Threaded Inserts

1
Threaded Inserts
Laura Hansen Jeremiah Johnstun
2
Purpose of Threaded Inserts

• Repair Damaged Threads
• Reduce Thread Pitch and Angle Errors
• Distributes Load More Evenly
• In Soft Materials
• Improves Holding Capacity
• Reduces Thread Wear

3
Angle and Thread Pitch Errors
4
Distributes Load More Evenly
5
Advantages of Threaded Inserts

• Low cost
• Blind installation
• Permanent, reliable fastening
• Eliminates the need for welding or tapping

6
Most Common Threaded Inserts

• Coil Type
• Wire wound into a helical coil
• Larger diameter than tapped holeapplies
  compression
• Can be self-threading or drilled and tapped

7

• Rivet Type
• Can be installed blind
• Can be used on sheet metal and fiberglass
• Cheaper and easier than welded studs for
  non-permanent applications

8
In Conclusion
Web Addresses www.recoil.com.au www.avdelcherry
textron.com www.emhart.com www.klsales.com www.
pintech.com
