Biological Database Systems

1
Biological Database Systems

• 8.1. Design issues specific to biological
  database systems (cont.)

2
Scientific requirements to design

• Scientific culture requirements
• Need to track the source of data
• Need to accommodate the fuzziness of biology
• Database should support these aspects
• (in case of relational DBMS) most tables store
  information about domain of your interest and
  several supplemental tables plus some attributes
  of informative tables contain technical
  information (related to tracking, versioning,
  etc.)

3
Tracking the data sources

• It is recommended to track the source of
  features
• E.g., features may be entered by users (rather
  than obtained from source databases)
• Different source databases may provide
  contradictory data/metadata
• Lack of tracking the sources may create problems
• Seq A is annotated as a kinase because of
  sequence similarity with Seq B
• Seq B turns out not to be a kinase
• Most probably Seq A has same basic structure as
  Seq B, but lacks kinase function
• Seq C is annotated as a kinase because of
  similarity to Seq A
• Function annotations cannot be trusted unless
  function transfers are traceable

4
Tracking the data sources

• It is crucial to be able to lookup and evaluate
  source reference
• Science is incomplete
• Your research may contradict the data in the
  database
• Where is the error? Often, both right since there
  is no full picture yet
• Researchers need to return to original source and
  evaluate experimental steps
• Gold standard is a peer-reviewed publication
• As a rule, indexed in the PubMed database
• But not always there are other sources (e.g.,
  publications in other domains like chemistry,
  technical reports, webpages, companies reports,
  etc.)

5
Tracking the data sources

• Reference data is quite complex
• For many tasks, it is enough to link to the
  PubMed
• Reference itself has to be stored if there is a
  need in queries into references
• E.g., find all features supported by works
  written by John D.
• NCBI provides a reference in XML format (can be
  parsed and stored in your database)
• Bibliographic Query Service (access to
  heterogeneous bibliographic databases,
  http//www.ebi.ac.uk/senger/openbqs)

6
Versioning

• Very important concept in software development
• Some public databases version their sequences
• For example RefSeq
• Sequence is identified by an accession number and
  a version (e.g., NM_005842.2)
• As a rule, only the latest version is available
• Have to decide do you need versioning or not? If
  yes, how to handle it in database
• Keep latest version only or all versions
• In case of keeping all versions, do you associate
  different versions of the same sequence with each
  other?
• What should happen to any metadata added to a
  sequence when its new version comes out?

7
Handling uncertainties

• Fuzziness in biology there will an exception in
  almost any biological classification scheme
• Make schemes user-extensible using lookup
  tables
• Provide a comment field so that users can
  document the exceptions
• Accommodate uncertainty in biological data

8
Handling uncertainties

• Uncertainty is associated with all scientific
  data
• Imperfections in measurement techniques
• Incomplete knowledge
• Handling uncertainty depends on
• Type of uncertainty
• Requirements of the scientists who use the data
• Ignoring uncertainty may corrupt your database
• Scientific conclusions may be derived from data
  in database
• Uncertainty in data will influence conclusions
• If users cannot assess uncertainty of data,
  database becomes less valuable

9
Handling uncertainties types

• Uncertainty in quantitative data can be
  calculated
• Store raw data and calculate on the fly
• Store data and calculated error (e.g., average
  and standard deviation)
• Uncertainty in qualitative data is more difficult
  to handle
• Some types of experiments are inherently less
  certain than others

10
Handling uncertainties

• Examples of bio-data with uncertainty
• Protein-protein interactions
• Large scale studies and individual studies have
  differing uncertainties
• Biophysical measurements
• Often include quantitative uncertainties
• Protein function annotation
• Large difference in uncertainty between
  experimental and computational annotations

11
Handling uncertainties example
12
Handling uncertainties

• The problem illustrated on the prev.slide is not
  caused by the first annotation transfer
• The problem is caused by the fact that a
  researcher using the data does not know that the
  annotation on protein 2 is less certain than the
  annotation on protein 1
• Solution is to include this uncertainty in the
  data presented to a user

13
Handling uncertainties

• Include it in the annotation text annotate
  protein 2 as sugar kinase (by similarity)
• GenBank/other sequence databases do this way
• Include information about the source of the
  annotation classify annotation on protein 1 as
  experimental and annotation on protein 2 as
  computational (derived)
• Gene Ontology includes evidence classifications
• Link annotation directly to the supporting data
• May be appropriate for database for lab/company
  that concentrates on protein annotations

14
Handling uncertainties
With classification method
15
Handling uncertainties
With supporting evidence
16
Biological database design and implementation

• Experience of building biological databases from
  people behind the Ensembl project (producing and
  maintaining automatic annotation on selected
  eukaryotic genomes), http//www.ensembl.org
• See Biological database design and
  implementation by Birney Clamp, Briefings in
  Bioinformatics, 5(1)31-38, 2004
• Best practices (very practical) to help people
  design/build bio-databases
• Note BirneyClamp didnt really distinguish
  between database systems and software development

17
Biological database design and implementation

• Unique problems for biological databases
• There is no true biological interpretation of
  data stored in database
• Interpretation can change over time
• Discovering new relationships between some
  aspects of the data is an important part of
  motivation to store information in database
• Technically, experiment-based data can be
  considered as invariable (e.g., read-outs from
  microarray chips), but, generally, there is
  always some agreement where data and data
  interpretation starts and ends (e.g., microarray
  data are manipulated before storing)

18
Biological database design and implementation

• Unique problems for biological databases
• Lack of people with good understanding of both
  biology and programming/database systems
• Hopefully, there will be more such people
• At least, people who involved in database
  building should have an appreciation of the other
  field

19
Biological database design and implementation
general points

• Use Source Code Control
• Concurrent Versions System (CVS) keeps track of
  all work and all changes in a set of files,
  typically the implementation of a software
  project, and allows several developers to
  collaborate
• Very useful even for only one person, essential
  for group of two and more
• Use relational databases (MySQL, PostgreSQL, ---
  SQLite)
• Do not store your data in text files (exceptions
  images often require specialized tools sequence
  files since many tools are tied to specific
  formats)
• Just study them

20
Biological database design and implementation
general points

• Be aware of cutting edge technologies
• Use only if you really have to
• More buggy because it is new and, hence, was not
  tested/used in different scenarios
• (!) there will be only a small number of people
  (and generally only one in your group) who
  understand this technology well
• Advice
• Programming languages C, C, Java, Perl,
  Python, Lisp (?)
• Database systems relational databases, SQL

21
Biological database design and implementation
general points

• Avoid to mix database development with
  CS/bioinformatics research
• Particularly, CS-oriented people may be eager to
  make in advance in CS using biological data as an
  exemplar
• Concentrate on a particular domain
• Do not try to integrate as much biological data
  as possible
• Make sure that no one or only a few groups
  provide a similar resource
• Particularly, people with biological background
  like to sketch out too detailed scheme that
  incorporates almost everything in a topic of
  interest (-- see slides for Lec.7 scope
  boundaries)
• Better find pieces of information that are
  missing in other places and focus on them

22
Biological database design and implementation
detailed advice

• Database project should have
• CVS repository
• Mailing lists for all group members, for
  programming developers, for public
• Well-backed-up production database instance
• Relatively isolated web-viewed database instance
• Development areas (place where developers can
  create and destroy development databases and
  develop new code)

23
Biological database design and implementation
detailed advice

• People behind database (it is rare for a single
  person to do three or more roles)
• Bioinformatician (understands what the data is
  and its biological meaning)
• Web developer
• Software developer (understands the precise
  database/software implementation and writes the
  required software)
• System administrator (provides support during
  system specific problems)

24
Biological database design and implementation
code and schema design

• Decide on a principal data model description
• SQL DDL (i.e., CREATE TABLE statements)
• XML DTD or XML Schema
• UML
• Try to focus on the core aspects of data or
  analysis
• Invest time into data model design
• Dont overdo (one month is likely to enough)
• Almost impossible to understand consequences of
  the design until one tries it out
• Design requirements are likely to be changed
• Use two types of tracking identifiers
• Internal (used within the database and related
  software)
• Published (external)
• When writing software
• Use object-oriented approach (aim for simplicity
  and code reuse)
• Test the code intensively

25
What makes a good database?

• Annual Nucleic Acids Research Database Issues
• A few pieces of advice from the editor of NAR
  database issue
• See What Makes a Good Database by Batemen, NAR,
  35(Database issue) D1D2, 2007
• Note very broad suggestions how to make your
  resource included in the database issue (i.e.,
  automatically means the database should be
  original in some way)

26
What makes a good database?

• Data considerations
• When thinking of a name for your database check
  if anyone else is using that name already (check
  search engines with your database name, you may
  be surprised at what it means in other languages
  )
• Make your data as comprehensive as possible (try
  to avoid making the data collection
  overspecialized i.e., a database of promoters
  for RNA genes in a single organism is not going
  to have a wide appeal, but a database of
  promoters for RNA genes in all organisms would be
  of wide interest and utility)
• Attribute the original sources of derived data
• Make sure that you are not breaching any license
  terms by redistributing data
• Include estimates of confidence in the data items
  if applicable
• Make data available for bulk download as flat
  files or relational database tables with
  associated documentation
• Web services are becoming popular ways to make
  databases programmatically available (i.e.,
  provide users with both user-friendly (via
  website) and program-friendly interfaces)
• Allow users to provide feedback on your data and
  submit new data

27
What makes a good database?

• Web interface considerations
• Document your web interface and data (include a
  short tutorial if possible)
• Include a brief statement of what your database
  does on the front page
• Make sure that users can always link back to the
  home page
• Do not make all your links pop up in new windows
• Include example sequence/identifiers/keywords for
  every entry box on a query form
• Keep search forms as simple as possible (most
  users will not want to do complex queries of your
  data keep advanced searches on a separate linked
  page)
• Allow users to browse the data without searching
  for a specific entry (e.g., provide alphabetical
  lists of entries, or entries sorted by function)
• Do not use a jargon term when a well-known term
  already exists

28
What makes a good database?

• Web interface considerations
• Make it obvious what information will be on a
  linked page and make clickable icons convey their
  function pictorially
• Get a domain name for your website (URLs to
  specific IP addresses/ports are unlikely to stand
  the test of time)
• Test your website on a range of browsers and on a
  range of operating systems and make sure that
  external users can access all the content
• Get feedback from your user community before
  submission
• Slow server response times will make your
  database unusable (you can help this by printing
  out at least some message to let users know when
  they may expect to obtain results)
• Look at websites devoted to creating good web
  pages (also have a look at the web pages
  describing web page faults to avoid such as
  http//www.webpagesthatsuck.com/)

29
Concluding remarks

• Successful design of biological databases
  requires understanding of biology and database
  principles
• Will not necessarily have both in same person
• Work in teams
• Respect the complexity of the field that is not
  your own
• For most research-scale databases, performance
  will be adequate without any tricks
• Use relational DBMSs
• Denormalizing is unlikely an option (denormalize
  only as a last resort)
• There is no right (or best) answer for many of
  the design issues
• Decisions often depend on database requirements
• Field is too young so there is no consensus on
  best way to handle data
• Dont get stuck in analysis paralysis take your
  best shot, and learn from how it works (or
  doesnt work)

30

• References
• Biological database design and implementation by
  Birney Clamp, Briefings in Bioinformatics,
  5(1)31-38, 2004
• What Makes a Good Database by Batemen, NAR,
  35(Database issue) D1D2, 2007
