1Near Infrared Spectroscopy for biomass studies
2OVERVIEW
- 1. About the Center NIRCE
- 2. NIR spectroscopy on biomass
- 3. MSPC an example
- 4. Offline mixtures
3OVERVIEW
- 1. About the Center NIRCE
- 2. NIR spectroscopy on biomass
- 3. MSPC an example
- 4. Offline mixtures
4NIRCE 2002-2003
- Biofuels Umeå
- Biofuels Vasa
- Forest seeds Umeå
- Calibration Umeå
- Medical and Optical Vasa
- Short courses
5NIRCE 2004-2006
- NIRCE ONLINE
- NIRCE IMAGE
- NIRCE CLINICAL
6What do we offer?
- Graduate courses and short courses
- Research projects
- Advice and consulting
- Method development
- Instrument pool
- Workshops and symposia
- NIR2007
7OVERVIEW
- 1. About the Center NIRCE
- 2. NIR spectroscopy on biomass
- 3. MSPC an example
- 4. Offline mixtures
8Bioenergy
Pulp and paper
Forestry
Non-food
Building materials
Textiles
Biomass
Consumer products
Food feed
Feed and safety
9(No Transcript)
10Where is biomass found?
- Biotechnology
- Natural products
- Bioenergy
11What is special about biomass?
- O-H
- C-H
- N-H
- CO
- different atom sizes good
- IRNIR energy movements of bonds
12?
?
?
13Near Infrared Spectra (NIR)
Cosmic Gamma Xray Ultraviolet Visible NIR
Infrared Microwaves
- 780-2500nm
- Suitable for all organic and bio materials
- Robust for industrial use
- Good penetration depth
- Many modes of measuring
- Powerful multivariate results
14Near Infrared Spectra
- Fast
- Simple sample preparation
- Nondestructive
- Online for process applications
- Need for calibration
- Opportunity for data analysis
15OVERVIEW
- 1. About the Center NIRCE
- 2. NIR spectroscopy on biomass
- 3. MSPC an example
- 4. Offline mixtures
16NIR for Process Monitoring in Energy Production
by Biofuels
- Tom Lillhonga
- Swedish Polytechnic
- Vasa, Finland
- tom.lillhonga_at_syh.fi
- Paul Geladi
- Head of Research
- NIR Center of Excellence
- Umeå, Sweden
- paul.geladi_at_btk.slu.se
17Alholmens Kraft
- Worlds largest biomass-fuelled power plant
- Fuels biofuels, peat and coal
- Almost 1 km2 of storage
- Furnace is 15 ton sand fluidized-bed
- One 20 ton truck every 5 min.
- www.alholmenskraft.com
18A reminder
19(No Transcript)
20(No Transcript)
21(No Transcript)
22Problem definition
- Biofuel consumption 750-1000 m3/h
- Large variations in moisture content
- Moisture determination off-line is very slow and
not valuable for process monitoring - Unwanted variations in steam and
- electricity production
- Reduced competitive strength
23Controls
z1
zJ
Industrial process
x1
y1
Inputs
Output(s)
xK
yM
y(t) Fx(t),z(t)
24y(t) Fx(t),z(t)
- F should be known
- x(t) should be known
- z(t) set by operators
25Inside
- Ambient temperature -25 to 25
- Dust
- Humid
- Steam and compressed air
- Heavy equipment
26Sampling and measurements
- Samples were collected manually from a conveyor
belt (at line) - A digital photo was taken of every sample
- NIR-spectra at-line
- Reference samples analysed off-line by industrial
standard 17h_at_105
27Sampling and measurements
- Measurements were done during summer of 2003
- Samples were collected manually from a conveyor
belt (at line) - Sample temperature was measured
- A digital photo was taken of every sample
- Grinding was tried (Retsch Mill SM2000)
- NIR-spectra at-line
- Reference samples analysed off-line by industrial
standard
28Foss NIRSystems 6500 grating instrument (Direct
Light)
2 Si 4 PbS
?0
71 W
13 cm
monochromator grating
5 cm ø
29Det
Det
Integrating sphere
Det
Mirror
30Process NIR spectrometer based on moving grating
31(No Transcript)
32(No Transcript)
33(No Transcript)
34Dataset
- NIR-spectra, 400-2500 nm, every 2 nm
- All spectra averages of 32 scans
- Calibration set 160 samples
- Test set 61 samples
35Spectra of calibration set (3 outliers)
Milled samples
36PCA-model
- All calculations are done with MATLAB 6.5 and
PLS_Toolbox v. 2.1 and v. 3.0 - Identification and removal of outliers
- Clustering observed
37Score plot of PCA-components 1 and 2
Series start
38Sample moisture (replicates with red)
Moisture,
Sample number
39Moisture histogram
40PLS-model
- Pre-treatment of spectra
- - noisy wavelengths removed
- (2300-2500 nm)
- - smoothing and second derivative
- calculated with Savitzky-Golay method
- Mean-centred spectra
- NIPALS- algorithm and cross validation (venetian
blinds) used - RMSECV 2.6 for 7 components
41Percent Variance Captured by PLS-Model
-----X-Block-----
-----Y-Block----- LV This
LV Total This LV Total
1 18.09 18.09 45.48 45.48
2 19.52 37.61 17.75 63.23
3 41.02 78.63 3.91 67.14
4 1.728 0.35 10.07 77.21
5 2.118 2.46 4.76 81.97
6 1.138 3.59 4.06 86.02
7 0.788 4.38 3.96 89.98
8 1.008 5.38 1.90 91.88
9 0.688 6.06 1.75 93.63
10 0.498 6.55 1.54 95.17
42Loading-plot for PLS-component 1
43Diagnostics for PLS-model
Moisture,
RMSECV 2.6 for 7 components
RMSEC
PLS Comp.
44Predicted vs. measured moisture of calibration set
r2 0.85
45PLS-predictions on test set
Moisture,
lab o NIR pred.
Sample number
46Acknowledgements
Stig Nickull Bo Johnsson Johanna
Backman Sari Ahava Morgan Grothage
Sten Engblom
47Standard deviation for replicates
48Future experiments
- Off-line measurements on fuel mixtures (H2O, ash,
energy) - Improved sampling probe
- Seasonal effects?
- Temperature
- Time series analyses
- On-line measurements
- Model included in process monitoring
49OVERVIEW
- 1. About the Center NIRCE
- 2. NIR spectroscopy on biomass
- 3. MSPC an example
- 4. Offline mixtures
50Off-line work
- At SYH
- CD 128l InGaAs 900-1700nm
- Integrating sphere with lamp
- Large glass plate
- Mixtures
- Linda Reuter of Wismar Polytechnic
51(No Transcript)
52Simplex mixture design
Coal
1/0/0
0.5/0/0.5
0.5/0.5/0
0.33/0.33/0.33
0/1/0
0/0/1
0/0.5/0.5
Biofuel
Peat
53(No Transcript)
54Coal
Peat
Biofuel
H2O
H2O x 3
Mixing (remixing)
Ash x 3
Energy x 3
10x
NIR spectrum 32 scans
55Average reference values moisture, energy, ash,
spectra all 10 replicates
Average spectra and average reference values
Individual references values and average spectra
33x128
Figure 10
56(No Transcript)
57(No Transcript)
58(No Transcript)
59(No Transcript)
60(No Transcript)
61(No Transcript)
62(No Transcript)
63(No Transcript)
64(No Transcript)
65(No Transcript)
66Conclusions
- Max bias / variance
- -moisture 1.8/ 3
- -energy 0.5 / 0.75 MJ/Kg
- -ash -5 / 7
- Reference replicates important
- Spectral replicates important
67Works well
- Design repeated in score plot
- Classification possible
- Within run error smaller than between-run error
- PLS prediction H2O, ash, energy
