What is TEMS Pocket?

• Portable Air Interface Test Tool

• Combines a regular phone and an advanced test
  tool in one device

• Captures network information wherever the user
  goes

• Measurement capabilities always ready and
  available

3
Who can use TEMS Pocket?

• RF engineers
• For detailed analysis of TEMS data in the field
• Network operations/rollout staff
• For site acceptance, verification of changes
• Sales force
• For capturing network status information
  as part of daily work

• Management
• For easy and accurate visualization
  of network quality

• Customers
• For automatic monitoring of quality from
  end-user perspective and SLA monitoring

The entire organization can use TEMS Pocket!
4
Benefits of TEMS Pocket

• Saves time and money on tool setup
• Promotes convenient measurement with a portable
  size

• Tests network from a users perspective
• Collects and transfers information for faster
  results

• Increases Operational Excellence

TEMS Pocket is a complete tool for data
collection and troubleshooting throughout your mo
bile network
5
Get the most from your TEMS Investment

• TEMS Pocket allows best use of all your TEMS
  tools

• Expands TEMS Automatic investment with new
  probes

• Fully integrates with TEMS Automatic no
  modifications needed

• Complete compatible with TEMS Presentation (Post
  Processing Solution)

• Compatible with TEMS Investigation
• Logfile replay

TEMS Pocket is the future of measurement probes
6
TEMS Pocket packages

• TEMS Pocket Classic
• Local control
• Data views for real-time monitoring
• Command sequence
• Easy-to-use engineering tool
• TEMS Pocket Professional
• Extends TEMS Pocket Classic with
• Data collection
• Positioning of data
• Upload of logfiles
• Provides testing capabilities for the
• professional RF engineer
• TEMS Pocket Remote
• Remote monitoring tool
• Remotely controlled from TEMS Automatic
• Fully integrated solution
• Phone user undisturbed by testing
• Collection tool for anyone

7
Focus for TEMS Pocket

• Continuous concentration on new devices and
  platforms

• Close cooperation with phone development
• Ease of use
• Remote administration, using scripts for
  testing

• Appropriate form factor for indoor and walkabout
  measurements

TEMS Pocket The way to go!
8
Whats new in TEMS Pocket?

• Support for Nokia N95 with TEMS Pocket
  Professional

• Graph monitor
• User configurable
• Integrated in view system for seamless operation
• GPS positioning
• Allows use of integrated or external GPS
• New data views
• HSDPA
• GSM BA list, AMR view
• FTP Application data
• Command sequence
• Lets TEMS Pocket perform measurements
  while you drive

• Mixed actions in sequence
• Voice
• FTP
• Idle

TEMS Pocket covers more devices!
9
TEMS Pocket Classic and TEMS Pocket Professional
10
TEMS Pocket Classic and TEMS Pocket
Professional Overview

• Ideal tool for all RF engineers
• Detailed analysis and troubleshooting in the
  field

• Network optimization
• Initial site acceptance
• Extremely powerful
• Real-time presentation of network information
• Logging capability with positioning
• Transfer of data to office for quick approvals
• Fully integrated with phone device
• Seamless operation
• Easy to use and configure
• On-screen help functions

11
TEMS Pocket Classic and TEMS Pocket Professional

• Available devices
• TEMS Pocket Classic
• Sony Ericsson K790i
• Sony Ericsson K800i
• TEMS Pocket Professional
• Sony Ericsson Z750i
• Nokia N95 (EU/US)

12
Phone capabilities
13
TEMS Pocket ClassicKey features

• Data views
• Information presented clearly
• Detailed help functions
• Network events
• Abnormal behaviors highlighted with audio and
  counters

• Cell control
• Forces phone behavior
• Command sequence
• Lets TEMS Pocket perform measurements while you
  drive

Let TEMS Pocket do the testing
14
TEMS Pocket ProfessionalKey features

• Includes all TEMS Pocket Classic features
• Logfile handling
• Facilitates in-depth data analysis in the field
  or in the office

• FTP client
• Enables automated data testing and data transfer
• GPS positioning
• Allows use of integrated or external GPS

TEMS Pocket captures a view of your network
15
TEMS Pocket Data views

• Designed and organized for ease of use
• Monitoring of real-time data
• Key information about serving cells
  always visible

• Control functions available in views
• Context-sensitive help

16
TEMS PocketNetwork events

• Event alerts about important states and failures
• Events can be connected with audio and icons
• Event Log
• Displays a short description of every event
• Counters for events available

17
TEMS PocketCell control

• Use control functions to verify network coverage


• Simply select cell control menu actions
• Lock to RAT
• Lock Cell WCDMA
• Lock ARFCN GSM
• Lock to Band GSM
• Lock to Band WCDMA
• Voice Codec GSM
• HS capability
• Ignore cell barred
• Reset of control settings to default Off state

Subject to phone capability
18
TEMS PocketAutomated command sequence

• Useful for no-hands testing
• Voice or video call sequence
• Number to dial
• Duration of call
• Guard time between calls
• FTP data sequence
• Configures Put/Get actions
• File sizes
• Server configurations
• Manual testing of services such as
• SMS
• MMS
• WAP/HTTP
• E-mail
• Streaming

19
TEMS Pocket Professional package Logfile handling

• Air interface information recorded
  in the handset using phone memory or
  memory card

• Local replay on the phone device for
  fast and easy troubleshooting

• Manual or automated logfile capture and
  upload

• Air interface information with detail level as
  in other TEMS tools


20
TEMS Pocket Professional package GPS support

• Integrated GPS means one device for user
• Additional license for external Bluetooth GPS
• Connect Bluetooth GPS devices supporting NMEA
• Pairing is done through standard Bluetooth menu
• Choose manual or automatic connection
• GPS position stored in logfile
• View to show GPS-related information

21
TEMS Pocket Remote

• Measurement probe in TEMS Automatic

22
TEMS Pocket Remote Overview

• User undisturbed by testing
• Remotely configurable and controlled
  from Operator Console

• Automated test execution
• Work order handling
• Automated data upload
• Can be scheduled
• Acts as an additional measurement probe
• For areas that are hard to reach
  with drive testing

Autonomous measurement probe
23
TEMS Pocket Remote Available devices

• TEMS Pocket Remote
• Sony Ericsson Z750i
• Multiple technologies in one device
• WCDMA/HSDPA 850/1900/2100 MHz
• GSM/GPRS/EDGE 850/900/1800/1900 MHz
• Integrated GPS Bluetooth GPS
• Control functions
• Remote control of phone behavior
• Upload control
• Remote control when probe uploads measurements
• Command sequence
• Voice
• FTP
• E911

TEMS Pocket Remote listens to your network
24
Everyone can use TEMS Pocket Remote

• Serves as an everyday phone
• Ideal for SLA monitoring
• Captures network information where your customers
  are

Measure wherever you are
25
What makes TEMS
Pocket Remote unique?

• Autonomous probe with minimal setup
• Fully remote controlled
• No user interaction needed
• Integrated into proven concept
• Information is log-compatible
  with TEMS tools


TEMS Pocket Remote does the work
26
(No Transcript)
27
TEMS Pocket evolution roadmap

• TEMS Pocket
• Any device
• Any user
• Remote activation
• Benchmarking
• Linked devices

• TEMS Pocket
• New platform
• Scanner
• Remote delivery
• Service testing
• Multimedia focus
• Questionaries
• LTE

• TEMS Pocket
• New devices
• Replay logfiles
• Map tool
• Graph tool
• Script controlled test
• Compressed upload
• System integration
• Speech quality MOS
• HSPA

• TEMS Pocket
• Dataview
• GPS
• Recording
• Upload

Current 2008 2009 Vision
28
TEMS Pocket Packaging

• Classic (data views, voice call testing, control
  functions)

• Professional (Classic upload, recording,
  replay, TEMS Investigation integration)

• Remote (a.k.a. HTU, remote controlled from TEMS
  Automatic)

• Premium
  (TEMS Professional
  TEMSRemote new features)

29
TEMS Pocket 6.0 for SEMC Z750iExecutive summary

• Data session view
• Present application data information
• Replay logfile
• Makes it possible to locally replay information
  recorded in TEMS Pocket device

• Improved call sequence
• Configuration of FTP and voice testing nodes made
  easier to handle

• Built in GPS
• Support SEMC Z750i with integrated GPS receiver.
  Still possible to use external Bluetooth GPS for
  high sensitivity and accuracy of positioning
  values
• Support for HSDPA
• TEMS Pocket 6.0 now supports HSDPA capabilities
  and a new separate data view


30
TEMS Pocket 6.2 for SEMC Z780iExecutive summary

• Support for band IV for T-Mobile
• Special version only for T-Mobile US

31
TEMS Pocket 6.3 for SEMC C702/W760Executive
summary

• Compressed Upload
• Gives the option to select compressed upload to
  reduce data transfer time to backend

• Export/Import settings
• Makes it possible to easily transfer settings
  between TEMS Pocket devices to share the same
  configuration

• Improved system integration
• Makes it easier to identify TEMS Pocket
  information when imported into TEMS Automatic
  database

• New devices
• Support for new SEMC C702 (dustproof and
  waterproof) and W760

• License handling
• Gives the opportunity to easily add functions in
  field

• SQI MOS voice quality measurement
• Generates MOS values correlated to PESQ for voice
  calls

• Initial configuration
• Simplifies initial configuration for TEMS Pocket
  Remote

• Multi language support
• Support for simplified Chinese
• Active HTTP
• Active testing of HTTP for TEMS Pocket Remote

32
TEMS Pocket 7.0 for SEMC C905Executive summary

• Map tool
• Includes indoor measurement option in TEMS
  Pocket

• Graph tool
• Adds pre-configured line chart to TEMS Pocket
• HSUPA
• Introduction of HSUPA devices
• WLAN View
• Simple view for WLAN information
• Streaming testing
• Possible to generate measurement sequence with
  streaming media

33
TEMS Pocket 7.2 for SEMC TBAExecutive summary

• HSUPA
• WCDMA
• 900/2100, 1700/2100, 850/1900/2100
• Slider
• GPS
• Passive measurements
• Captures measurements on user calls in TEMS
  Pocket Remote

• Command Sequence Enhancement
• Captures measurements on user calls in TEMS
  Pocket Remote

• Scanner functions
• Scanner mode in TEMS Pocket Professional

34
TEMS Pocket for SEMC Rel W Executive summary

• Scanner measurement
• Adds scanner functionality to the phone device
• Linked devices
• Makes it possible to connect several devices
  into one
  synchronized measurement unit

• New platform
• New platform
• Event based logging
• Only does logging based on user events

35
TEMS Pocket 6.1 for Nokia N95Executive summary

• Nokia N95 upgrade
• Offer upgrades to existing Nemo customers
• Graph monitor
• Catch up existing SEMC function
• Command sequence
• New data views

36
TEMS Pocket 7.0 for Nokia N96Executive summary

• New device
• Nokia N96
• Map tool
• Indoor measurements
• Compressed data upload
• Makes it possible to do effective data upload
• Save/restore settings
• Transfers settings between devices
• Control functions
• WCDMA band
• HSDPA capabilities
• GSM Vocoder control
• WCDMA Vocoder control

37
TEMS Pocket 7.1 for Nokia N96Executive summary

• DVB-H Support
• DVB-H views

38
(No Transcript)
