid Ethnographic Assessment (REA) is another
mixed methods approach

• Also called Quick Ethnography
• Speedy but effective ethnography
• Uses careful project management and mixed method
  ethnographic tools

58
Case study research is also a mixed methods
approach

• An in depth look at one or more organizations
• Exploratory
• Descriptive
• Explanatory

59
Our CPOE study is a good example using multiple
qualitative methods

• In 1997, computerized physician order entry was
  touted as the answer to medical error problems
• We did national surveys in 1997 and 2003 to
  measure diffusion
• We mistrusted the results

60
We used observation, interviews, and focus groups

• Interns look and feel like this
• So theres a need to be unobtrusive

61
Good field notes were critical

• Handwritten during observation and interviews
• Improved upon and typed in full soon after

62
Transcripts and field notes were carefully
analyzed by individuals

• Coding the transcripts
• Use of software
• Building themes

63
We conducted further analysisduring
multidisciplinary team meetings
64
The results were rich descriptions and useful
insights

• Principles for successful implementations and
  types of unintended consequences of CPOE

65
Case 2

• Project 2 Assessing the Impact of Bedside
  Information Tools (Electronic Textbooks)
• Goal Measure the impact of the tools on health
  care quality
• Project Summary
• This project will take the best resources from
  project 1 and attempt to increase their use at
  the point of care, perhaps by supplying
  patient-specific links in the clinical
  information system (Infobuttons) or by providing
  easy access from bedside terminals. It should be
  designed as an experiment, with an intervention
  and a control group. The measured outcomes should
  be desirable and likely to improve.

66
Case

• Describe program
• Stakeholders
• Purpose
• What to evaluate
• Needs
• Designs skills
• Structure
• Function
• Impact
• Metrics, insights

• Methods
• Lab trial (fnc)
• Field trial (RCT)
• Survey instruments
• Ethnographic
• Focus group
• Cognitive
• Case studies
• Rapid ethnographic assessment
• Action research

67
EvaluationThe Rubber Meets the Road!
68
Your Expertise is Required!

• You are implementing a PDA-based tool to help
  with deciding what medication to prescribe,
  creating the prescription, and routing it to a
  pharmacy This tool would be integrated with the
  electronic health record. Your institution is
  willing to fund this project for 5 years, and you
  get additional funding to evaluate it over that
  period. Your results will impact whether the
  institution supports this for the long term.
  Note that your institution understands the
  importance of patient safety to their overall
  bottom line.

69
Assignments (5 minutes)

• Row 1 - given 1 month before the tool is built,
  what might you evaluate and how?
• Row 2 - Now that you've seen the tool, there is
  a decision to pilot it for a month with highly
  motivated users. What might you evaluate and how?
• Row 3 - The pilot is over and was successful.
  There were a few pilot users who wished there was
  more training, but by the end they were all good
  at using it. What might you do to help the next
  phase?
• Row 4 - The tool is about to roll out. What would
  you like to evaluate in the next 2 years, and
  how?

70
Well Done!
