HyQuip Inc' Sales Presentation

1
Introduction
2
Locations
With two store locations to serve you better
Waukesha 1811 Dolphin Drive Waukesha, WI 53186
Hose Assemblies Made While You Wait!
Butler 4665 N 124th Street Butler, WI 53007
3
Eaton Brands
Aeroquip Boston Weatherhead Vickers Synflex Everfl
ex
Aeroquip Boston Weatherhead
Vickers Synflex Everflex
Brands offered by HyQuip
4
Value Added Services
HyQuip Value Added Services

• Custom Hose Assemblies
• Kits
• Custom BOMs
• Vendor Managed Inventory
• Custom Labeling
• Cut Lengths of Hose (ex. ¼ Fuel Line)
• Bin Bar Codes Bin Labeling
• Consolidated Billing
• JIT Coordination
• Sub-Assemblies
• 24 hr Emergency Customer Service

Open 6 days a week!
We are Customer Service Orientated!
Dedicated Customer Service and Sales Staff!
5
Aeroquip Hose Offered
HyQuip Hose Offered
SAE 100R12 SAE 100R13 SAE 100R16 SAE 100R17 SAE
100R18 SAE 30R2 SAE J2064
SAE 100R1 SAE 100R2 SAE 100R3 SAE 100R4 SAE
100R5 SAE 100R7 SAE 100R8 SAE 100R11
Single Wire Braid Double Wire Braid Four Wire
Spiral Six Wire Spiral Thermoplastic PTFE Smooth
Convoluted Socketless Air Hose Refrigerant
Hose Industrial Transfer Hose And many more
6
Hose types and Uses
Aeroquip
MatchMate AQP Polyon/Thermoplastic Bruiser Socketl
ess Air Conditioning Refrigeration
Industrial Aerospace Automotive
7
MatchMate Step 1
Hose Assemblies Made Easy with MatchMate Plus
Step 1
Choose the right MatchMate Plus replacement hose
by matching construction and size.
Rings on the colored layline indicate
construction and the hose dash number indicates
size.
8
MatchMate Step 2
Hose Assemblies Made Easy with MatchMate Plus
Step 2
Select a MatchMate fitting with the same dash
number as the hose.
Make sure the number grooved rings on the socket
match the number of rings on the hose.
Insert fitting into hose.
Skiving of hose is not necessary with the (TTC)
fitting designs!
9
MatchMate Step 3
Hose Assemblies Made Easy with MatchMate Plus
Step 3
Choose the correct die cage by matching the dash
number and the color code to the hose layline to
the color coded tabs on the die cage.
Insert into crimp machine.
10
MatchMate Step 4
Hose Assemblies Made Easy with MatchMate Plus
Step 4
Adjust the crimp machine settings as it is listed
on the machine mounted decal or in the crimp
specification chart.
11
MatchMate Step 5
Hose Assemblies Made Easy with MatchMate Plus
Step 5
Place your pre-assembled hose in the die cage
and line up the crimp line on the fitting with
the top of the die cage.
Activate the crimp machine and it will
automatically crimp your assembly to factory
standards.
12
MatchMate Overview
Hose Assemblies Made Easy with MatchMate Plus

• HyQuip is proud to offer this industry leading
  system.
• Aeroquips global product line is now enhanced by
  combining the convenience, performance and
  accessibility of TTC fittings with the ease and
  consistency of the MatchMate Plus system.
• Together, global products and MatchMate Plus
  bring you the 3 minute crimp hose assembly
  system. There is no easier way to make a crimp
  hose assembly than MatchMate Plus.

13
Fittings Adapters
Fittings Adapters
Steel Stainless Steel Brass
14
Additional Eaton Products
Swivel Joints
Quick Disconnect Coupling
Flexmaster Joints
15
Bruiser Hose
Bruiser
Constant Pressure
High Abrasion Resistance
Which eliminates the need for abrasion resistant
sleeving
16
Exciting Offers
Exciting new products offered by HyQuip!
Exciting
Industry Leading Product
Synflex
Synflex
Everflex
Everflex
Price Competitive
Brass Products
Wide Varity and Selection
Brass Products
Boston
Quality Hose Product
Boston
17
Boston Hose
Boston
Industrial Hose

• Air Multi-Purpose
• Chemical Service
• Specialty Service
• Food Service Industry
• Suction Discharge
• Material Handling
• Cleaning Service
• Steam Service
• General Purpose

Transfer Hose Products
18
Everflex
Vacuum/Steam lines Spray Paint Aerospace Biomedica
l Chemical Processing Industrial Adhesives Paper
Mill Truck and Bus Paint Ball
Everflex
PTFE Hose
"When Rubber Hose is Not Enough..."
Unmatched Strength Ultimate Flexibility
Carries fluids of all kinds without contamination
Withstands constant flexing and vibration
Functions smoothly at extreme temperatures
Resists fatigue and failure under high pressure
19
Synflex
Synflex
Thermoplastic Hose
Product Applications
General Hydraulic Applications Construction Forkli
fts Pneumatics Agriculture Equipment Material
Handling Aerial Lift Equipment Mobile Hydraulics
HyQuip Feature Product
30CT Constant Pressure Hose
100R18 3,000 psi
20
Crimpers
Eaton Brand Crimpers
Purchase Crimper Rentals Instructional
Training Repair Services
21
Extras!
Flaretite Seals
Hose Looms
Hose Support Clamps
Abrasion Resistant Sleeving
Fire Sleeve
and much more
22
More Extras!
Our Express Store Locations now offer OSHA
approved safety equipment!
Hose, Tube, and Pipe cleaning kits and supplies
available
23
Additional Product Lines
Other Product lines offered by HyQuip
Midland Metal Malone MRO Solutions New
Age Oil-Dri Precision Instrument Corp.
(P.I.C.) Pressure Components inc.
(PCI) Pyramex RuB SSP Fittings Thermoid Tompkins T
omco Tridon / Ideal Ultra Clean World Wide Voss
Industries
Accuflex Adaptall Anchor Flange Anderson
Fittings Arrow Pneumatics BVA Behringer Brennan Ce
jn Coxreels Dixon Enerpac Europower Flow
Ezy Goodyear Hedland Hydro-Craft
24
Closing Slide
Waukesha 1811 Dolphin Drive Waukesha, WI 53186
Butler 4665 N 124th Street Butler, WI 53007
Phone [phone] Fax [phone]
www.hyquip.net
