Flexibility and Interoperability in a Parallel MD code

1
Flexibility and Interoperability in a Parallel MD
code

• Robert Brunner,
• Laxmikant Kale,
• Jim Phillips
• University of Illinois at Urbana-Champaign

2
Contributors

• Principal investigators
• Laxmikant Kale, Klaus Schulten, Robert Skeel
• Development team
• Milind Bhandarkar, Robert Brunner, Attila Gursoy,
  Neal Krawetz, Ari Shinozaki, ...

3
Middle layers
Applications
Middle Layers Languages, Tools, Libraries
Parallel Machines
4
(No Transcript)
5
Molecular Dynamics

• Collection of charged atoms, with bonds
• Newtonian mechanics
• At each time-step
• Calculate forces on each atom
• bonds
• non-bonded electrostatic and van der Waals
• Calculate velocities and Advance positions
• 1 femtosecond time-step, millions needed!
• Thousands of atoms (1,000 - 100,000)

6
Molecular Dynamics

• Collection of charged atoms, with bonds
• Newtonian mechanics
• At each time-step
• Calculate forces on each atom
• bonds
• non-bonded electrostatic and van der Waals
• Calculate velocities and Advance positions
• 1 femtosecond time-step, millions needed!
• Thousands of atoms (1,000 - 100,000)

7
Further MD

• Use of cut-off radius to reduce work
• 8 - 14 Å
• Faraway charges ignored!
• 80-95 work is non-bonded force computations
• Some simulations need faraway contributions

8
NAMD Design Objectives

• Performance
• Scalability
• To a small and large number of processors
• small and large molecular systems
• Modifiable and extensible design
• Ability to incorporate new algorithms
• Reusing new libraries without re-implementation
• Experimenting with alternate strategies

9
Force Decomposition
Distribute force matrix to processors Matrix is
sparse, non uniform Each processor has one
block Communication N/sqrt(P) Ratio
sqrt(P) Better scalability (can use 100
processors) Hwang, Saltz, et al 6 on 32 Pes
36 on 128 processor
Not Scalable
10
Spatial Decomposition
11
Spatial decomposition modified
12
Implementation

• Multiple Objects per processor
• Different types patches, pairwise forces, bonded
  forces,
• Each may have its data ready at different times
• Need ability to map and remap them
• Need prioritized scheduling
• Charm supports all of these

13
Charm

• Data Driven Objects
• Object Groups
• global object with a representative on each PE
• Asynchronous method invocation
• Prioritized scheduling
• Mature, robust, portable
• http//charm.cs.uiuc.edu

14
Data driven execution
Scheduler
Scheduler
Message Q
Message Q
15
Object oriented design

• Two top level classes
• Patches cubes containing atoms
• Computes force calculation
• Home patches and Proxy patches
• Home patch sends coordinates to proxies, and
  receives forces from them
• Each compute interacts with local patches only

16
Compute hierarchy

• Many compute subclasses
• Allow reuse of coordination code
• Reuse of bookkeeping tasks
• Easy to add new types of force objects
• Example steered molecular dynamics
• Implementor focuses on the new force functionality

17
Multi-paradigm programming

• Long-range electrostatic interactions
• Some simulations require this feature
• Contributions of faraway atoms can be computed
  infrequently
• PVM based library, DPMTA
• Developed at Duke, by John Board, et al
• Patch life cycle
• better expressed as a thread

18
Converse

• Supports multi-paradigm programming
• Provides portability
• Makes it easy to implement RTS for new paradigms
• Several languages/libraries
• Charm, threaded MPI, PVM, Java, md-perl, pc,
  nexus, Path, Cid, CC,..

19
Namd2 with Converse
20
Separation of concerns

• Different developers, with different interests
  and knowledge, can contribute effectively
• Separation of communication and parallel logic
• Threads to encapsulate life-cycle of patches
• Adding new integrator, improving performance, new
  MD ideas, can be performed modularly and
  independently

21
Load balancing

• Collect timing data for several cycles
• Run heuristic load balancer
• Several alternative ones
• Re-map and migrate objects accordingly
• Registration mechanisms facilitate migration
• Needs a separate talk!

22
Performance size of system
23
Performance various machines
24
Speedup
25
Conclusion

• Multi-domain decomposition works well for
  dynamically evolving, or irregular apps
• When supported by data driven objects (Charm),
  user level threads, call backs
• Multi-paradigm programming is effective!
• Object oriented parallel programming
• promotes reuse ,
• good performance
• Measurement based load balancing
