Implementing Memory Protection Primitives on Reconfigurable Hardware

1
Implementing Memory Protection Primitives on
Reconfigurable Hardware
Brett Brotherton Nick Callegari Ted Huffmire
2
Project Goals

• Evaluate security primitives for reconfigurable
  hardware
• Build a real system with multiple cores
• Design a security policy for the system
• Efficient memory system performance
• Programmatic interface to system

3
System Overview
ublaze 1
ublaze 1
Ref Monitor/Arbiter
OPB
Shared External Memory
AES Core
Ethernet
RS232
4
Security Policy

• Range0?0x41400000,0x4140ffff (Debug)
• Range1?0x28000000,0x28000777 (AES1)
• Range2?0x28000800,0x28000fff (AES2)
• Range3?0x24000000,0x24777777 (DRAM1)
• Range4?0x24800000,0x24ffffff (DRAM2)
• Range5?0x40600000,0x4060ffff (RS-232)
• Range6?0x40c00000,0x40c0ffff (Ethernet)
• Range7?0x28000004,0x28000007 (Ctrl_Word1)
• Range8?0x28000008,0x2800000f (Ctrl_Word2)
• Range9?0x28000000,0x28000003 (Ctrl_WordAES)

5
Security Policy

• Access0?M1,rw,R5M2,rw,R6M1,rw,R3
• M2,rw,R4M1,rw,R0M2,rw,R0

• Access1?Access0M1,rw,R1M1,rw,R9
• Access2?Access0M2,rw,R1M2,rw,R9
• Trigger0?M1,w,R7
• Trigger1?M1,w,R8
• Trigger2?M2,w,R7
• Trigger3?M2,w,R8
• Expr1?Access0Trigger3Access2Trigger4
• Expr2?Access1Trigger2Expr1Trigger1
• Expr3?Expr1Trigger1Expr2
• Policy?Expr1Expr1Trigger3Access2
• Expr3Trigger2Expr1Trigger3Access2
• Expr3Trigger2Expr1Expr3?

6
Security Policy DFA
7
System Overview
ublaze 1
ublaze 1
Ref Monitor/Arbiter
OPB
Shared External Memory
AES Core
Ethernet
RS232
8
Performance Results

• One cycle latency increase for reference monitor
• 25.75 vs 26.75 cycles
• Area overhead very small
• 116 LUTs (1 increase)
• Clock speed increase
• 65 to 73 MHz

9
Impact of Moats

• Moats tested for size 0, 1, 2, 6
• Best case 0 and 6
• only a 4 decrease in clock frequency
• Area overhead minimal

10
User Interface

• Currently using Hyperterminal to connect to AES
  core via serial connection
• Tested using 128 bit key data manually parsed
  into 32 bit lines and sent via hyperterminal.
• GOAL
• Incorporate a User Interface to allow the user to
  select a data file and key file and receive the
  corresponding result over multiple communication
  platforms to test multi-core design and Reference
  Monitor.

s 5 8 16 16 0 0 0 0 ce537f5e 5a567cc9 966d9259 033
6763e 6a118a87 4519e64e 9963798a 503f1d35
11
User Interface

• Progress
• Implemented User Interface in C to allow more
  functionality and user friendliness.
• SERIAL OR ETHERNET? 1-SERIAL2-ETHERNET
• ENCRYPT OR DECRYPT? 1-ENCRYPT2-DECRYPT
• INPUT FILENAME
• KEY FILENAME
• OUTPUT SENT TO OUTPUT.TXT

12
Demo

• Demo
