Rectification

1

• Rectification

2
AC to DC

• Electricity distribution
• Power stations
• Transformers
• Transmission lines
• AC
• Electronics
• DC
• Smooth
• Stable

3
Process of rectification

• Conversion of AC to DC
• Half-wave
• Full-wave
• Dedicated circuits
• Contain diodes
• Semiconductor
• Thermionic
• Power rating
• Supply current to circuits

4
Half-wave rectification

• Only the positive half-cycle of the AC supply is
  allowed to pass

5
Half-wave rectifier circuit

• Simple!
• Single diode
• Load
• DC circuitnot really getting DC!

6
Full-wave rectification

• Positive AND negative half-cycles converted to
  ALL positive

7
Full-wave rectifier circuit

• Bridge circuit
• Load
• Circuit requiring DC

8
Bridge as two potential dividers
Vout
9
Capacitative smoothing
10
Smoothed output

• Un-smoothed
• Large ripple voltage
• Not true DC
• Low-value smoothing capacitor
• RloadC small
• High-value smoothing capacitor
• RloadC big

11
www.search for...

• Capacitors
• Rectification
• PSU
• Electronic power supplies
• Bridge rectifiers
