Seamless Flux Cored Wire

1
SeamlessFlux Cored Wire
NITTETSU SF/SM series
2
What is Seamless FCW ?
3
Production of Seamless FCW
Vibration flux filling process ltUntil 1998gt
Drawing
Drawing
Copper plating
Flux filling by vibration
Dehydrogenation annealing
Spooling
Pipe
Intermediate size
Product size (1.22.0f)
4
New Production Process of NSSW
Inline-Continuous-flux-Filling process (ICF)
Roll forming
Seam welding (ERW)
Flux filling
Strip
?
Welding
Dehydrogenation annealing
Copper plating
Spooling
Drawing
Drawing
5
ICF Process
6
Story of our Seamless FCW
1981 Start of NITTETSU SF-1 1991 Started
operation H-ICF (Hikari plant) 1998 Started
operation N-ICF1(Narashino plant) 2008 Started
operation N-ICF2(Narashino plant)
Three ICF production lines are expected to
supply seamless FCW toward all of the world
7
The Biggest Seamless FCWsales supplier
Sales of Seamless FCW in 2008
8
Performances of NITTETSU Seamless FCW
9
Feat.1Ultra-low hydrogen can be achieved
Because of Seamless
No open gap in the wire
Dehydrogenation annealing process
Copper plating
Ultra-low diffusible hydrogen FCW
10
Feat.2Moisture absorption can be prevented
Steel sheath
Flux
NITTETSU SF-60
Keeping HD after unpacking
11
Feat.3Rust can be prevented
Fold type (No copper plating)
Seamless (Copper plated)
Easy storage
12
Feat.4Low temp. cracking can be prevented easily
Seamless FCW

• Dehydrogenation process
• No moisture absorption
• High rust prevention property

13
Relation between critical preheat temp. and weld
metal diffusible hydrogen
y-groove weld cracking test
Seamless can decrease preheat temp.
Critical preheat temperature (deg.C)
Yurioka, Kasuya Quarterly Journal of Japan
Welding Society,Vol.13 No.3, pp347-357 (1995)
Weld metal diffusible hydrogen (ml/100gr)
14
Investigation of targeting performance
(Wire dia.1.2mm palepack, straight torch,
Ext.150mm )
15
Feat.5Targeting point is extremely stable
16
Feat.6Less tip abrasion
(Circumscribed circle of tip hole after
welding) (Diameter of the tip hole before
welding)
17
Sales of NSSWs Seamless FCW
Over 3,000 ton/month
18
Advanced Technology in Regard to Steel and
Welding Materials for Customers
Anti-low temp. cracking property
Ultra-low hydrogen process
Rust prevention
No moisture absorption
excellent targeting performance
Less tip abrasion
