Eddies: Continuously Adaptive Query Processing

1
Eddies Continuously Adaptive Query Processing

• Ross Rosemark

2
Goals of Presentation

• What are traditional query optimizers?
• What are the problems with these optimizers?
• What is an eddy?
• How does an eddy work?
• Discuss how an eddy self tunes query plans?

3
Traditional Query Optimizer

• Metadata (statistics) about the distribution of
  data is collected by the query optimizer
• Based on the metadata the query optimizer
  determines the most energy efficient query plan
• Query plan is executed.
• This is good for snapshot queries (short lived
  queries)

4
Problems

• The problem with this approach is that data
  became streaming
• Internet
• Sensor nodes
• Etc.
• The query plan chosen by the query optimizer
  could eventually become inefficient if the
  metadata statistics change
• Cost of operators
• Operator selectivies could change
• Rate tuples arrive from inputs
• Also its difficult to just re-optimize a query
• Determining when to re-optimize the query is a
  difficult research issue that has not been
  addressed.
• Must determine not only when you should
  re-optimize but that re-optimizing still leaves
  produces the same state

5
Example

• Assume a query that asks for Employees age and
  salary gt 100000 is issued into the sensor
  network.
• Initially the predicate salary gt 100000 will be
  very selective hence eliminating a lot of tuples
• As older employees in the database start to be
  read the predicate salary gt 100000 will be less
  selective

6
Lets show some things Eddie must consider.

• Eddie should
• Increase synchronization
• Increase the moments of Symmetry

7
Synchronization Barriers

• Synchronization barriers
• Where one operation hinders the speed of another
  operations
• Extreme example
• Assume you have a merge join on two
  duplicate-free inputs. (slowlo and fasthi)
• Assume that during processing the next tuple is
  always consumed from the relation that had the
  lowest values
• Assume that slowlo is a slowly delivered external
  relation with many low columns in its bandwith
• Assume that fasthi is high bandwith (i.e.
  delivers tuples fast) and has only high values in
  its column
• In this example fasthi is delayed why slowlo
  delivers tuples
• Known as a synchronization barrier
• Desirable to minimize the number of
  Synchronization barriers

8
Moments of Symmetry

• You can only re-optimize at a moment of symmetry
• A moment of symmetry is when the query is
  executed to a point that the optimizer can change
  the query plan without affecting the way the
  query plans predicates are performed
• Typically happens in joins
• Example
• Assume you have a nested loop join with inner
  relation R and outer relation S.
• In this example you can only re-optimize this
  join when R is completely scanned.
• It is possible to re-optimize in the middle of
  scanning S but the join algorithm would then have
  to be changed

9
Eddy

• An Eddy was designed to dynamically re-optimize
  queries.
• The authors implemented Eddies in a River
• A river is a shared nothing parallel query
  processing framework that dynamically adapts to
  fluctuations and workloads
• An eddy is implemented via a module in a river
  containing an arbitrary number of input
  relations, a number of participating unary and
  binary modules, and a single output relation
• An Eddy also maintains a fixed size buffer of
  tuples that need to be processed
• Each operator takes two tuples, processes them
  and delivers them back to the eddy

10
Eddy (Cont)

• A tuple in a eddy is associated with a tuple
  descriptor
• Contains a vector of Ready bits and Done bits
• The Eddy ships the tuple to only the operators
  that have the Ready bits turned on
• After an operators is processed its Done bits
  are set
• If all done bits are set the tuple is sent to the
  Eddys output
• Else its sent to another operators

11
Eddy (Cont)

• So how do you route tuples to the different Eddy
  operators
• In this paper they look at multiple different ways

12
Naïve Scheme

• Eddies buffer is implemented as a priority queue
• Recall the buffer is used to store tuples that
  should be processed by the Eddies
• When a tuple enters a buffer its priority is set
  to low
• After its processed by an operator in the Eddy
  and returned to the buffer its priority is set
  to high
• This ensures that tuples do not get stuck in the
  Eddy. I.e. starvation
• This scheme dynamically adjusts to work required
  of operators
• Operators that are slower (i.e. take 4 seconds
  vs. 1 second will receive less tuples)
• Note each operator has a fixed size queue
• Once queue is filled up no more tuples can be
  inserted into queue

13
Lottery Scheme

• Each time a tuple is routed to a operator the
  operator is credited with a ticket
• When the operator returns a tuple the eddy one
  ticket is debited from the eddies running count
  for that operator
• Tracks how efficiently a operator drains tuples
  from the system
• When a tuple is to be routed to an operator the
  Eddy holds a lottery
• Only the operators that have their Ready bit sets
  can participate in the lottery
• An operators chance of winning the lottery and
  receiving
• the tuple corresponds to the count of tickets
  for that operator.
• Dynamically adjusts to selectivity of operators

14
Window Scheme

• Problem with lottery scheme is that it uses to
  much past info
• Problem An operator that gained a lot of ticket
  initially but then became slow
• In this scheme the lottery scheme is modified
  such that the lottery only looks at tickets
  gained by an operator in a fixed window.
• Keeps track of two types of tickets
• Banked tickets
• Used when running the lottery
• Escrow tickets
• Used to measure efficiency during the window
• At the end of a window
• Banked Tickets Escrow Tickets
• Escrow Tickets 0
• Ensure operators re-approve themselves each
  window

15
Comparison

• Shows that due to Fluid Dynamics (i.e. the
  varying rates of operators) the Naïve approach
  naturally adjusts based on the cost of operators
• Shows that Lottery also adjusts based on workload

16
Comparison

• Naïve eddies does not adjust based on selectivity
• Naïve performs between the best and worse
• Lottery does adjust based on selectivity

17
Joins

• Shows that Lottery performs nearly optimally
• Naïve performs between the best and worst

18
Joins (Cont)

• All joins are ripple joins
• Change selectivity of join predicate
• In all cases the Eddy with the Lottery is close
  to optimal

19
Window Scheme

• Both cases are related to different query plans
• Shows eddy is in between the best and worst case

20
Adaptability

• Toggle the cost of the operator 3 times
  throughout experiment
• Notice that Eddy switches how many tuples are
  first processed by that operator

21
Problems

• Does not work well when there is initially a long
  delay at an operator
• Eddy gives all tuples to operator because
  operator is not returning tuples that satisfy the
  join predicates criteria
• Not until after the delay
• Notice eventually this problem is figured out by
  Eddy
• Just make take some time
