ISO18000 vs AutoID classe1

1
ISO18000 vs Auto-ID classe1

• ISO SC31/WG4/SG03
• 21/01/2004
• CHRISTOPHE MANI

2
ISO18000

• Covert RFID needs in
• Long distance detection
• Unique ID
• Inventory
• Data Storage (ISO15961)
• Multiple frequencies
• 125KHz, 13.56MHz, 433MHz, 900MHz, 2.45GHz

3
Auto-ID Class 0 and 1

• Covert RFID needs in
• Long distance detection
• ePC code
• Inventory
• No data storage
• Multiple frequencies
• (13.56MHz) , 900MHz, 2.45GHz

4
Auto-ID Class 1 Generation 2

• Covert RFID needs in
• Long distance detection
• ePC code
• Inventory
• data storage in banks
• Multiple frequencies
• 900MHz, 2.45GHz

5
ISO18000Memory Organisation
6
Auto-ID Classe0 1Memory Organisation
7
Auto-ID Classe 1 Generation 2Memory Organisation
8
UID vs ePC

• UID (ISO18000)
• Fixed size for each 18000 (40 or 64 bits)
• Accessible in Read Only (IC programmed)
• Inventory algorithm linked to the UID size
• Uniqueness guaranty by single source IC fondery
• ePC
• Variable size (64bits, 96bits, )
• Can fully support the ISO15963
• Programmed on the supply chain
• Inventory algorithm not linked to the ePC size
• Uniqueness guaranty by EAN/UCC codification
  scheme, but final user has to managed it.

9
Complexity of ISO solutions

• ISO18000-6A commands

• ISO18000-6B commands

• Write_block
• Write_multiple_blocks
• Write_multiple_blocks
• Lock_blocks
• Lock_blocks
• Write_AFI
• Write_AFI
• Lock_AFI
• Lock_AFI
• Write_DSFID
• Write_DSFID
• Lock_DSFID
• Lock_DSFID
• Get_block_lock_status
• Get_block_lock_status

• Init_round
• Next_slot
• Close_slot
• Standby_round
• New_round
• Reset_to_ready
• Select
• Read_blocks
• Read_blocks
• Get_system_information
• Get_system_information
• Init_round_all
• Begin_round
• Write_block

• GROUP_SELECT_EQ
• GROUP_SELECT_NE
• GROUP_SELECT_GT
• GROUP_SELECT_LT
• GROUP_UNSELECT_EQ
• GROUP_UNSELECT_NE
• GROUP_UNSELECT_GT
• GROUP_UNSELECT_LT
• FAIL
• SUCCESS
• INITIALIZE
• DATA_READ
• READ
• WRITE
• WRITE_MULTIPLE
• LOCK
• IC manufacturer dependant
• QUERY_LOCK
• READ_VERIFY

• MULTIPLE_UNSELECT
• IC manufacturer dependant
• RESEND
• IC manufacturer dependant
• GROUP_SELECT_EQ_FLAGS
• GROUP_SELECT_NE_FLAGS
• GROUP_UNSELECT_EQ_FLAGS
• GROUP_UNSELECT_NE_FLAGS
• WRITE4BYTE
• WRITE4BYTE_MULTIPLE
• READ_VERIFY_4BYTE
• FAIL_O
• SUCCESS_O
• DATA_READ_O
• RESEND_O
• READ_FLAGS
• READ_VARIABLE
• READ_PORT
• READ_UNADDRESSED

10
Auto-ID protocols

• Class 1 commands
• MASKED SCROLL
• SLEEP
• KILL
• PING
• WAKE
• GLOBAL SCROLL
• ERASE
• PROGRAM
• VERIFY

• Class 1 generation 2
• QUERY
• QUERYREP
• RESEND
• ACK
• NAK
• REQ_RN
• SELECT
• RESET
• READ
• WRITE
• LOCK
• KILL
• CONCEAL
• PASSWORD
• WRITEPASSWORD
• ERASE
