Volume Rendering Hardware

1
Volume Rendering Hardware

• Anselmo Lastra

2
Volume Pro

• Single-chip volume renderer
• Meant for real time
• Was commercial product
• H. Pfister, J. Hardenbergh, J. Knittel, H. Lauer,
  and L. Seiler, The VolumePro Real-Time
  Ray-Casting System, Proceedings of ACM SIGGRAPH
  99, 251-260, Los Angeles, CA, August 1999

3
Shear Warp Image

• Voxels read in slices

4
Block Diagram

• Data read only once per frame
• 8 or 12-bit scalars
• Tri-linear interp
• Gradient block buffers 2 slices
• Classification by lookup table to RGBA
• Images sent to regular VGA card

5
Chip

• Chip had 4 pipelines
• 2563, 30 Hz

6
GI-Cube

• Global illumination for volumes
• Architecture paper from SUNY Stony Brook
• Frank Dachille, Arie Kaufman, GI-cube an
  architecture for volumetric global illumination
  and rendering , Graphics Hardware 2000

7
Examples
8
Algorithm

• Two pass
• Rays from lights to volume faces, with k
  supersamples
• These distribute energy through volume
• Rays from eye
• Rays can be transmitted, absorbed or scattered

9
Machine Block Diagram
10
Block Processor

• Scattering uses BRDF to change ray direction
• If simple, done on hardware if complex, sent to
  software
• I assume software means the PC, not the DSP

11
Queues

• Enough queues for all blocks
• For 2563 volume with 323 block size, 128 queues
  over 4 processors
• Queue Overflow
• Rays sent to DSP
• They say this is OK because it means theres
  enough work at block processor anyway

12
Queue Importance

• Pipelined insertion sorter

13
Redistribution Scheme

• Works well for this volume because space is
  bounded
• Known number of bins
• Can the same thing be done for conventional ray
  tracer?

14
Also

• Vizard and Vizard 2 systems from Tuebingen
• FPGA based
