Title: Signaling System 7


1
Signaling System 7
2
SS7 - 1
  • Common channel interoffice signaling CCIS based
    on SS6
  • SS7 developed for ISDN voice and nonvoice
    services
  • SS7 is used to set up and manage switch centres
    to provide a range of services

3
SS7 - 2
  • Application domestic and international
  • Signaling type - digital
  • Speed 56/64Kbps
  • Link capacity 30K circuits
  • Message length lt272 octets
  • Routing destination office
  • Architecture - layered

4
SS7 - 3
  • Flexibility high
  • Date of development - mid 70s before OSI
  • Messages passed on D channel
  • SS7 uses out of band signaling
  • SS7 Protocol Architecture Diagram p222

5
SS7 Protocol overview 1
  • Message transfer port MTP
  • Protocols roughly correspond to the lower three
    layers of the OSI
  • Provides physical data link, connectionless
    network functions
  • Reliable transfer of signaling messages
  • Three layer protocol

6
SS7 Protocol overview 2
  • Signaling Connection Control Port SCCP
  • Provides some network layer functions, full OSI
    addressing, connection oriented information
    transfer

7
SS7 Protocol overview 3
  • User and Application Parts
  • Provides end to end signaling functions for
    switched voice and nonvoice services in the ISDN,
    several user parts can operate in parallel over
    single MTP and/or SCCP

8
MTP Level 1 protocol
  • Signaling data link OSI physical layer
  • Duplex digital links operating at 64Kbps
  • Rates 1.55M and 2.048 and 8.448 possible
  • USA use 56Kbps

9
MTP Level 2 protocol
  • Signaling link OSI data link layer
  • Bit oriented protocol
  • Detail on p224
  • Frames called signaling units
  • Begin and end with flag pattern - 01111110
  • Zero bit insertion is used for transparency
  • Bit stuffing

10
MTP Level 3 protocol
  • Signaling network functins lower half of OSI
    network layers
  • Functions message handling and network management
  • Handles routing labels, destination point code
    DPC and origination point code OPC

11
ISDN User Part
  • ISUP or ISDN-UP provides signaling for basic ISDN
    circuit-mode bearer services
  • Support for voice and nonvoice services
  • ISUP provides conectin between two ISDN switches
  • Connection identified by circuit identification
    code CIC

12
ISDN User Part
  • ISDN call TE sends setup message to the LE on the
    D channel
  • LE at originating side siezes a trunk
  • Initial address message IAM
  • Terminal equipment TE
  • Local exchange LE

13
ISDN
  • Zero bit insertion is used
  • Ref
  • ISDN Sec Ed, 1993
  • GC Kessler
  • McGraw-Hill, ISBN 0-07-034247-4
