Broadcast Basics

1
Broadcast Basics

• Week 13

ICS 620
2
BROADCAST BASICS
ICS 620 Week 13
3
Introduction

• Video Basics (Analog Systems)
• Transmission Systems
• Wireless (terrestrial)
• Wired (cable television)
• Digital Video (Two Weeks)

4
Video Standards

• Standards and Principals
• Persistence of Vision
• The rapid presentation of frames of video
  information to give you the illusion of smooth
  motion.

5
Frequency StandardsFrame Frequency

• 16 Frames per Second (fps) Black and White
• 24 fps SOF
• Continuity of Action
• Problem of Flicker
• The gross alteration of light and dark

6
Frequency StandardsField Frequency

• Frame Frequency x 2
• Continuity of Illumination

7
Film Vs. Video

• Film - Project a complete picture
• Video - Scan, line by line, at a high rate of
  speed - 6 million bits per second

8
How do we describe a picture?

• A picture element (pel or pixel) one at a
  time

• For each pel we need to somehow describe
• Brightness (luminance)
• Hue (phase, tint)
• Saturation (color intensity, chroma)

9
Vertical Resolution

• The picture quality associated with the number of
  dots (pixels) used to construct the picture.

• 367,000 dots
• on 525 rows (vertical)

10
Film vs. NTSC Specs

• Aspect Ratio

11
Camera Tubes
12
Early Camera Tubes
13
Image Orthicon
14
Electronic Scan (Camera Pickup Tube)
Target
Lens
Object
Electron Beam
Video Signal
15
Scanning

• Progressive
• Interlace/Offset
• Interlace Example
• NTSC 525 lines, 30 frames/sec,
• 60 fields/sec

16
Picture Tube
17
Picture Tube
18
Picture Tube
19
Scanning a Focused Image
20
Progressive Scanning
21
Interlace Scanning
22
Sync Pulses
23
Differences Between Horizontal and Vertical Synch
Pulses

• Rate Duration
• Vertical 59.94/sec 13
• Horizontal 15,734.264/sec 31

24
Waveform Sketch of a Video Signal
25
A simple video waveform
One Line
26
Waveform of Sync Pulses
27
IRE Measurement Scale
28
Vertical Blanking Interval (VBI)

• Lines 1-21 of each field
• Vertical Interval Test Signal (VITS)
• Vertical Interval Reference Signal (VIRS)
• Lines 1-9 V-sync and Equalizing Pulses
• Lines 12-14 SMPTE Time Code
• Lines 17-19 VITS and VIRS
• Line 20 Network Source Code (field 1)
• Line 21 Closed captioning (field 1)

29
Kell Factor

• The Ratio of effective resolution to the
  theoretical resolution is known as the Kell
  Factor.


30
Vertical Resolution Summary

• Max Lines/Frame 525
• Lost for Vertical Blanking 42 (21 lines per
  field)

• Visible 525-42 483
• Kell Factor 72.5
• Effective Resolution 350 lines

31
Horizontal Resolution Summary

• (4.2 MHz Video Bandwidth)
• 4.2 cycles per microsecond
• x 52 microseconds (active scan)
• x 2 pixels per cycle
• 436 pixels per line

32
Television Transmission

• Picture Information
• Blanking pulses
• Sync pulses
• Audio information

33
What about Color?
34
Component Nature of Color
R
G
B
35
Video Color Palette
36
Color Television

• R Red
• G Green
• B Blue
• B G Cyan
• G R Yellow
• B R Magenta

37
NTSC Color Bars
38
Block Diagram of Color Camera
39
Gamma G

• A measurement of contrast, gamma correction is
  required because the brightness output of a
  camera does not correspond to the brightness
  recognition of the human eye.

40
Composite Color

• Y Luminance Signal
• Y 30 red 59 green 11 blue
• C Chrominance Signal
• C I Q Matrix

41
Color Matrix

• Saturation Amplitude of the I and Q signals
• Hue Phase developed by the difference in
  amplitude between the I and Q signals

42
Transmitter Tube
43
Color TV Transmitter
44
TV Frequency Allocations
2 - 4 VHF-Lo 54 MHz - 72 MHz
5 - 6 VHF-Lo 76 MHz - 88 MHz
7 13 VHF-Hi 174 MHz 216 MHz
14 59 UHF 470 MHz 746 MHz
NOTE Natural breaks occur between channels 4 a
nd 5 channels 6 and 7 and channels 13 and 14.
Each channel is 6 MHz wide.
45
NTSC Bandpass Characteristics (Black and White)
46
Color TV Signal
47
NTSC Bandpass Characteristics (Color)
48
Color TV Signal
49
Worldwide Standards

• National Television System Committee - NTSC
  (1953)

• Phase Alternation Line -PAL (1967)
• Sequentiel Couleur Avec Memoire - SECAM (1967)

50
World TV Standards
51
World TV Standards
52
Principal TV Systems
53
FM Stereo Transmitter

• Transmitter Output
• Main Channel (L R)
• Stereo Channel (L - R)
• 19 kHz Pilot Sub-carrier

54
Stereo Multiplexing

• LR Signal (Main Channel)
• L-R Signal (Stereo Channel)
• 19 kHz Pilot Subcarrier (FM)

The Math (L R) (L - R) 2 L (L R) (- L
R) 2 R
55
FM Stereo Receiver
56
Television Stereo

• Multi-channel Television Sound (MTS)
• Used to provide Stereo on conventional NTSC TV
  broadcast (TV has been FM mono for most of its
  history)

57
Television Transmission Systems
Over-the Air Terrestrial Broadcasting
58
Antenna Systems

• Radio Energy in Space
• 300 million meters per second
• E MC2
• Speed of Light

59
Spectrum
60
Wavelength

• Lambda (meters)
• Velocity (300,000,000 meters/sec.)
• Frequency (Hz)
• ? v/f

61
TV Station
WTHR-TV Ch.13 (210-216 MHz)

• WAVELENGTH IN
• Meters
• Miles
• Feet

WTHR-TV
62
WTHR Television - Channel 13 Indianapolis, Indian
a

• Channel 13 (210-216 MHz)
• 316 kw visual
• 63.2 kw aural
• 980t/1,039g
• Television Factbook
• 47 CFR 73.603

63
Wavelength Example WTHR Television
Meters Lambda 300/211.25 1.46 meters
Miles Lambda .186/211.25 .00088 miles
Feet 1 meter 3.28 feet Lambda 1.46 meters
x 3.28 4.79 feet
64
AM Station

• What is the height of this AM station antenna
  tower operating at 540 kHz, in meters and feet?

65
Propagation

• Radiation Patterns (Contours)
• AM - Tower as the Antenna
• FM/TV - Antenna on Tower

66
TV Propagation
67
TV Propagation Map
68
FM Propagation Map
KFMD-FM Denver
69
AM Tower
Side view
Top view
70
AM Directional Towers
71
AM Directional Propagation
72
Irregular Geographical Patterns

• Refraction
• Reflection
• Absorption
• Interference

73
Why Directional Arrays?

• Co-Channel
• Adjacent Channel
• Other

74
Types of Waves

• Direct Waves (FM/TV)
• Ground Waves (AM)
• Radials
• Swampy Soil vs. Sandy Terrain
• Sky Waves (AM at night)

75
Types of Waves
76
Direct Waves
The primary path of the direct wave is from the
transmitting antenna to the receiving antenna.
So, the receiving antenna must be located within
the radio horizon of the transmitting antenna.
Because direct waves are refracted slightly, even
when propagated through the troposphere, the
radio horizon is actually about one-third farther
than the line-of-sight or natural horizon.
77
Direct Waves
78
Ground Waves
The Earth has one refractive index and the
atmosphere has another, thus constituting an
interface that supports surface wave
transmission. These refractive indices are
subject to spatial and temporal changes.
79
Ground Waves
80
Sky Waves
Sky waves, often called ionospheric waves, are
radiated in an upward direction and returned to
Earth at some distant location because of
refraction.
81
Sky Waves
82
Questions and Answers
