Follow the Water Part 3

1
Follow the Water (Part 3)

• Lecture 11
• Limits of the Habitable Zone. Climate Feedbacks.

2
From Last Lecture

• Habitable zone (HZ) is defined as the range of
  distances from a star for which liquid water can
  exist on a planetary surface.
• Under the present Earths atmospheric pressure (1
  atm 101325 Pa) water is stable if the surface
  temperature is 273 K (freezing) lt Ts lt 373 K
  (boiling)

3
Boundaries of the HZ(without climate feedbacks)

• Inner boundary 0.56 AU
• Outer boundary 1.13 AU

4
Global surface temperature (Ts)

• Global surface temperature (Ts) depends on three
  main factors
• Solar flux
• Albedo (on Earth mostly clouds)
• Greenhouse Effect (CO2, H2O , CH4, O3 etc.)
• We can calculate Te (effective temperature) or
  Trad (radiative temperature) from the Energy
  balance equation and add the greenhouse warming
• Ts Te ?Tg

5

• But! The amount of the atmospheric greenhouse
  warming (?Tg) and the planetary albedo can change
  as a function of surface temperature (Ts) through
  different feedbacks in the climate system.

6
Climate System

• We can think about climate system as a number of
  components (atmosphere, ocean, land, ice cover,
  vegetation etc.) which constantly interact with
  each other.
• There are two ways components can interact
  positive and negative couplings

7
Systems Notation
system component
positive coupling
negative coupling
8
Positive Coupling
Cars speed
Cars gas pedal
Body weight
Amount of food eaten

• A change in one component leads to a change of
  the same
• direction in the linked component

9
Negative Coupling
Cars speed
Cars break system
Body weight
Exercise

• A change in one component leads to a change of
  the opposite
• direction in the linked component

10
Positive Coupling
Atmospheric CO2
Greenhouse effect

• An increase in atmospheric CO2 causes
• a corresponding increase in the greenhouse
• effect, and thus in Earths surface
  temperature
• Conversely, a decrease in atmospheric CO2
• causes a decrease in the greenhouse effect

11
Negative Coupling
Earths albedo (reflectivity)
Earths surface temperature

• An increase in Earths albedo causes a
• corresponding decrease in the Earths surface
• temperature by reflecting more sunlight back to
• space
• Or, a decrease in albedo causes an increase in
• surface temperature

12
Feedbacks

• In nature component A affects component B but
  component B also affects component A. Such a
  two-way interaction is called a feedback loop.
• Loops can be stable or unstable.

B
A
13
NOT A Harmonious Family
positive coupling
parents anger
childrens noise
positive coupling
street noise
A positive feedback loop Unstable system which
changes further following a perturbation
14
A Harmonious Family
positive coupling
parents anger
childrens noise
negative coupling
street noise
A negative feedback loop Stable system which
resists change following a perturbation
15

• Negative feedback loops have an odd number of
  negative couplings within the loop.

16
Climate Feedbacks
Water Vapor Feedback
17
Snow and Ice Albedo Feedback
18
The IR Flux/Temperature Feedback
Short-term climate stabilization
19
In a typical glaciation ice stops growing
because of the IR Flux/Temperature Feedback
20
The Carbonate-Silicate Cycle
(metamorphism)
Long-term climate stabilization
21

• CaSiO3 CO2 ? CaCO3 SiO2 (weathering)
• CaCO3 SiO2 ? CaSiO3 CO2 (metamorphosis)

22
Negative Feedback Loops
The carbonate-silicate cycle feedback
Rainfall
Surface temperature
Silicate weathering rate
(-)
Atmospheric CO2
Greenhouse effect
23
The inner edge of the HZ

• The limiting factor for the inner boundary of the
  HZ must be the ability of the planet to avoid a
  runaway greenhouse effect.
• Theoretical models predict that an Earth-like
  planet would convert all its ocean into the water
  vapor 0.84 AU
• However it is likely that a planet will lose
  water before that.

24
Moist Greenhouse

• If a planet is at 0.95 AU it gets about 10
  higher solar flux than the Earth.
• Increase in Solar flux leads to increase in
  surface temperature ? more water vapor in the
  atmosphere ? even higher temperatures
• Eventually all atmosphere becomes rich in water
  vapor ? effective hydrogen escape to space ?
  permanent loss of water

25
Effective H escape
Space
h?
h?
Ineffective H escape
H2O h? ? H OH
H2O h? ? H OH
Upper Atmosphere (Stratosphere, Mesosphere)
H2O-poor
H2O-rich
H2O-rich
Lower Atmosphere (Troposphere)
H2O-ultrarich
26
Venus fate

• Runaway (or moist) greenhouse and the permanent
  loss of water could have happened on Venus
• Venus has very high D/H (120 times higher than
  Earths) ratio suggesting huge hydrogen loss

27

• Without water CO2 would accumulate in the
  atmosphere and the climate would become
  extremely hot present Venus is 90 times more
  massive than Earths and almost entirely CO2.
• Eventually Earth will follow the fate of Venus

28
The outer edge of the HZ

• The outer edge of the HZ is the distance from the
  Sun at which even a strong greenhouse effect
  would not allow liquid water on the planetary
  surface.
• Carbonate-silicate cycle can help to extend the
  outer edge of the HZ by accumulating more CO2 and
  partially offsetting low solar luminosity.

29
Limit from CO2 greenhouse

• At low Solar luminosities high CO2 abundance
  would be required to keep the planet warm.
• But at high CO2 abundance does not produce as
  much net warming because it also scatter solar
  radiation.
• Theoretical models predict that no matter how
  high CO2 abundance would be in the atmosphere,
  the temperature would not exceed the freezing
  point of water if a planet is further than 1.7
  A.U.

30
Limit from CO2 condensation

• At high CO2 abundance and low temperatures carbon
  dioxide can start to condense out (like water
  condense into rain and snow)
• Atmosphere would not be able to build CO2 if a
  planet is further than 1.4 A.U.

31
Fate of Mars

• Mars is on the margin of the HZ at the present
• But! Mars is a small planet and cooled relatively
  fast
• Mars cannot outgas CO2 and sustain
  Carbonate-Silicate feedback.
• Also hydrogen can escape effectively due to the
  low martian gravity and lack of magnetic field.


32
River channel
Nanedi Vallis (from Mars Global Surveyor)
3 km
33

• Grand Canyon required several millions
• of years to form
• The same should be true for Nanedi Vallis

34
Solar Luminosity versus Time
Solar luminosity is changing with time gt
Boundaries of the HZ are changing with time. How?
35
Continuous Habitable Zone (CHZ)

• A region, in which a planet may reside and
  maintain liquid water throughout most of a stars
  life.

36
HZ boundaries depend on the class of the
star. How?
37
Summary Habitable Zone

• The boundaries of the habitable zone depend on
  the stellar luminosity, planetary albedo,
  atmospheric greenhouse effect
• Atmospheric greenhouse and planetary albedo can
  change through climate feedbacks
• Stellar luminosity changes through time gt HZ
  boundaries change through time

38

• Suppose a planet is within the HZ.
• Does it mean that such planet would have to have
  liquid water on its surface?

39
Additional conditions for liquid water on the
planetary surface

• Planet should get enough water during its
  formation or shortly after
• Planet should be massive enough to retain water
• Planet should have enough internal heat to
  maintain plate tectonics
• Even if all of the above is true a water-rich
  planet can get into Snowball glaciations

40
Low Latitude Glaciations

• Paleomagnetic data indicate low-latitude
  glaciation at 0.63 (Marinoan), 0.75 (Sturtian)
  and 2.3 billions years ago (Huronian).
