Chapter 15 Chromosomal Basis of Inheritance

1
Chapter 15 Chromosomal Basis of Inheritance
2
1902

• Walter Sutton
• Theodor Boveri
• Etc
• Noted parallels between chromosomes and Mendels
  factors
• CHROMOSOME THEORY emerged
• Mendelian genes have specific loci on chromosomes
  and it is the chromosomes that undergo
  segregation and independent assortment (see page
  270)

3
Figure 15.1 The chomosomal basis of Mendels laws
4
Linked genes

• Number of genes in a cell is FAR greater than the
  number of chromosomes
• Linked genes are genes that are located on the
  same chromosome and that tend to be inherited
  together
• Inheritance patterns with linked genes tend to
  deviate from expected Mendelian ratios
• Morgan first to trace a gene to a specific
  chromosome

5
Figure 15.4 Evidence for linked genes in
Drosophila
Pages 272 and 273
6
Genetic recombination

• General term for the production of offspring with
  new combinations of traits inherited from two
  parents
• Organisms that have these are called
  recombinants

7
Figure 15.5a Recombination due to crossing over
Page 274
8
Figure 15.5b Recombination due to crossing over
9
Geneticists can use recombination data to map a
chromosomes genetic loci

• Method discovered by Alfred Sturtevant
• Called a genetic map (linkage map) an ordered
  list of the genetic loci along a particular
  chromosome
• Assuming that cross-over possibility is
  approximately equal at all points on a
  chromosome, the further apart two genes are, the
  HIGHER the probability that a cross-over will
  occur between those two genes the higher the
  recombination frequency
• Map units are called centimorgans in honor of
  Thomas Hunt Morgan

10
Figure 15.6 Using recombination frequencies to
construct a genetic map
b body color cn cinnabar eyes (brighter
red) vg wing size
11
Figure 15.7 A partial genetic map of a
Drosophila chromosome
12
Figure 15.8 Some chromosomal systems of sex
determination
Page 276
13
Sex-linked genes

• Show up more often in the sex that has only one
  copy of the X- chromosome
• Human examples
• -Duchenne muscular dystrophy
• -Hemophilia

14
X-Inactivation in Female Mammals

• Only one X chromosome stays active in females
  other becomes inactivated during embryonic
  development.
• The inactive X in each cell of a female condenses
  into a compact object a Barr body
• Barr body chromosomes are reactivated in the
  ovary cells that give rise to ova
• See page 278-279 and discussion of tortoiseshell
  cat
• XIST is a gene that is active ONLY on the
  Barr-body chromo

15
Figure 15.10 X inactivation and the
tortoiseshell cat
Mary Lyon and the inheritance of inactivation
page 278
16
Two types of mutations

• Gene mutations affect only one base or point on
  a gene
• a. substitution
• b. deletion
• c. insertion
• Chromosome mutations affect large sections of
  genes
• alterations in numbers of chromosomes
  nondisjunction resulting in aneuploidy
• a. monosomy
• b. trisomy
• c. polyploidy
• alterations in size of chromosomes
• a. deletion
• b. inversion
• c. translocation (reciprocal or
  non-reciprocal)
• d. duplication

17
Gene MutationsSubstitution, Insertion, and
Deletion
Section 12-4
Deletion
Substitution
Insertion
Gene Mutations only affect ONE point of the code
-- often called Point Mutations
Go to Section
18
Figure 15.13 Alterations of chromosome structure
19
Figure 15.11 Meiotic nondisjunction
20
Figure 15.14 Down syndrome
21
Figure 15.x3 XYY karyotype
22
Human Genetic anomalies

• Autosomal Dominant Genes body cells, not passed
  on to offspring
• Autosomal Recessive Genes body cells, not
  passed on to offspring
• X-linked recessive Genes sex cells, passed on
• Y-linked only in males
• Chromosomal Abnormalities if affects sex
  chromos, passed on
• Multifactorial genetic component (gene or
  chromosome) plus a significant environmental
  influence

23
Final notes

• Not all of a eukaryotic cells genes are located
  in the nucleus
• Extranuclear genes are found in mitochondria and
  chloroplasts, too!
• These cytoplasmic genes do not display Mendelian
  inheritance because are not distributed evenly as
  happens in nucleus
• 1909 Karl Correns studied variegated leaves in
  tomato plants
• Mitochondrial DNA comes from Mom maternal
  inheritance, because mitochondria passed on by
  zygote all come from the cytoplasm of the ovum
