Title: Muon Phase Rotation at PRISM FFAG


1
Muon Phase Rotation at PRISM FFAG
  • Akira SATO
  • Osaka University

2
Contents
  • PRISM Overview
  • Tracking Simulation by Geant3.21
  • Phase rotation
  • Acceptance of FFAG
  • Muon decay - survival rate
  • Large Gap FFAG
  • Betatron tune dependence
  • Summary

3
PRISM Beam Characteristics
Phase Rotated Intense Slow Muon source
  • intensity 1011-1012m/sec
  • muon kinetic energy 20 MeV (68 MeV/c)
  • range about 3 g
  • kinetic energy spread 0.5-1.0 MeV
  • a few 100 mg range width
  • beam repetition about 100Hz

Search µN?eN with sensitivity of 10-18 Cf. MECO
_at_BNL-AGS 10-16
4
PRISM layout
  • Pion capture section
  • Decay section
  • Phase rotation section
  • FFAG Based
  • a ring instead of linear systems
  • reduction of of rf cavities
  • reduction of rf power consumption
  • compact

not in scale
5
FFAG for Phase Rotation
Fixed Field Alternating Gradient Synchrotron
  • synchrotron oscillation for phase rotation
  • not cyclotron (isochronous)
  • large momentum acceptance
  • larger than synchrotron
  • several 10 is aimed
  • large transverse acceptance
  • strong focusing
  • large horizontal emittance
  • reasonable vertical emittance at low energy

6
Phase Rotation
  • Phase Rotation decelerate particles with high
    energy and accelerate particle with low energy by
    high-field RF
  • A narrow pulse structure (lt1 nsec) of proton beam
    is needed to ensure that high-energy particles
    come early and low-energy one come late.

7
Simulation of the PRISM Phase Rotator
  • By GEANT3.21 Full simulation
  • Muon decay -gt intensity
  • Interaction -gt background
  • Acceptance study
  • Phase rotation study
  • Muon survival rate

8
Simulation Setup
  • Muon phase rotation was studied by the GEANT3.21
    3D simulation.
  • except kicker parts.
  • GEANT3 has single precision.
  • Cf. Double precision
  • DPGeant
  • Geant4

9
Magnet Model and Field
  • Field gradient was made by gap size.
  • Magnitude of the field
  • D Bz -0.0717(r(m)/r0)5 (T)
  • F Bz 0.435(r(m)/r0)5 (T)
  • r0 5 m for 68MeV/c
  • 3D magnetic field of FFAG magnet was calculated
    by TOSCA.

FFAG Lattice Triplet DFD
10
RF modeling
  • Total of RF cavity 12
  • 4gaps/cavity
  • RF wave field type
  • Sinusoidal
  • Saw tooth

11
?0
  • Information
  • _at_?0
  • (r,?,z)
  • momentum
  • ToF
  • Particle ID

?
12
Muon injection
  • Muon was injected from ?0
  • momentum 68MeV/c-20
  • 54.4, 61.2, 68.0, 74.8, 81.6MeV/c
  • Phase space
  • r r(p)-8 cm
  • ur 0-0.2 rad.
  • z 0-16 cm
  • uz 0-0.08 rad.
  • Timing
  • Arrival time to solenoid exit is taken into
    account.

81.6
71.2
68.0
61.2
54.4MeV/c
t0,-5ns
13
Typical Muon Track
  • 54.4MeV/c µ
  • Because FFAG has momentum dispersion, radius of
    the muon orbit becomes lager gradually.

14
Phase Rotation Study
  • Sinusoidal
  • Saw tooth

15
Sinusoidal RF
  • RF 5MHz, 128kV/m
  • Energy spread after 5turns
  • ?p/p
  • 68MeV/c8-6
  • ?E/E
  • 20MeV12-10

16
Saw tooth RF
  • RF 5MHz, 250kV/m
  • Energy spread after 5turns
  • ?p/p
  • 68MeV/c2-2
  • ?E/E
  • 20MeV4-5

17
How to realize saw tooth
  • It is difficult to realize saw tooth with a field
    gradient of 250kV/m.
  • Fit the saw tooth wave to the function
  • Each RF have just sinusoidal wave.

18
Simulation Result
19
Acceptance Study
  • Horizontal acceptance
  • Vertical acceptance
  • Survival rate
  • Large gap FFAG

20
Horizontal Phase Space
Horizontal Acceptance 10000pi mm mrad
21
Vertical Phase Space
Vertical Acceptance 2000pi mm mrad
22
Muon surviving
of surviving muon after 5 turns
  • Surviving rate after 5turns 60
  • e- contamination lt 1/1600

23
Survival Rate vs. Momentum
  • Why do large momentum particles have low survival
    rate?
  • Gap ? (r0/r)5
  • Physical aperture limits the dynamical
    acceptance.
  • Lager Gap Magnet
  • ? Lager Acceptance
  • We Need Lager Gap Magnet !

24
FFAG Magnet with Large Gap(1)
25
Dose an acceptance depend on betatron tune?
Selection of Betatron Tune
26
Long Term Acceptance (Region1)
27
Long Term Acceptance (Region2)
28
5 turns Acceptance- Number of lost particle
Region1
Region2
FFAG acceptance depends on betatron tune.
29
Surviving Rate (Region2)
30
(No Transcript)
31
(No Transcript)
32
Summary
  • PRISM phase rotation was studied by GEANT3.21.
  • We can achieve energy spread of ?E/E-5 after
    phase rotation.
  • Even present design PRISM FFAG has large
    acceptance H10000, V2000pmm mrad. These
    acceptance was limited by physical aperture.
  • We have some idea to get lager acceptance. These
    will be studied soon.
