Bioinformatics Software

1
Bioinformatics Software
Stuart M. Brown Research Computing NYU School of
Medicine
2
BioinformaticsBeyond Websites

• A lot of sophisticated bioinformatics work can be
  done using free websites
• Some biology projects generate a LOT of data
• how we define a lot is a moving targetTB
• The only solution is to have a dedicated
  bioinformatics computer, database, and custom
  programs.
• May require more processor power and more hard
  drive space than a typical desktop personal
  computer

3
(No Transcript)
4
Computer Hardware is not Free

• However, you can build a powerful Linux cluster
  for 20-50-100K (depending on how much power
  you need)
• The big cost is for people with the skills to
  manage the machines, install the software, and
  train scientists to use it.
• Small schools can join together or affiliate with
  a larger neighbor.

5
Open Source Bioinformatics

• All of the bioinformatics software that you need
  to do complex analyses is free for UNIX computers
• The Open Source software ethic is very strong
  among biologists
• Bioinformatics.org
• Bioperl.org
• Open-bio.org
• BioConductor
• New algorithms generally appear first as free
  software (a publication requirement)

6
What is "Open Source?"

• Software distributed with source code under
  licenses guaranteeing anybody rights to freely
  use, modify, and redistribute the code.
• When users can read, redistribute, and modify the
  source code for a piece of software, the software
  evolves. People improve it, people adapt it,
  people fix bugs. User communities provide free
  tech support.

7
Open Source

• Free
• Users can see and change code
• Easy to modify add new functions
• Send changes back to developer - share with
  everyone - grows as a community
• Can be incorporated into other products
• Developers can lose interest - no guarantee of
  support

8
Popular Open Source Projects

• Linux
• Apache
• PHP
• mySQL
• Mozilla/Firefox
• OpenOffice
• Wiki

9
Science is Open Source

• Must publish results in a form that your work can
  be checked and recreated by others
• If your scientific work is a program then is
  must be open source

10
Free Software

• Linux operating system, mySYQL database
• Perl - programming language
• R, BioConductor - statistics package
• Blast and Fasta - similarity search
• Clustal - multiple alignment
• Phylip - phylogenetics
• Phred/Phrap/Consed - sequence assembly and SNP
  detection
• EMBOSS - a complete sequence analysis package
  created by the EMBL

11
Assemble your Own Bioinformatics computer

• We will install some bioinformatics tools in the
  CS computer room
• You will learn more if you install these tools on
  your own computer
• Every installation has its own style and its own
  hassles
• What tools will be needed?
• Interface?

12
Bioinformatics Requires Powerful Computers

• One definition of bioinformatics is "the use of
  computers to analyze biological problems.
• As biological data sets have grown larger and
  biological problems have become more complex, the
  requirements for computing power have also grown.
• Computers that can provide this power generally
  use the Unix operating system - so you must learn
  Unix

13
Why Unix?

• Bioinformatics applications are typically written
  in Unix
• It is the operating system of choice for high
  performance computers (multi-processor or
  clusters)
• Ability to use lots of software written by others
• Pipelining and database integration

14
Unix Runs the Internet

• Unix is a command line interface, used by most
  large, powerful computers.
• In fact, Unix is the underlying structure for
  most of the Internet and most large scale
  bioinformatics operations.
• A knowledge of Unix is likely to be helpful in
  your future career, regardless of where you
  pursue it.

15
When Do I Need Unix?

• Big sets of data
• Integrating raw data, results, and display
• Speed of large batch processing
• Integration of web server and database with
  automated data processing programs

16
Unix Advantages

• It is very popular, so it is easy to find
  information and get help
• pick up books at the local bookstore (or street
  vendor)
• plenty of helpful websites
• USENET discussions and e-mail lists
• most Comp. Sci. students know Unix
• Unix can run on virtually any computer (IBM,
  Sun, Compaq, Macintosh,etc)
• Unix is free or nearly free
• Linux/open source software movement
• RedHat, FreeBSD, MKLinux, LinuxPPC, etc.

17
Stable and Efficient

• Unix is very stable - computers running Unix
  almost never crash
• Unix is very efficient
• it gets maximum number crunching power out of
  your processor (and multiple processors)
• it can smoothly manage extremely huge amounts of
  data
• it can give a new life to otherwise obsolete Macs
  and PCs
• Most new bioinformatics software is created for
  Unix - its easy for the programmers

18
Unix has some Drawbacks

• Unix computers are controlled by a command line
  interface
• NOT user-friendly
• difficult to learn, even more difficult to truly
  master
• Hackers love Unix
• there are lots of security holes
• most computers on the Internet run Unix , so
  hackers can apply the same tricks to many
  different computers
• There are many different versions of Unix with
  subtle (or not so subtle) differences

19
Flavors of Unix

• Dec Alpha True64
• Sun Solaris SunOS
• IBM AIX
• HPUX
• DGUX
• Minix
• KNOPPIX
• Gentoo

• Linux
• Redhat/Fedora
• SuSe
• Mandrake
• Mandriva
• Slackware
• Debian

20
Linux is Unix

• Linux is a free (or cheap) operating system
• Works on any computer
• Increasingly popular for both desktops and
  servers
• It is an open implementation of Unix
• Uses all normal Unix commands
• Most new bioinformatics programs are written
  first for Linux

21
General Unix Tips

• UNIX is case sensitive!!
• myfile.txt and MyFile.txt do not mean the same
  thing
• I like to use capital letters for directory names
  - it puts them at the top of an alphabetical
  listing
• Every program is independent
• the core operating system (known as the kernel)
  manages each program as a distinct process with
  its own little chunk of dedicated memory.
• If one program runs into trouble, it dies, but
  does not affect the affect the kernel or the
  other programs running on the computer.

22
Shell scripts

• Part of the UNIX operating system
• a powerful program in a 3-line text file
• Very simple method to run an existing program on
  multiple files (foreach)
• Can chain together several programs (a pipeline)
• Can make simple decisions (if then)
• Can read output files and match patterns (grep)
• Can manipulate text files (sed awk)

23
Unix Help on the Web

• Here is a list of a few online Unix tutorials
• Unix for Beginners
• http//www.ee.surrey.ac.uk/Teaching/Unix/
• Getting Started in Unix
• http//its.ucsc.edu/services/web/unix/start.php
• Unix Guru Universe
• http//www.ugu.com/sui/ugu/show?help.beginners
• Getting Started With The Unix Operating System
  http//www.leeds.ac.uk/iss/documentation/be
  g/beg8/beg8.html

24
Standalone Tools

• BLAST - sequence similarity
• free from NCBI
• works on most operating systems
• versions for local, web client, web server
• EMBOSS - complete package of tools
• free from EMBL
• many handy little tools
• BioConductor - genomics/statistics
• free from BioConductor.org (requires "R" Java)
• works on most operating systems (best on Windows)

25
BLAST
26
EMBOSS

• EMBOSS is a suite of hundreds of simple programs
  that work with DNA and protein sequences
• Free UNIX software -works on Mac OS X
• -has a Windows implementation
• Somewhat challenging to download, compile, and
  configure
• Has web and Java interfaces

27
(No Transcript)
28

• transeq
• Translate nucleic acid sequences
• Input sequence(s) xelrhodop.fasta
• Output sequence xelrhodop.pep
• transeq -opt
• Translate nucleic acid sequences
• Input sequence(s) xelrhodop.fasta
• Translation frames
• 1 1
• 2 2
• 3 3
• F Forward three frames
• -1 -1
• -2 -2
• -3 -3
• 6 All six frames
• Frame(s) to translate 1 1
• Genetic codes
• 0 Standard

Minimalist Interface Fast, powerful Easy to
script (all options for all programs can be
input on command line)
29
(No Transcript)
30
(No Transcript)
31
Ugly EMBOSS on unix command line has now turned
into a beautiful Jemboss swan!
32
programs are highlighted based unambiguous letters
33
(No Transcript)
34
(No Transcript)
35
GDE - multiple alignment viewer
36
GDE - supports phylogenetic Apps. and graphics
37
Programming Languages

• Like religions
• Perl is the most commonly used language for
  simple bioinformatics apps.
• Really a fast prototyping language
• Useful for linking other programs and shell
  scripts
• SLOW compared to compiled languages
• C Java are used for many more polished programs

38
Perl

• Perl is a powerfull language
• convert file formats
• search a file for something you need
• change things in a file
• run a program and select just some lines of the
  output
• process your sequences
• build a pipeline that runs on many different
  systems
• Very powerful text handling
• has its own Regular Expression language

39
Compiled vs. Interpreted

• Perl is an Interpreted language
• A Perl program is just a bit of text with
  commands in a (semi) human readable form
• Must have a Perl Interpreter (program) on your
  computer to execute this program
• Can run on any operating system
• Very slow
• Compiled program language like C
• Executable program is a bunch of gibberish
• Can only run on one specific operating system
• Much faster

40
BioPerl

• Don't spend your time reinventing the wheel
• most types of bioinformatics data manipulations
  have been done before
• grab a module and go from there (there are
  hundreds of them)
• object oriented

41
Role of CS in Biology Project

• The CS Bioinformatics specialist works closely
  with biologists
• Provides consulting in project design
• collect the data in a way that makes it easy to
  analyze
• Works with biologists to establish scope of the
  project
• Chooses appropriate technologies
• Builds the programs/database and processes the
  data
• Works with biologists to produce data
  visualization/output that works for THEM!

42
Its all about the INTERFACE

• Biologists are (generally) visual wholistic
  thinkers
• A good tool needs a good interface
• Biologists will tolerate an essential tool with a
  lame interface, but it will dramatically reduce
  the quality of the science (and the utility of
  the tool)
• As we play with each bioinformatics tool this
  semester, think about the interface and how it
  aids or impedes your work.

43
UI Elements

• Most biologists are not comfortable with the
  command line
• A simple web form is vastly better than a command
  line tool
• Graphical display is better than text (although a
  text output option is also highly desirable)
• The Visual Display of Quantitative Information
• User feedback for navigation, runtime indicator,
  record of options used, etc. is also important

44

• The chart shows 6 variables
• size of the army
• location on a 2D surface
• direction of the army's movement
• Temperature
• location of major river crossings

45
(No Transcript)
46
Toolkits

• Existing bioinformatics tools and reference
  datasets are dispersed and uncoordinated
• Each scientist is required to discover or
  re-invent appropriate tools for their data
  analysis
• Toolkits are extremely useful when they group
  related tools with a common interface

47
(No Transcript)
48
(No Transcript)
49
Project Mangement

• Building the project
• Basic Unix
• Databases
• Shells
• Pipelining / Scaling
• Basic BioPerl / BioJava / Obj.Oriented
  Programming
• Translating Biology to IT
• Integration
• Publishing / Managing the Project
• Data Security

50
BIG DATA
51
New Technology Big Data

• The past 2-3 years have seen a huge increase in
  the size of data files generated in scientific
  projects
• This has been driven entirely by new
  technologies
• High-throughput (Next-Generation) DNA sequencing
• Genome tiling chips
• High density SNP chips

52
Computing Challenges

• There are many practical challenges associated
  with very large data files
• Data storage for TB of laboratory information
• Cant easily manipulate millions of records in
  traditional sql databases
• Difficult to run Perl scripts on data files
  millions of lines long

53
Need massive new CPU power

• Traditional software/algorithms may not run on
  clusters (MPI challenges)
• Biologists are not parallel computing programming
  experts
• Familiar bioinformatics skills/tools run into
  roadblocks of scale
• Whats old is new again (hello to grep, sed, awk,
  etc)

54
New technology enables new science

• Just like a new microscope, the development of
  these new big data technologies are creating
  opportunities for new kinds of science
• Quantitative changes in technology enable
  qualitative changes in science
• Chip-seq, Transcript profiling
• Metagenomics
• Genome Wide Association

55
Biology is a big new market for computing vendors

• Compute Clusters
• Storage
• LIMS databases
• MPI compliant bioinformatics tools
• Consultants and 3rd party VARs
• Job opportunities for bioinformatics-savvy CS
  people.
