Grids for 21st Century Data Intensive Science

1

• Grids for 21st CenturyData Intensive Science

Paul Avery University of Florida http//www.phys.u
fl.edu/avery/ avery_at_phys.ufl.edu
NSF MeetingApr. 15, 2003
2
The Grid Concept

• Grid Geographically distributed computing
  resources configured for coordinated use
• Fabric Physical resources networks provide
  raw capability
• Middleware Software ties it all together (tools,
  services, etc.)
• Goal Transparent resource sharing

3
Fundamental Idea Resource Sharing

• Resources for complex problems are distributed
• Advanced scientific instruments (accelerators,
  telescopes, )
• Storage, computing,
• Groups of people, institutions
• Communities require access to common services
• Research collaborations (physics, astronomy,
  biology, eng. )
• Government agencies
• Health care organizations, large corporations,
• Virtual Organizations
• Create a VO from geographically separated
  components
• Make all community resources available to any VO
  member
• Leverage strengths at different institutions
• Add people resources dynamically

4
Some (Realistic) Grid Examples

• High energy physics
• 3,000 physicists worldwide pool Petaflops of CPU
  resources to analyze Petabytes of data
• Climate modeling
• Climate scientists visualize, annotate, analyze
  Terabytes of simulation data
• Biology
• A biochemist exploits 10,000 computers to screen
  100,000 compounds in an hour
• Engineering
• A multidisciplinary analysis in aerospace couples
  code and data in four companies to design a new
  airframe

From Ian Foster
5
Grid Challenges

• Manage workflow across Grid
• Balance policy vs. instantaneous capability to
  complete tasks
• Balance effective resource use vs. fast
  turnaround for priority jobs
• Match resource usage to policy over the long term
• Goal-oriented algorithms steering requests
  according to metrics
• Maintain a global view of resources and system
  state
• Coherent end-to-end system monitoring
• Adaptive learning new paradigms for execution
  optimization
• Handle user-Grid interactions
• Guidelines, agents
• Build high level services integrated user
  environment

6
Data Intensive Science 2000-2015

• Scientific discovery increasingly driven by data
  collection
• Computationally intensive analyses
• Massive data collections
• Data distributed across networks of varying
  capability
• Internationally distributed collaborations
• Dominant factor data growth (1 Petabyte 1000
  TB)
• 2000 0.5 Petabyte
• 2005 10 Petabytes
• 2010 100 Petabytes
• 2015 1000 Petabytes?

How to collect, manage, access and interpret
this quantity of data?
Drives demand for Data Grids to
handleadditional dimension of data access
movement
7
Data Intensive Physical Sciences

• High energy nuclear physics
• Including new experiments at CERNs Large Hadron
  Collider
• Astronomy
• Digital sky surveys SDSS, VISTA, other Gigapixel
  arrays
• VLBI arrays multiple- Gbps data streams
• Virtual Observatories (multi-wavelength
  astronomy)
• Gravity wave searches
• LIGO, GEO, VIRGO
• Time-dependent 3-D systems (simulation data)
• Earth Observation, climate modeling
• Geophysics, earthquake modeling
• Fluids, aerodynamic design
• Dispersal of pollutants in atmosphere

8
Data Intensive Biology and Medicine

• Medical data
• X-Ray, mammography data, etc. (many petabytes)
• Digitizing patient records (ditto)
• X-ray crystallography
• Bright X-Ray sources, e.g. Argonne Advanced
  Photon Source
• Molecular genomics and related disciplines
• Human Genome, other genome databases
• Proteomics (protein structure, activities, )
• Protein interactions, drug delivery
• Brain scans (1-10?m, time dependent)

9
Example LHC Physics
Compact Muon Solenoid at the LHC (CERN)
Smithsonianstandard man
10
LHC Data Rates Detector to Storage
40 MHz
1000 TB/sec
Physics filtering
Level 1 Trigger Special Hardware
75 GB/sec
75 KHz
Level 2 Trigger Commodity CPUs
5 GB/sec
5 KHz
Level 3 Trigger Commodity CPUs
100 400 MB/sec
100 Hz
Raw Data to storage
11
LHC Higgs Decay into 4 muons
109 events/sec, selectivity 1 in 1013
12
LHC Computing Overview

• Complexity Millions of individual detector
  channels
• Scale PetaOps (CPU), Petabytes (Data)
• Distribution Global distribution of people
  resources

1800 Physicists 150 Institutes 32 Countries
13
Global LHC Data Grid
CMS Experiment
Tier0/(? Tier1)/(? Tier2) 111
Online System
100-400 MBytes/s
CERN Computer Center 20 TIPS
Tier 0
10-40 Gbps
Tier 1
2.5-10 Gbps
Tier 2
1-2.5 Gbps
Tier 3
1-10 Gbps
Physics cache
Tier 4
PCs, other portals
14
Example Digital Astronomy Trends

• Future dominated by detector improvements

• Moores Law growth in CCDs
• Gigapixel arrays on horizon
• Growth in CPU/storage tracking data volumes
• Investment in software critical

Glass
MPixels

• Total area of 3m telescopes in the world in m2
• Total number of CCD pixels in Mpix
• 25 year growth 30x in glass, 3000x in pixels

15
The Age of Astronomical Mega-Surveys

• Next generation mega-surveys will change
  astronomy
• Top-down design
• Large sky coverage
• Sound statistical plans
• Well controlled, uniform systematics
• The technology to store and access the data is
  here
• Following Moores law
• Integrating these archives for the whole
  community
• Astronomical data mining will lead to stunning
  new discoveries
• Virtual Observatory

16
Virtual Observatories
Multi-wavelength astronomy,Multiple surveys
17
Virtual Observatory Data Challenge

• Digital representation of the sky
• All-sky deep fields
• Integrated catalog and image databases
• Spectra of selected samples
• Size of the archived data
• 40,000 square degrees
• Resolution 50 trillion pixels
• One band (2 bytes/pixel) 100 Terabytes
• Multi-wavelength 500-1000 Terabytes
• Time dimension Many Petabytes
• Large, globally distributed database engines
• Multi-Petabyte data size
• Thousands of queries per day, Gbyte/s I/O speed
  per site
• Data Grid computing infrastructure

18
Sloan Sky Survey Data Grid
19
U.S. Grid Projects
20
Global Context Data Grid Projects

• U.S. Infrastructure Projects
• Particle Physics Data Grid (PPDG) DOE
• GriPhyN NSF
• International Virtual Data Grid Laboratory
  (iVDGL) NSF
• TeraGrid NSF
• DOE Science Grid DOE
• NSF Middleware Initiative (NMI) NSF
• EU, Asia major projects
• European Data Grid (EU, EC)
• EDG national Projects (UK, Italy, France, )
• CrossGrid (EU, EC)
• DataTAG (EU, EC)
• LHC Computing Grid (LCG) (CERN)
• Japanese Project
• Korea project

21
Particle Physics Data Grid

• Funded 2001 2004 _at_ US9.5M (DOE)
• D0, BaBar, STAR, CMS, ATLAS
• SLAC, LBNL, Jlab, FNAL, BNL, Caltech, Wisconsin,
  Chicago, USC

22
PPDG Goals

• Serve high energy nuclear physics (HENP)
  experiments
• Unique challenges, diverse test environments
• Develop advanced Grid technologies
• Focus on end to end integration
• Maintain practical orientation
• Networks, instrumentation, monitoring
• DB file/object replication, caching, catalogs,
  end-to-end movement
• Make tools general enough for wide community
• Collaboration with GriPhyN, iVDGL, EDG, LCG
• ESNet Certificate Authority work, security

23
GriPhyN and iVDGL

• Both funded through NSF ITR program
• GriPhyN 11.9M (NSF) 1.6M (matching) (2000
  2005)
• iVDGL 13.7M (NSF) 2M (matching) (2001
  2006)
• Basic composition
• GriPhyN 12 funded universities, SDSC, 3
  labs (80 people)
• iVDGL 16 funded institutions, SDSC, 3 labs (80
  people)
• Expts US-CMS, US-ATLAS, LIGO, SDSS/NVO
• Large overlap of people, institutions, management
• Grid research vs Grid deployment
• GriPhyN 2/3 CS 1/3 physics ( 0 H/W)
• iVDGL 1/3 CS 2/3 physics (20 H/W)
• iVDGL 2.5M Tier2 hardware (1.4M LHC)
• 4 physics experiments provide frontier challenges
• Virtual Data Toolkit (VDT) in common

24
GriPhyN Goals

• Conduct CS research to enable Petascale science
• Virtual Data as unifying principle (more later)
• Planning, execution, performance monitoring
• Disseminate through Virtual Data Toolkit
• Series of releases
• Integrate into GriPhyN science experiments
• Common Grid tools, services
• Impact other disciplines
• HEP, biology, medicine, virtual astronomy, eng.,
  other Grid projects
• Educate, involve, train students in IT research
• Undergrads, grads, postdocs, underrepresented
  groups

25
iVDGL Goals and Context

• International Virtual-Data Grid Laboratory
• A global Grid laboratory (US, EU, Asia, South
  America, )
• A place to conduct Data Grid tests at scale
• A mechanism to create common Grid infrastructure
• A laboratory for other disciplines to perform
  Data Grid tests
• A focus of outreach efforts to small institutions
• Context of iVDGL in US-LHC computing program
• Mechanism for NSF to fund proto-Tier2 centers
• Learn how to do Grid operations (GOC)
• International participation
• DataTag
• UK e-Science programme support 6 CS Fellows per
  year in U.S.

26
Goal PetaScale Virtual-Data Grids
Production Team
Single Researcher
Workgroups
Interactive User Tools
Request Execution Management Tools
Request Planning Scheduling Tools
Virtual Data Tools
ResourceManagementServices
Security andPolicyServices
Other GridServices

• PetaOps
• Petabytes
• Performance

Transforms
Distributed resources(code, storage,
CPUs,networks)
Raw datasource
27
GriPhyN/iVDGL Science Drivers

• US-CMS US-ATLAS
• HEP experiments at LHC/CERN
• 100s of Petabytes
• LIGO
• Gravity wave experiment
• 100s of Terabytes
• Sloan Digital Sky Survey
• Digital astronomy (1/4 sky)
• 10s of Terabytes

• Massive CPU
• Large, distributed datasets
• Large, distributed communities

28
US-iVDGL Sites (Spring 2003)

• Partners?
• EU
• CERN
• Brazil
• Australia
• Korea
• Japan

29
iVDGL Map (2002-2003)
Surfnet
DataTAG

• New partners
• Russia T1
• China T1
• Brazil T1
• Romania ?

30
ATLAS Simulations on iVDGL Resources
Joint project with iVDGL
31
US-CMS Grid Testbed
32
CMS Grid Testbed Production
33
US-CMS Testbed Success Story

• Production Run for the IGT MOP Production
• Assigned 1.5 million events for eGamma Bigjets
• 500 sec per event on 750 MHz processor all
  production stages from simulation to ntuple
• 2 months continuous running across 5 testbed
  sites
• Demonstrated at Supercomputing 2002

1.5 Million Events Produced ! (nearly 30 CPU
years)
34
Creation of WorldGrid

• Joint iVDGL/DataTag/EDG effort
• Resources from both sides (15 sites)
• Monitoring tools (Ganglia, MDS, NetSaint, )
• Visualization tools (Nagios, MapCenter, Ganglia)
• Applications ScienceGrid
• CMS CMKIN, CMSIM
• ATLAS ATLSIM
• Submit jobs from US or EU
• Jobs can run on any cluster
• Demonstrated at IST2002 (Copenhagen)
• Demonstrated at SC2002 (Baltimore)

35
WorldGrid Sites
36
Grid Coordination
37
U.S. Project Coordination Trillium

• Trillium GriPhyN iVDGL PPDG
• Large overlap in leadership, people, experiments
• Benefit of coordination
• Common S/W base packaging VDT PACMAN
• Collaborative / joint projects monitoring,
  demos, security,
• Wide deployment of new technologies, e.g. Virtual
  Data
• Stronger, broader outreach effort
• Forum for US Grid projects
• Joint view, strategies, meetings and work
• Unified entity to deal with EU other Grid
  projects
• Natural collaboration across DOE and NSF
  projects
• Funding agency interest?

38
International Grid Coordination

• Global Grid Forum (GGF)
• International forum for general Grid efforts
• Many working groups, standards definitions
• Close collaboration with EU DataGrid (EDG)
• Many connections with EDG activities
• HICB HEP Inter-Grid Coordination Board
• Non-competitive forum, strategic issues,
  consensus
• Cross-project policies, procedures and
  technology, joint projects
• HICB-JTB Joint Technical Board
• Definition, oversight and tracking of joint
  projects
• GLUE interoperability group
• Participation in LHC Computing Grid (LCG)
• Software Computing Committee (SC2)
• Project Execution Board (PEB)
• Grid Deployment Board (GDB)

39
Future U.S. Grid Efforts

• Dynamic workspaces proposal (ITR program 15M)
• Extend virtual data technologies to global
  analysis communities
• Collaboratory proposal (ITR program, 4M)
• Develop collaborative tools for global research
• Combination of Grids, communications, sociology,
  evaluation,
• BTEV proposal (ITR program)
• FIU Creation of CHEPREO in Miami area
• HEP research, participation in WorldGrid
• Strong minority E/O, coordinate with
  GriPhyN/iVDGL
• Research intl network Brazil / South America
• Other proposals
• ITR, MRI, NMI, SciDAC, others

40
Sub-Communities in Global CMS
Pull In Outside Resources
41
Summary

• Progress on many fronts in PPDG/GriPhyN/iVDGL
• Packaging Pacman VDT
• Testbeds (development and production)
• Major demonstration projects
• Productions based on Grid tools using iVDGL
  resources
• WorldGrid providing excellent experience
• Excellent collaboration with EU partners
• Excellent opportunity to build lasting
  infrastructure
• Looking to collaborate with more international
  partners
• Testbeds, monitoring, deploying VDT more widely
• New directions
• Virtual data a powerful paradigm for LHC
  computing
• Emphasis on Grid-enabled analysis

42
Grid References

• Grid Book
• www.mkp.com/grids
• Globus
• www.globus.org
• Global Grid Forum
• www.gridforum.org
• PPDG
• www.ppdg.net
• GriPhyN
• www.griphyn.org
• iVDGL
• www.ivdgl.org
• TeraGrid
• www.teragrid.org
• EU DataGrid
• www.eu-datagrid.org
