Certificate and Key Storage Tokens and Software

1
Certificate and Key StorageTokens and Software

• Mark Swyers
• VeriSign, Inc.
• mswyers_at_verisign.com

2
Key Storage Considerations

• Many different ways to store a certificate and
  private key
• Application will usually dicatate the appropriate
  method
• Concerns include
• Security
• Portability
• Functionality
• Usability
• Managability
• Expense

3
Software-Based Certificates

• Several different software stores
• Microsoft CAPI
• Netscape certificate database
• Macintosh keyring
• Java keystores
• Vendor specific
• VeriSign Personal Trust Agent
• Pros
• Browser based, so easy to use
• Inexpensive
• no new infrastructure
• easy distribution
• Cons
• Locks user to desktop
• Desktop management
• Cannot control password use

4
PKI Tokens

• Generally provide greater security than software
  certificates
• Can require PINs or passwords, even biometric
  authenication
• Keys usually cannot be exported
• Tokens can be locked in a safe when not in use
• FIPS (Federal Information Protection Standard)
  140 rated
• Provide better portability than software
  certificates
• Can be used on multiple machines while
  maintaining only one copy of the private key
• Have the capcaity to hold multiple keys and
  certificates
• Challenges
• Typically require installation of drivers
• May require a separate reader
• End user acceptance
• Token lifecycle management distribution,
  forgotten/lost/broken tokens
• Cost

5
Smart Cards

• Can support multiple forms of access
• Physical access to building
• Logical access to workstation
• Can double as ID card
• Can print photo and other info
• Can support a magnetic stripe
• Requires a reader
• Contact or contactless (proximity)
• Examples
• FIPS 201 standard for HSPD-12
• DoD Common Access Card
• DOI Employee ID Cards
• University ID cards

6
USB Tokens

• Many form factors
• PKI only
• PKI with One-Time Password
• PKI with OTP and storage
• Easily portable
• Ensures tokens travel with user (i.e. when
  attached to car keys)
• Most computers have USB ports
• Better for consumers and when you dont have
  control over the user environment

7
VeriSign Approach Flexible Authentication
Platform
PKI-USB Token
Cost-Effective OTP
Multi-Function Token (OTP USB Smart Card)
Smart Card For Physical Network Access
VeriSign Unified Authentication
Multi-Function Token with Secure Storage
Mobile Devices
Soft Certificate And Soft OTP
Many Credential Types One Integrated Platform
One Strategic Vendor
