A High Density Carbon Nanotube Capacitor for
Decoupling Applications
  • Mark M. Budnik, Arijit Raychowdhury,
  • Aditya Bansal, Kaushik Roy
  • July 27, 2006

3
A High Density Carbon Nanotube Capacitor
  • Introduction to Decoupling Capacitors
  • Carbon Nanotube Capacitor Physical Structure
  • Carbon Nanotube Electrical Model
  • Carbon Nanotube vs. Conventional Capacitors
  • Capacitance per Unit Area
  • Leakage per Unit Area
  • Conclusions

4
Introduction to Decoupling Capacitors
  • Decoupling capacitors are used to reduce supply
    voltage variations in advanced processors


Input Voltage
i (t)
-
5
Integrated Decoupling Capacitor Structure
A
t
A
6
Traditional Decoupling Capacitors
  • Problems
  • Parallel plate topology - low capacitance / unit
    area
  • Expensive die area
  • High leakage current
  • Algorithm placement
  • Improvements?
  • Improve dielectric material - limited
  • Increase area - more expensive, more leakage
  • Decrease dielectric thickness - more leakage
  • Increase number of layers - unproven

7
Carbon Nanotube Capacitor Alternative
  • Metallic, single wall carbon nanotubes
  • Offer large surface area to volume ratio

1nm
1nm
? 1?m
8
Carbon Nanotube Capacitor (CNCAP)
C
C
A
A
C Cathode A Anode
C
C
A
A
C
C
A
A
C
C
A
A
9
CNCAP Electrical Model
Parallel CNTs
CNCAP Model
R/2
L/2
L/2
R/2
Cathode
Front
End
CQ
CQ
L
CG
CC
CQ
CT
R/2
L/2
L/2
R/2
Front
End
R
CQ
CG
Anode
10
Capacitance Per Unit Area
Separation 2 nm 3 nm 4 nm
CC 22.8 aF / µm 18.1 aF / µm 15.6 aF / µm
CT 20.4 aF / µm 16.6 aF / µm 14.4 aF / µm
4xCT 81.6 aF / µm 66.4 aF / µm 57.6 aF / µm
Capacitor Technology 2018 MOS CNCAP, s2nm CNCAP,
s3nm CNCAP, s4nm
ITRS Capacitance ( fF / µm2 ) 11 - - - - - - - - -
200 CNT Layers Capacitance ( fF / µm2 ) - -
- 2,710 1,660 1,160
11
Capacitance Leakage Per Unit Area
ILEAK
Capacitor Technology 2018 MOS CNCAP, s2nm CNCAP,
s3nm CNCAP, s4nm
Capacitance ( fF / µm2 ) 11 2,710 1,660 1,160
Leakage Current ( / µm2 ) lt 20 fA 1.83 µA 27.5
pA 0.586 fA
12
Conclusions
  • Traditional MOS parallel plate capacitors
  • Limited in ability to serve as decoupling
    capacitors
  • Limited improvements for the forseeable future
  • Metallic, single wall carbon nanotubes
  • High surface area to volume ratio
  • Small inter-tube spacing can result in
    appreciable capacitance per unit length
  • May be placed in multiple layer bundles
  • 3-D carbon nanotube capacitor structure
  • High capacitance per unit area ( gtgt 11fF /
    µm2 as a function of the number of layers)
  • Low leakage current per unit area ( lt 1fA /
    µm2 for inter-tube spacing of 4nm)
