Title: Manipulating Data Using Methods


1
Chapter 3
  • Manipulating Data Using Methods

2
Introduction
  • Data are collections of raw facts or figures
  • A program performs operations oninput data to
    output information
  • Input data can come from a variety of sources
  • The program itself
  • Users of the program
  • External files

3
The Body Mass Index Calculator
  • An interactive program
  • Accepts the weight and height from the user
  • Calculates the BMI to gauge total body fat
  • Displays the result
  • Three versions
  • Input/Output using the command prompt
  • Input/Output using dialog boxes
  • Web environments use an applet interface

4
(a) console application in a command prompt window
(b) console application using dialog boxes
(c) applet
5

6
Problem Analysis
  • Convert user input to metric measurements
  • Calculate the BMI
  • Display the result

7
Design the Solution
  • Design the three kinds of user interfaces with
    storyboards
  • Design the logic of the program
  • Use pseudocode for sequential flow for all
    programs
  • Use an event diagram for the applet
  • Validate the design
  • Compare the program design with the original
    requirements

8

pseudocode
event diagram
9
Code the program
  • Open TextPad and save as BodyMass.java
  • Enter beginning comments (lines 1 9)/
    Chapter 3 Body Mass Index Calculator
    Programmer your name Date todays date
    Filename BodyMass.java Purpose This project
    calculates the body mass index based on a
    person's height and weight./
  • Line 10import java.io.

10
Code the program
  • Add class header and main method header(lines 12
    15)public class BodyMass
  • public static void main(String args) throws
    IOException

11
Code the program
  • Import the java.io package
  • Provides classes to support system input and
    output
  • Add a throws IOException clause to the method
    header
  • Warns the compiler that the possibility of input
    or output errors exists
  • Gives the program the opportunity to handle input
    or output errors during run-time without aborting

12
Storing Data
  • Java is a strongly typed language
  • Variables must be declared with a data type
  • Variable locations can hold only that data type
  • Java has two categories of data types
  • Primitive data types hold single data items
  • Integers, characters, floating point, and
    booleans are primitive types
  • Reference data types hold a value that refers to
    the location of the data
  • All Objects and arrays are reference types

13

14
Declaring Variables
15
Code the program
  • Declare and construct variables (lines16
    19)// declare and construct variablesString
    strHeight, strWeightint intInches,
    intPoundsdouble dblKilograms, dblMeters,
    dblIndex

16
User Input Streams and the System Class
  • The act of data flowing in and out of a program
    is called a stream
  • The System class creates three streams when a
    program executes

17
User Input Streams and the System Class
  • Data from input streams are first sent to a
    buffer
  • The java.io package contains several stream
    classes
  • InputStreamReader
  • Decodes the bytes from the System.in buffer into
    characters
  • BufferedReader
  • Increases efficiency by temporarily storing the
    input received from another class, such as
    InputStreamReader
  • Aids in platform independence by simplifying the
    process of reading text and numbers from various
    input sources

18
Using the BufferedReader class
  • Call the BufferedReader constructor to
    instantiate a BufferedReader object
  • The argument of the BufferedReader( ) method
    instantiates an InputStreamReader
  • BufferedReader( ) returns a reference to the
    input data from System.in
  • Line 20 BufferedReader dataIn new
    BufferedReader (new InputStreamReader
    (System.in))

19
(No Transcript)
20
User Prompts, Inputs, and Conversions
  • The readLine() method reads a line of input text
    and returns a String containing the line
  • The returned String must be explicitly converted
    if the data is to be used as another data type
  • Each primitive data type has a wrapper class
    allowing the primitive to be treated as an object
  • The wrapper classes provides a parse() method to
    convert Strings to primitives, and vice versa

21
Code the program
  • Lines 22 - 30// print prompts and get input
  • System.out.println("\tTHE SUN FITNESS CENTER
    BODY MASS INDEX CALCULATOR")
  • System.out.println()
  • System.out.print("\t\tEnter your height to the
    nearest inch ")
  • strHeight dataIn.readLine()
  • intInches Integer.parseInt(strHeight)
  • System.out.print("\t\tEnter your weight to the
    nearest pound ")
  • strWeight dataIn.readLine()
  • intPounds Integer.parseInt(strWeight)

22
Assignment Statements
  • General syntax location value

23
Arithmetic Operators
24
Arithmetic Operators
  • The order of operator precedence is a
    predetermined order that defines the sequence in
    which operators are evaluated in an expression
  • Addition, subtraction, multiplication, and
    division can manipulate any numeric data type
  • When Java performs math on mixed data types, the
    result is always the larger data type
  • Casts allow programmers to force a conversion
    from one primitive type to another

25
Comparison Operators
  • A comparison operation results in a true or false
    value that can be stored in a boolean variable

26
Numeric Expressions
  • Numeric expressions evaluate to a number
  • Only numeric primitive data types may be used in
    a numeric expression
  • A value and variable must be separated by an
    arithmetic operator
  • Unless parentheses supercede, an expression is
    evaluated left to right with the following rules
    of precedence
  • Multiplication and/or division
  • Integer division
  • Modular division ( modulus)
  • Addition and/or subtraction

27
Conditional Expressions
  • Conditional expression evaluate to either true or
    false (10 lt 5 true)
  • Comparison operators, values, variables, methods,
    and Strings may be used in a conditional
    expression
  • Two operands must be separated by a comparison
    operator
  • Unless parentheses supercede, an expression is
    evaluated left to right with relational operators
    (lt, lt, gt, gt) taking precedence over equality
    operators (, !)

28
Parentheses in Expressions
  • Parentheses may be used to change the order of
    operations
  • The part of the expression within the parentheses
    is evaluated first
  • Parentheses can provide clarity in complex
    expressions
  • Numeric and conditional expressions should be
    grouped with parentheses
  • Parentheses can be nested
  • Java evaluates the innermost expression first and
    then moves on to the outermost expression

29
Construction of Error-Free Expressions
  • Java may not be able to evaluate a validly formed
    expression due to the following logic errors
  • Dividing by zero
  • Taking the square root of a negative value
  • Raising a negative value to a non-integer value
  • Using a value too great or too small for a given
    data type
  • Comparing different data types in a conditional
    expression

30
The Math Class

31
Using Variables in Output
32
Code the program
  • Lines 32 35
  • // calculations
  • dblMeters intInches / 39.36
  • dblKilograms intPounds / 2.2
  • dblIndex dblKilograms / Math.pow(dblMeters, 2)

33
Code the program
  • Lines 37 - 42
  • // output
  • System.out.println()
  • System.out.println("\tYOUR BODY MASS INDEX
    IS " Math.round(dblIndex) ".")
  • System.out.println()

34
Compiling, Running, and Documenting the
Application
  • Compile the Body Mass Index Calculator program
  • Execute the program
  • Test the program by entering the sample input
    data supplied in the requirements phase at the
    prompts
  • Verify the results

35
Sample Results
36
Using Swing Components
  • Save the previous version of the Body Mass Index
    Calculator with a new filename
    BodyMassSwing.java
  • Use Search/Replace to find BodyMass and change
    them all to BodyMassSwing in the program.

37
Using Swing Components
  • Remove the old import statement and replace with
    import javax.swing.JOptionPane
  • Contains methods to create dialog boxes for
    input, confirmation, and messages
  • Delete the IOException and BufferedReader code
  • The swing dialog boxes buffer data from the user
    and handle IO errors

38
Code the program
  • Lines 10 22
  • import javax.swing.JOptionPane
  • public class BodyMassSwing
  • public static void main(String args)
  • // declare and construct variables
  • String strHeight, strWeight
  • int intInches, intPounds
  • double dblKilograms, dblMeters, dblIndex
  • // print prompts and get input
  • System.out.println("\tTHE SUN FITNESS CENTER
    BODY MASS INDEX CALCULATOR")

39
Swing Dialog Boxes
  • Dialog boxes are created with the JOptionPane
    show methods
  • The showInputDialog() and showConfirmDialog
    return a String containing the user input
  • First argument null means to center in the
    active window
  • Second argument is the display area inside the
    dialog box
  • Third argument is the caption on the title bar
  • Fourth argument is a constant refering to the
    type of icon

40
OptionPane.showMessageDialog(null, "message",
"caption", one of the arguments below)
JOptionPane.ERROR_MESSAGE
JOptionPane. INFORMATION_ MESSAGE
JOptionPane. WARNING_ MESSAGE
JOptionPane. QUESTION_ MESSAGE
JOptionPane. PLAIN_ MESSAGE
41
Code the program
42
Closing Programs that use Swing
  • System.exit() terminates an application that
    displays a GUI
  • The command prompt window closes when this method
    is called
  • System.exit accepts an integer argument that
    serves as a status code
  • 0 indicates successful termination
  • 1 indicates abnormal termination
  • Add Line 39 System.exit(0)

43
Saving, Compiling, and Running the Swing Version
  • Verify that the file name matches the class name
    at the beginning of the code
  • Compile the source code
  • Test with the same sample data for all versions
    to compare output results
  • If incorrect or unrealistic data is entered by
    the user, errors will occur
  • Errors and exception handling will be discussed
    in a later chapter

44
Run the application
45
Moving to the Web
  • The applet version of the Body Mass Index
    Calculator has four kinds of objects
  • Image, Labels, TextFields, and Buttons
  • Import three packages
  • Java.applet
  • Java.awt
  • Java.awt.event
  • Implement an ActionListener interface in the
    class header
  • Informs the program to respond to user-driven
    events

46
Moving to the Web
  • Every event class has one or more associated
    listener interfaces

47
Code the program
  • Using TextPad, start a new program
  • Save the program as BodyMassApplet.java
  • Enter the first 13 lines
  • /
  • Chapter 3 Body Mass Index Calculator
  • Programmer your name here
  • Date todays date
  • Filename BodyMassApplet.java
  • Purpose This project calculates the body mass
    index based
  • on a person's height and weight.
  • /
  • import java.applet.
  • import java.awt.
  • import java.awt.event.

48
Code the program
  • Lines 14 - 19
  • public class BodyMassApplet extends Applet
    implements ActionListener
  • // declare variables
  • Image logo // declare an image object
  • int intInches, intPounds
  • double dblKilograms, dblMeters, dblIndex

49
Adding Interface Components to an Applet
  • Label
  • Displays text in the applet window
  • TextField
  • Displays a text box for users to enter text
  • Buttons
  • Displays a command button for users to click

50
Code the program
  • Lines 21 - 28
  • //construct components
  • Label companyLabel new Label("THE SUN FITNESS
    CENTER BODY MASS INDEX
    CALCULATOR")
  • Label heightLabel new Label("Enter your height
    to the nearest inch")
  • TextField heightField new TextField(10)
  • Label weightField new Label("Enter you weight
    to the nearest pound")
  • TextField weightField new TextField(10)
  • Button calcButton new Button("Calculate")
  • Label outputLabel new Label("Click the
    Calculate Button to see your body mass
    index.")

51
The init() Method
  • Initializes the window color and graphic
  • Adds components to the applet window
  • Registers the Buttons ActionListener
  • Enter lines 30 42

52
The actionPerformed() Method
  • When a click event occurs, the ActionListeners
    actionPerformed() method is triggered
  • Input values are retrieved with getText()
  • Calculations are performed
  • Output is sent to a label with setText()
  • Enter lines 44 52
  • public void actionPerformed(ActionEvent e)
  • intInches Integer.parseInt(heightField.getText(
    ))
  • intPounds Integer.parseInt(weightField.getText(
    ))
  • dblMeters intInches / 39.36
  • dblKilograms intPounds / 2.2
  • dblIndex dblKilograms / Math.pow(dblMeters,
    2)
  • outputLabel.setText("YOUR BODY MASS INDEX IS "
    Math.round(dblIndex)
    ".")

53
The paint() Method
  • Draws the initialized image in the applet window
  • Lines 54 - 58

54
Creating an HTML Host Document for an Interactive
Applet
  • Save and Compile the applet
  • Fix any errors and compile again
  • In TextPad create a new document and save as
    BodyMassApplet.html
  • ltHTMLgt
  • ltAPPLET CODE "BodyMassApplet.class" WIDTH
    375 HEIGHT 300gt
  • lt/APPLETgt
  • lt/HTMLgt

55
Run the java applet
56
File Management
  • Coding and compiling an application creates
    several files on your storage device
  • File naming conventions and the operating
    systems capability of displaying icons can help
    the programmer maintain a logical order
  • Three java files named after the program purpose
    and user interface type
  • Three class files after compilation
  • HTML host document
  • Image file

57
Chapter 3 Homework
  • Short Answer, page 201
  • 1 9, 11 - 15
  • Only type the answers, not the questions
  • All answers must be typed and printed out
  • Debugging Assignment, page 205
  • Programming Assignments
  • Pages 208 - 215
  • 3, 4, 6, 10
Write a Comment
User Comments (0)
About PowerShow.com
