Tight Coupling between ASR and MT in Speech-to-Speech Translation

1
Tight Coupling between ASR and MT in
Speech-to-Speech Translation

• Arthur Chan
• Prepared for
• Advanced Machine Translation Seminar

2
This Seminar

• Introduction (6 slides)
• Ringgers categorization of Coupling between ASR
  and NLU (7 slides)
• Interfaces in Loose Coupling
• 1 best and N-best (5 slides)
• Lattices/Confusion Network/Confidence Estimation
  (12 slides)
• Results from literature
• Tight Coupling
• Theory
• Some As Is Ideas on This Topic

3
6 papers on Tight Coupling of Speech-to-Speech
Translation

• H. Ney, Speech translation Coupling of
  recognition and translation, in Proc. ICASSP,
  1999.
• Casacuberta et al., Architectures for
  speech-to-speech translation using finite-state
  models, in Proc. Workshop on Speech-to-Speech
  Translation, 2002.
• E. Matusov, S.Kanthak, and H. Ney, On the
  integration of speech recognition and statistical
  machine translation, in Proc. InterSpeech,
  2005.
• S.Saleem, S. C. Jou, S. Vogel, and T. Schultz,
  Using word lattice information for a tighter
  coupling in speech translation systems, in Proc.
  ICSLP, 2004.
• V.H. Quan et al., Integrated N-best re-ranking
  for spoken language translation, in In
  EuroSpeech, 2005.
• N. Bertoldi and M. Federico, A new decoder for
  spoken language translation based on confusion
  networks, in IEEE ASRU Workshop, 2005.

4
A Conceptual Model of Speech-to-Speech Translation
Speech Recognizer
Machine Translator
Speech Synthesizer
Decoding Result(s)
Translation
waveforms
waveforms
5
Motivation of Tight Coupling between ASR and MT

• One best of ASR could be wrong
• MT could be benefited from wide range of
  supplementary information provided by ASR
• N-best list
• Lattice
• Sentenced/Word-based Confidence Scores
• E.g. Word posterior probability
• Confusion network
• Or consensus decoding (Mangu 1999)
• MT quality may depend on WER of ASR (?)

6
Scope of this talk.
Speech Recognizer
Machine Translator
Speech Synthesizer
1-best?
Translation
N-best?
waveforms
waveforms
Lattice?
Confusion network?
7
Topics Covered Today

• The concept of Coupling
• Tightness of coupling between ASR and
  Technology X. (Ringger 95)
• Interfaces between ASR and MT in loose coupling
• What could ASR provide?
• System with Semi-tight coupling
• Very tight coupling
• Neys formulae
• Casacubertas Approach
• Some random thoughts for this topic.
• What is missing in the current research?

8
Topics not covered

• Direct Modeling
• Use both features in ASR and MT
• Some referred as ASR and MT unification
• Implication of the MT search algorithms on the
  coupling
• Generation of speech from text.
• Presenter doesnt know enough.

9
The Concept of Coupling
10
Classification of Coupling of ASR and Natural
Language Understanding (NLU)

• Proposed in Ringger 95, Harper 94
• 3 Dimensions of ASR/NLU
• Complexity of the search algorithm
• Simple N-gram?
• Incrementality of the coupling
• On-line? Left-to-right?
• Tightness of the coupling
• Tight? Loose? Semi-tight?

11
Tightness of Coupling
Tight
Semi-Tight
Loose
12
Notes

• Semi-tight coupling could appear as
• Feedback loop between ASR and Technology X for
  the whole utterance of speech
• Or Feedback loop between ASR and Technology X for
  every frame.
• The Ringger system
• A good way to understand how speech-based system
  is developed

13
Example 1 LM

• Someone asserts that ASR has to be used with
  13-grams.
• In tight-coupling,
• A search will be devised to search for the best
  word sequence with best acoustic score 13 gram
  likelihood
• In loose coupling
• A simple search will be used to generate some
  outputs (N-best list, lattice etc.),
• 13-gram will then use to rescore the output.
• In semi-tight coupling
• 1, A simple search will be used to generate
  results
• 2, 13 gram will be applied at the word-end only
  (but exact history will not be stored)

14
Example 2 Higher order AM

• Segmental model assume obs. probability is not
  conditionally independent.
• Someone assert that segmental model is better
  than just HMM.
• Tight coupling Direct search of the best word
  sequence using segmental model.
• Loose coupling Use segmental model to rescore
• Semi-tight coupling Hybrid HMM-Segmental model
  algorithm?

15
Summary of Coupling between ASR and NLU
16
Implication on ASR/MT coupling

• Generalize many systems
• Loose coupling
• Any system which uses 1-best, n-best, lattice, or
  other inputs for 1-way module communication
• (Bertoldi 2005)
• CMU System (Saleem 2004)
• (Matusov 2005)
• Tight coupling
• (Ney 1999)
• (Casacuberta 2002)
• Semi-tight coupling
• (Quan 2005)

17
Interfaces in Loose Coupling1-best and N-best
18
Perspectives

• ASR outputs
• 1-best results
• N-best results
• Lattice
• Consensus network.
• Confidence scores
• How ASR generate these outputs?
• Why they are generated?
• What if there are multiple ASRs?
• (and what if their results are combined?)

19
Origin of the 1-best.

• Decoding of HMM-based ASR
• Searching the best path in a huge HMM-state
  lattice.
• 1-best ASR result
• The best path one could find from backtracking.
• State Lattice (Next page)

20
(No Transcript)
21
Note on 1-best

• Most of the time 1-best Word Sequence
• Why?
• In LVCSR, storing the backtracking pointer table
  for state sequence takes a lot of memory (even
  nowadays)
• Compare this with the number of frames of score
  one need to be stored
• Usually a backtrack pointer storing
• The previous words before the current word
• Clever structure dynamically allocate
  back-tracking pointer table.

22
What is N-best list?

• Traceback not only from the 1st -best, also from
  the 2nd best and 3rd best, etc.
• Pathway
• Directly from search backtrack pointer table
• Exact N-best algorithm (Chow 90)
• Word pair N-best algorithm (Chow 91)
• A search using Viterbi score as heuristic (Chow
  92)
• Generate lattice first, then generate N-best from
  lattice

23
Interfaces in Loose CouplingLattice, Consensus
Network and Confidence Estimation
24
What is Lattice?

• A compact representation of state-lattice
• Only word node (or link) are involved
• Difference between N-best and Lattice
• Lattice could be compact representation of N-best
  list.

25
(No Transcript)
26
How lattice is generated?

• From the decoding backtracking pointer table
• Only record all the links between word nodes.
• From N-best list
• Become a compact representation of N-best
• Sometimes spurious link will be introduced

27
How lattice is generated when there are phone
contexts at the word end?

• Very complicated when phonetic context is
  involved
• Not only word-end needs to be stored but also the
  phone contexts.
• Lattice has the word identity as well as contexts
• Lattice can become very large.

28
How this is resolved?

• Some used only approximate triphone to generate
  lattice in first stage (BBN)
• Some generate lattice even with full CD-phones
  but convert it back to no-context lattices (RWTH)
• Use the lattice with full CD phone contexts
  (RWTH)

29
What ASR folks do when lattice is still too large?

• Use some criteria to prune the lattice.
• Example Criteria
• Word posterior probability
• Application of another LM or AM, then filtering.
• General confidence score
• Maximum lattice density
• (number of words in lattice/number of words)
• Or generate an even more compact representation
  than lattices
• E.g. consensus network.

30
Conclusions on lattices

• Lattice generation itself could be a complicated
  issue
• Sometimes, what post-processing stage (e.g. MT)
  will get is pre-filtered, pre-processed results.

31
Confusion Network and Consensus Hypothesis

• Confusion Network
• Or Sausage Network.
• Or Consensus Network

32
Special Properties (?)

• More local than lattice
• One can apply simple criteria to find the best
  results
• E.g. consensus decoding is to apply
  word-posterior probability on confusion network.
• More tractable
• In terms of size
• Found to be useful in
• ?
• ?

33
How to generate consensus network?

• From the lattice
• Summary of Mangus algorithm
• Intra-word clustering
• Inter-word clustering

34
Note on Consensus Network

• Note
• Time information might not be preserved in
  confusion network
• The similarity function directly affect the final
  output of the consensus network.

35
Other ways to generate confusion network

• From the N-best list
• Using Rover.
• A mixture of voting and adding confidence of word

36
Confidence Measure

• Anything other than likelihood which could tell
  whether the answer is useful
• E.g.
• Word posterior probability
• P(WA)
• Usually compute using lattices
• Language model backoff mode
• Other posterior probabilities (frame, sentence)

37
Interfaces in Loose CouplingResults from the
Literature
38
N-best list
39
Lattices CMU results (Saleem 2004)

• Just Put some graphs here.

40
Consensus Network
41
Confidence Does it help?
42
Tight Coupling
43
Motivation
44
Theory (Ney 1999)
Bayes Rule
Introduce f as hidden var.
Bayes Rule
Assume x doesnt depend on target lang.
Sum to Max
45
Layman point of view
46
Later Approaches
47
Casacuertas Approach
48
Some As Is Ideas on This Topic
49
The End. Thanks.
50
(No Transcript)
51
Literature

• Eric K. Ringger, A Robust Loose Coupling for
  Speech Recognition and Natural Language
  Understanding, Technical Report 592, Computer
  Science Department, Rochester University, 1995
• The ATT paper
