Title: The PV industry challenge of reaching grid parity


1
  • The PV industry challenge of reaching grid parity
  • inverter solutions for residential and commercial
    applications
  • Future Energies Event, Paris, 15 April 2008

2
Our business
3
The Danfoss Group
  • Danfoss is a family-owned, global company (no
    public shares, but approx. 3 employee shares)
  • Net sales 2007
  • EUR 2,97 billion
  • Employees 22,300 worldwide
  • Production of 250,000 items per day
  • 64 manufacturing sites
  • 103 sales companies
  • 114 agents and distributors

4
World wide production and service
Global Network Regional Support 24 Hour Service
Customer and technical Support
50 Danfoss companies More than 200 dealers,
distributors and Service partners
5
Ten largest markets
400
Other activities
mill EUR
Danfoss Motion Controls Division
300
Danfoss Heating Division
200
Danfoss Refrigeration Air Conditioning Division
100
Germany
France
Denmark
Great Britain
Sweden
Italy
USA
Russia
Spain
China
6
Danfoss in the PV inverter market Background and
ambition
  • Danfoss strategy to capture the growing market
    for renewable energy solutions
  • Strong synergies with Danfoss frequency
    converters
  • 80-90 identical components
  • Lean production setup
  • 40 years of power electronics experience
  • In-house power module production
  • Test laboratories
  • Contribute to the PV industry goal of becoming
    competitive to conventional energy sources by
    providing innovative solutions based on
    well-proven technological platforms
  • It is Danfoss ambition to become a leading
    inverter supplier in the industry

7
Danfoss Solar Inverters - Value chain and
customer support
PV Module Manufacturer
Installers
Danfoss Solar Inverters
Distributors System Integrators
End user
  • Our Customers Distributors, System Integrators
    and Module Manufacturers
  • Dual Business Strategy Danfoss Brand and Private
    Label Concept
  • Customer Support Management
  • Service Hotline and local service and support
  • Marketing support
  • Comprehensive training program
  • Web-based support tools

8
The PV Industry Challenge
  • Drive down system costs
  • Provide standardised solutions
  • Industry standard quality for long life
  • Easy installation and service
  • Attain cost efficient and dependable solutions
    known from more mature industries - fast

9
Inverter range/Market coverage
Residential installations 0-20 kWp
Commercial installations 10-500 kWp
TripleLynx
UniLynx
Powerplant installations gt500 kWp
10
TripleLynx Inverter Range
  • 3-phase, grid connected
  • Inverter. Transformerless
  • The range covers 10, 12.5
  • and 15 kW in IP54 cabinet
  • TLX 10k
  • TLX 12.5k
  • TLX 15k
  • Appropriate for applications from 10 kW to
    several MW
  • Intelligent Inverter Solutions

11
TripleLynx
  • TripleLynx sets new standard for string inverters
  • Wide operation specifications
    Voc
    1000v max., 250-800v MPP range. 3x12 A DC current
  • Max efficiency 98
  • High MPP tracker efficiency 99,9 at static and
    99,4 at dynamic irradiation
  • Three DC string input strings working
    independently
  • With TripleLynx, string inverters have become an
    attractive alternative to central inverters for
    large applications

12
TripleLynx
  • Installation flexibility and cost efficiency
  • Suitable for installations from 10 kW up
    to several MW.
  • Commercial roof top
  • Trackers
  • Power plants
  • Etc
  • High voltage ensures minimum DC loss when
    transferring energy from the panels
  • Weight of just 35 kg makes the inverter easy to
    handle
  • Cable costs reduced by 40-60 compared to
    conventional string inverters
  • Strong alternative to central inverters

13
TripleLynx
  • String inverter simplicity and availability
  • Available at the local distributor
  • Standard technology
  • Integrated data logger RS485 network
  • No special training needed
  • Can be installed and serviced by the local
    installer

14
UniLynx Inverter Range - Indoor and Outdoor
  • Single phased, grid
  • connected inverter with
  • transformer
  • The range covers 1.8, 3.6
  • and 5.4 kW in IP21 and IP54 cabinet
  • ULX 1800i
  • ULX 3600i
  • ULX 5400i
  • ULX 1800o
  • ULX 3600o
  • ULX 5400o
  • Intelligent Inverter Solutions
  • Unique Versatility

15
UniLynx Inverter Range Indoor and Outdoor
  • Unique Versatility
  • Multi DC string input
  • strings working independently
  • Individual/parallel configuration
  • allows for varying types and angles of panels
    and still gain max. output
  • 5 inch or 6 inch modules choose between High
    voltage and Medium voltage
  • Handles thin film modules
  • One inverter for 16 countries

16
UniLynx Inverter Range Indoor and Outdoor
  • Optimal Energy Output
  • High MPP tracker efficiency - 99,9 at static and
    99,4 at dynamic irradiation
  • Ride Through algorithm stays on grid
  • Derating Function remains working at
    max possible level
  • Early start-up and late stop of daily production
    uses two MPP tracking methods

17
UniLynx Inverter Range Indoor and Outdoor
  • Easy and Safe to Install and Service
  • Standard connection for DC input and AC output
    cannot
    be connected wrongly
  • Integrated DC switch easy and safe
    disconnection
  • Quick exchange of individual PCB due to modular
    design
  • Service Tool allows for easy configuration,
    monitoring and software update

18
The PV Industry Challenge
  • Drive down system costs
  • Provide standardised solutions
  • Industry standard quality for long life
  • Easy installation and service
  • Attain cost efficient and dependable solutions
    known from more mature industries - fast

Danfoss aims to contribute to the PV industry
goal of rapidly reaching grid parity by
providing innovative solutions based on
well-proven technological platforms
19
Making Modern Living Possible with Danfoss Solar
Inverters
