Superconductivity: modelling impurities and coexistence with magnetic order

1
Superconductivity modelling impurities and
coexistence with magnetic order
Brazil-India Workshop on Theoretical Condensed
Matter Physics Brazilian Academy of Sciences,
April 2008
Raimundo R dos Santos

• Collaborators
• Pedro R Bertussi (UFRJ)
  André L Malvezzi (UNESP/Bauru)
• F. Mondaini (UFRJ)
  Richard T.Scalettar (UC-Davis)
• Thereza Paiva (UFRJ)

Financial support
2

• Layout
• A) Disordered Superconductors
• Motivation
• The disordered attractive Hubbard model
• Quantum Monte Carlo
• Ground state properties
• Finite-temperature properties
• Conclusions
• B) Coexistence of Superconductivity and Magnetism
• Motivation
• Model
• DMRG
• Results
• Conclusions
• C) Overall Conclusions

3
Disordered superconducting films
F Mondaini et al.
4
Disorder on atomic scales Sputtered amorphous
films
Sheet resistance R at a fixed
temperature can be used as a measure of disorder
Mo77Ge23 film
CRITICAL TEMPERATURE Tc (kelvin)
independent of the size of square
SHEET RESISTANCE AT T 300K (ohms)
Disorder is expected to inhibit superconductivity
J Graybeal and M Beasley, PRB 29, 4167 (1984)
5
Issues
How much dirt (disorder) can take a
super-conductor before it becomes normal
(insulator or metal)?

• Question even more interesting in 2-D (very thin
  films)
• superconductivity is marginal
• Kosterlitz-Thouless transition
• metallic behaviour also marginal
• Localization for any amount of disorder in the
  absence of interactions (recent expts MIT
  possible?)

A M Goldman and N Markovic, Phys. Today, Page 39,
Nov 1998
6
Metal evaporated on cold substrates, precoated
with a-Ge disorder on atomic scales.
Bismuth
Superconductor Insulator transition at T 0
when R reaches one quantum of resistance for
electron pairs, h/4e2 6.45 k?
SHEET RESISTANCE R (ohms)
?Quantum Critical Point
(evaporation without a-Ge underlayer granular ?
disorder on mesoscopic scales.1)
Behaviour near QCP will not be discussed here
D B Haviland et al., PRL 62, 2180 (1989)
TEMPERATURE (K)
7
(No Transcript)
8
Dilute magnets fraction p of sites occupied by
magnetic atoms
Tc ? 0 at pc, the percolation concentration
(geometry)
Yeomans Stinchcombe JPC (1979)
Ising 2D
9
The disordered attractive Hubbard model

• ? particle-hole symmetry at half filling
• ? strong-coupling in 2D
• half filling XY (SUP) ZZ (CDW) ? Tc ? 0
• away from half filling XY (SUP) ? TKT ? 0

Homogeneous case
Paiva, dS, et al. (04)
10
The disordered attractive Hubbard model
? particle-hole symmetry is broken
Heuristic arguments Litak Gyorffy, PRB (2000)
fc ? as U?
Disordered case
mean- field approxn
c ? 1- f
11
Quantum Monte Carlo

• Calculations carried out on a square imaginary
  time lattice

Absence of the minus-sign problem in the
attractive case
x
12
For given temperature 1/?, concentration f,
on-site attraction U, system size L ? L etc, we
calculate the pairing structure factor,
averaged over 50 disorder configurations. N.B.
half filling from now on
13
Ground State Properties
14
We estimate fc as the concentration for which ? ?
0 can plot fc (U )...
normalized by the corresponding pure case
15
fc increases with U, up to U 4 mean-field
behaviour sets in above U 4?
transition definitely not driven solely by
geometry (percolative) fc fc (U ) (c.f.,
percolation fc 0.41)
16
Finite-temperature properties
Finite-size scaling for Kosterlitz-Thouless
transitions
L2/?2
L1/?1
KT
L2/?2
L1/?1
usual
?
?c
?
?KT
Barber, DL (83)
17
For infinite-sized systems one expects
Finite-size scaling at T gt 0 KT transition
18
(No Transcript)
19
Tc initially increases with disorder breakdown
of CDW-SUP degeneracy
20
Conclusions (half-filled band)

• A small amount of disorder seems to initially
  favour SUP in the ground state.
• fc depends on U ? transition at T 0 not
  solely geometrically driven quantum effects
  correlated percolation?
• Two possible mechanisms at play
• MFA as U increases, pairs bind more tightly ?
  smaller overlap of their wave functions, hence
  smaller fc.
• QMC this effect is not so drastic up to U 4 ?
  presence of free sites allows electrons to stay
  nearer attractive sites, increasing overlap,
  hence larger fc.
• QMC for U gt 4, pairs are tightly bound and SUP
  more sensitive to dirt.
• A small amount of disorder allows the system to
  become SUP at finite temperatures as disorder
  increases, Tc eventually goes to zero at fc.

21
Coexistence between superconductivity and
magnetic order
PR Bertussi et al.
22
Motivation
Competition between exchange interaction and
electronic correlations, as, e.g., in -
Magnetic superconductors (attractive
correlations) heavy fermions (FM
AFM) - bulk borocarbides (AFM) -
layers - Diluted magnetic semiconductors
(repulsive correlations). In this work
attractive correlations
23
Borocarbides
Canfield et al., (1998)
Coexistence of magnetic order and
superconductivity
24
Borocarbides
Er
Tm
Tb
R Pr, Dy, Ho
Lynn et al., (1997)

• Rare earth 4f electrons order (AF) magnetically
• Conduction electrons form Cooper pairs

25
Model

• Electronic correlations ? Attractive Hubbard
  Model
• Exchange interaction between conduction
  electrons and local moments ? Kondo term

26
Method

• DMRG ? approximate ground state
• Up to 60 sites
• Density n1/3
• Open boundaries ? consider only sites away from
  the boundaries (5 sites)
• Analysis of ground state properties through
  correlation functions (pairing, magnetic and
  charge) and their respective structure factors

27
Density Matrix Renormalization Group

• Obtain the ground state by using, for example,
  Lanczos

28
Density Matrix Renormalization Group
Superblock
System S
Environment E

• Obtain the ground state by using, for example,
  Lanczos
• Use density matrix to select the states of the
  system (environment) that are the most important
  to describe the ground state of the universe
• ? truncation

29
Density Matrix Renormalization Group
Superblock
System S
Environment E
S
E
S
E

• Obtain the ground state by using, for example,
  Lanczos
• Use density matrix to select the states of the
  system (environment) that are the most important
  to describe the ground state of the universe
• ? truncation
• Add sites to create a new system (environment)

30
Results
31
Electron-spin?localized-spin correlations
S s (U 8t )
- Non-exhausted singlet states (Kondo) above
(J/U)c
32
Electron spin-spin correlations
sz ( i ) sz ( j ) (U 8t)
- Rapidly decaying correlations electrons on
different sites are not magnetically ordered
33
Localized spin-spin correlations
Sz ( i ) Sz ( j ) (U 8t)
Sx ( i ) Sx ( j ) (U 8t)
- SDW correlations for small J/U
- FM for large J/U
34
Localized spin-spin correlations structure factor
(U 8t)
(U 6t)
- maximum at k 0 indicates FM and at k p, SDW
(U 4t)
- maximum at intermediate k ? ISDW,
incommensurate with lattice spacing
- Gradual transition from maximum at k p to k
0
35
Comparison S(k) peaks
? No significant finite-size effects
36
Pairing correlations
(U 8t)
- Superconductivity possible only below (J/U)c
37
Comparison Ps(r)
38
Ps fit
? Ps 1 / rß
39
Phase Diagram
40
Conclusions

• Conduction electrons never order magnetically
• Coexistence of Superconductivity with magnetic
  ordering of the local moments (SDW or ISDW) below
  (J/U)c
• Kondo effect (singlets between local moments and
  conduction electrons) with a tendency of spiral
  ferromagnetism of the local moments

41
Overall conclusions
Use of simple attractive Hubbard model allows
investigation of real-space phenomena in
superconductors BCS model hard to extract info
in similar contexts ? need to learn how to
incorporate finite-size effects (in progress)
42
Materials for Spintronics Diluted Magnetic
Semiconductors
Collaborators Antônio José Roque da Silva
(IFUSP) Adalberto Fazzio (IFUSP) Luiz
Eduardo Oliveira (IFGW/UNICAMP) Tatiana G
Rappoport (IF/UFRJ)
