DSpace 2.x Architecture Roadmap

1
DSpace 2.x Architecture Roadmap

• Robert Tansley
• DSpace Technical Lead, HP

2
Overview

• Why a DSpace 2.x?
• Proposed Target Architecture
• Example Deployments
• Proposed Migration Path

3
Why a DSpace 2.x?
4
DSpace 1.x

• Breadth-first implementation of institutional
  repository
• Provides all required functionality to start
  capturing digital assets
• Widened awareness and understanding of digital
  preservation problem

5
Key areas for improvement

• Modularity
• Digital Preservation
• Scalability

6
Modularity

• Current APIs are low-level, somewhat ad-hoc
• Difficult to keep stable
• Difficult to implement enhanced/alternative
  functionality behind them
• Changing a particular aspect of functionality
  involves changing UI as well as underlying
  business logic module
• e.g Workflow review pages very specific to
  current Workflow Manager module functionality

7
Modularity

• Heavy inter-dependence
• e.g. Use same DB tables change in one module
  means you have to change others that use the same
  tables
• No real plug in mechanism
• Managing a modification alongside evolving core
  DSpace code can be tricky

8
DSpace 1 series architecture
9
Making a change
10
Proposed new modular approach

• Modules provide own UI
• Modules do not directly share data, e.g. DB
  tables
• Inter-module communication via defined APIs
• Many modules then dont need APIs, e.g. browse UI

11
Proposed new modular approach

• UIs glued together by UI framework
• Framework provides navigation tools, look and
  feel, internationalisation, localisation

12
Proposed new modular approach

• Modules can depend on APIs

13
Proposed new modular approach

• Modules can implement two APIs
• E.g. LDAP integration module could implement
  E-person API and authorisation API

14
Digital preservation

• Use of relational database optimised for access
• Metadata is separate from Bitstreams
• database corruption would make archive very
  difficult to reconstruct
• Hard to extend metadata schema support
• Custom schema difficult for other apps to access

15
Scalability

• Some limits on scalability in 1.x, e.g.
• Browse code
• Supports multiple file systems, but not ideal
• Largely limited to single server
• Mirroring difficult
• Metadata in database, bitstream on file system
• extraction non-trivial

16
Proposed approach

• Refactor storage Asset store
• Metadata in standard format and bitstreams stored
  in the same place
• AIP becomes a more tangible concept
• Aids preservation No reliance on particular
  software
• Aids scalability Easier to manage storage and
  distribution
• Easier to move around

17
Summary
18
Proposed Target Architecture
19
Target architecture overview
20
Asset store
21
Asset store

• Corresponds to OAIS Archival Storage
• Contains only Archival Information Packages
  (AIPs)
• Not e-people records, in-progress submissions
  etc.
• AIPs consist of
• Metadata serialisation
• Bitstreams
• AIP checksum

22
Object model
23
Example AIP (item)

• How it might look in a file system
• aip-identifier/
• metadata.xml current metadata serialisation
• 184BE84F293342 bitstream 1 (filename
  checksum)
• 3F9AD0389CB821 bitstream 2
• 330F925A1D0386 bitstream 3
• checksum checksum of AIP

24
Asset store API
25
Asset store API

• Standardised Java API for DSpace asset stores
• May be different implementations
• simple file system
• Enterprise reference information store
• Grid-based, e.g. SRB
• SAN
• Allows creation, retrieval, update etc. of AIPs

26
Scaling up

• Easy to replicate AIPs and asset stores
• Enables serving larger numbers of users
• Aids preservation Multiple copies, more robust

27
Scaling up

• Two DSpaces can easily keep synchronised

28
Scaling up

• Two DSpaces can easily keep synchronised
• Something as simple as a periodic rsync can do
  the job
• Exact mechanism would depend on asset store
• File system, enterprise reference information
  store, SRB etc.

29
What about clashes?

• Were dealing with reference information
• DSpace is not an authoring system
• Not work-in-progress, often-updated material
• Same AIP updated by two different DSpace
  instances in same day unlikely
• Can flag as a conflict for manual resolution
• Exception Items being added to same collection
• Simple to resolve merge the additions
• Just make sure IDs are unique!

30
What about search indices?

• Modules may maintain indices or caches of
  information from AIPs in the asset store
• E.g. the browse UI, Lucene index
• Modules keep indices or caches up-to-date by
  periodically polling asset store API
• Similar to incremental harvesting in OAI-PMH

31
Why the polling approach?

• Polling is simpler to implement than real-time
  notification
• Implementing custom asset store easier
• More scalable can control when indexing occurs
• Big sync might mean several indices updating at
  once
• End-users might not see deposits appear in the
  search/browse indices immediately. However
• Doesnt happen anyway if any workflow review
  needed
• Neednt take more than overnight to happen
• Reference information not time-critical data

32
DSpace modular architecture

• Some modules have APIs some do not
• Modules may have dependencies
• i.e. for module X depends on an implementation of
  API Y
• Modules may use RDBMS but do not share tables

33
UI framework
34
UI framework

• Glues together UIs of different modules
• Provides navigation tools, stylesheets, skin
• Internationalisation, localisation
• User authentication
• Cocoon provides most of the above functionality
• Easy to add the rest

35
Exposing services via Tomcate.g. OAI-PMH
36
Core DSpace modules and APIs
37
Content management API

• Similar to existing org.dspace.content API
• Provides procedural way to manipulate AIPs
• Implementation may cache some information in
  RDBMS
• E.g. Community/collection/item structure

38
Extending metadata

• Pull out pieces of search UI, submit UI, item
  display related to Dublin Core into a separate
  module
• Allow other similar modules for dealing with
  other schemas and extensions
• Start with simple property/value support
• SIMILE will provide richer functionality

39
Security

• Similar to DSpace 1.x
• Modules running within DSpace instance trusted
• Not worrying about malicious code for now
• Modules, UI framework responsible for
  authenticating end-user as an e-person
• Modules, asset store implementation must invoke
  authorisation API as appropriate

40
Summary

• Refactor storage Content in AIPs (metadata
  bitstreams)
• Easier to share/mirror AIPs with periodic
  synchronisation
• Modules do OAI-PMH-style incremental harvests to
  keep indices/caches up to date
• Benefit Increased scalability, preserve-ability
• Cost New/changed AIPs arent instantly indexed
• Often not the case anyway (workflow reviews)
• Reference information (not time critical)

41
Summary

• Modular architecture
• Modules responsible for own UI and data
• Modules inter-communicate via defined APIs
• UI framework provides Web UI glue Cocoon
• Dependency mechanism to allow plug-in
  functionality
• Benefit Vastly improved modularity
• Essential for our diverse community of users
• Cost Implementing modules might take more effort
• Unavoidable but manageable price of modularity
• Different from current approach migration
  non-trivial
• Those who havent changed DSpace 1 much will have
  easy upgrade path
• Does anyone really like servlets/JSPs?

42
Example Deployments
43
Standard deployment
44
Web services module
45
LDAP-based e-people and authorisation
46
Mirrored asset store
47
Shared asset store
48
Separate ingest and access instances
49
DSpace on SRB
50
SIMILE
51
Proposed Migration Path
52
Stage 1 Build asset store

• Decide on AIP metadata serialisation
• Build asset store
• Integrate asset store w/DSpace 1.x
• Either build synchronisation tool, or
• Replace CM API (org.dspace.content) -- trickier

53
Stage 2 Build 2.0

• Design build modular infrastructure
  (dependencies etc)
• Define the APIs
• Port/implement 1.x functionality
• Release this as 2.0
• Institutions can port their code to the 2.0
  architecture, and swap over

54
Stage 3 2.x and beyond

• DSpace 2.1
• Authorisation policy expression in AIPs
• XQuery API
• DSpace 2.2
• Federation
• DSpace 2.3
• Integrate SIMILE components
