Title: Some History and


1
Some History and The International
Amateur Radio Union
2
Before Radio
  • 1840 - Samuel Morse patented his Telegraph
  • 1861 - First US transcontinental telegraph
    message
  • 1866 - First transatlantic telegraph cable
  • 1865 - International Telegraph Union founded for
    regulation of international telegraph
    communications
  • First supranational organisation to regulate a
    public service

3
Beginnings
Heinrich Hertz in 1887 demonstrated that
electromagnetic waves could be transmitted
through the air
4
Radio Arrives
  • 1895 - Marconi transmitted and received radio
    waves
  • 1901 - First transatlantic radio signal
  • 1907 First commercial transatlantic radio
    message, Clifden to Glace Bay
  • 1903 Berlin, preliminary conference on
    regulating wireless telegraphy
  • Nine nations attended including the US

5
Amateur Radio Arrives
  • Communication through thin air fascinated
    experimenters from the start
  • Widespread unregulated experimentation
  • Interference with the growing radio services
  • Pressure grows for governmental regulation

6
Why Regulation?
  • Radiofrequency spectrum is a finite reusable
    natural resource
  • Used worldwide by a range of essential services
  • Crosses national frontiers frequency
    coordination essential
  • Need for international coordination recognised
    from the earliest days

7
Regulation Arrives
  • 1906 - Berlin, 29 countries form International
    Radiotelegraph Union
  • Introduced first regulations for wireless
    telegraphy now the ITU Radio Regulations
  • Established an International Table of Frequency
    Allocations (500 to 1000 kHz 300 to 600 metres)
  • National allocations to be notified to a central
    registrations agency the Berne Bureau
  • International Radiotelegraph Conferences to be
    held every five years

8
Demand for Increased Regulation
  • Wireless gaining priority in safety at sea
  • Commercial services growing
  • Increasing experimentation interference
    protection of services essential
  • April 1912 Titanic disaster increased pressure
    for regulation
  • President Taft pressed for July 1912 Conference
    in London to adopt universal government
    regulation

9
1912 International Radiotelegraph Conference
  • New services like Time and Weather below 188 kHz
  • Experimental Activity above 1.5 MHz
  • Frequencies above 1.5 MHz (200 metres) considered
    useless short waves
  • Dealt with spectrum of 150 to 1000 kHz (300 to
    2000 metres)
  • 1912 US Radio Act restricted private stations
    to above 1.5 MHz

10
Consequences
  • Initial reduction in experimentation
  • Serious experimenters rose to the challenge of
    the short waves
  • Devised innovative HF circuits and antennas
  • Key to success open sharing of information
    attracted new amateurs
  • Other services seeing their success sought
    allocations below 200 metres

11
Amateur Radio Landmarks
  • Experimentation existed from the start
  • 1912 Dublin Wireless Club formed
  • 1913 RSGB founded
  • 1914 ARRL founded
  • 1920 US coast to coast two way message by
    amateur relay stations in 6½ minutes
  • Nov 1921 Paul Godley sponsored by ARRL received
    signals in Scotland from over 30 transatlantic
    stations
  • 1924 Worldwide amateur communication on
    wavelengths below 100 metres - potential

12
Some More
  • 1923 First amateur two way transatlantic
    contact 27 Nov 2130 GMT
  • Fred Schnell 1MO and Leon Deloy 8AB in Nice
    exchanged signals on 2.72 MHz (110 metres)
  • Proved that frequencies above 1.5 MHz not useless
  • Established superiority of CW over spark end
    of the spark era

13
Amateurs Lead the Way
  • 1925 An important year
  • Amateur radio provided communications for the two
    MacMillian expeditions to the arctic
  • Amateur station with the US Naval Fleet sent
    messages back from Australia when standard navy
    equipment could not
  • 1925 IARU founded

14
Why the IARU ?
  • Climate of increasing regulation
  • Far-sighted individuals saw the need to be
    involved in the process
  • Spectrum the lifeblood of amateur radio
    frequency bands essential
  • Broadcasting ousting amateurs from longer waves
  • Commercial concerns showing intense interest in
    amateurs results on short waves
  • Representatives of 23 national associations
    representing 30,000 radio amateurs (mostly in the
    USA) met in Paris in 1925 and founded the IARU

15
General Purpose
  • IARU was formed
  • For better mutual use of radio spectrum among
    amateurs
  • To develop amateur radio worldwide
  • To successfully interact with the agencies
    responsible for regulating and allocating radio
    frequencies
  • A timely initiative in the light of the challenge
    of the upcoming Washington Radiotelegraph
    Conference in 1927

16
US Bands pre 1927
  • 1.5 2.0 MHz 150 to 200 metres
  • 3.5 4.0 MHz 75 to 85.7 metres
  • 7.0 8.0 MHz 37.5 to 42.8 metres
  • 14.0 16.0 MHz 18.7 to 21.4 metres
  • 56.0 64.0 MHz 4.69 to 5.35 metres
  • 400 401 MHz 0.75 metres
  • Long distance communication was a feature of the
    first four bands

17
1927 Conference
  • 80 countries participated over 8 weeks as did the
    newly formed IARU (mainly ARRL)
  • United States amateurs to get internationally
    what they had in the US
  • Most other countries favoured only narrow
    frequency bands
  • Favourable US, Australia, Italy, New Zealand
  • Opposed Britain, Germany, Netherlands, Japan ,
    Belgium
  • Much compromise before final outcome US support
    for amateur radio crucial

18
Outcome for Amateurs
  • Frequency bands allocated to the various
    services, broadcasting, fixed, maritime and
    aeronautical mobile, amateur and experimental
  • International harmonically related amateur bands
    established near 160, 80, 40, 20, 10 and 5 metres
  • International system of call signs introduced
  • First international legal recognition, definition
    and regulation of the amateur service
  • Would not have been possible without the support
    of the US and others and the lobbying of
    ARRL/IARU
  • First success for organised amateur radio

19
Definition
  • Article 1, 14 Amateur Station A station used
    by an amateur, that is, by a duly authorised
    person interested in radio technique solely with
    a personal aim and without pecuniary
    interest

20
ITU Radio Regulations Amateur Service
  • 1.56 amateur service A radiocommunications
    service for the purpose of self- training,
    intercommunication and technical investigations
    carried out by amateurs, that is, by duly
    authorised persons interested in radio technique
    solely with a personal aim and without pecuniary
    interest
  • 1.96 amateur station A station in the
    amateur service
  • 1.98 experimental station A station
    utilising radio waves in experiments with a view
    to the development of science or technique. This
    definition does not include amateur stations

21
Comments QST 1928
  • They forget that radio is an international
    affair and that it has been agreed that radio is
    to be governed by international treaties.
  • If they do not seem enough they were the best
    that could be got in the face of united
    opposition.
  • We have received a great deal more that most of
    the world wanted us to have.
  • The preservation of amateur radio on the face of
    the earth to-day is very largely attributable to
    the efforts of the United States Delegation.

22
International Bands After 1927
  • 1.715 2.000 MHz - Shared (1.5 2.0)
  • 3.500 4.000 MHz - Shared (3.5 4.0)
  • 7.000 7.300 MHz Exclusive (7.0 8.0)
  • 14.0 14.400 MHz - Exclusive (14.0 16.0)
  • 28.0 30.000 MHz Amateurs/Exp (--------)
  • 56.0 60.000 MHz Amateur/Exp (56 64)

23
Madrid Conference 1932
  • 77 governments represented lasted 14 weeks
  • Amateur frequency bands unchanged
  • IARU admitted to participation in the
    International Technical Consulting Committee on
    Radiocommunications
  • International Telegraph Union (Paris 1865) and
    the International Radiotelegraph Union (Berlin
    1906) merged to form the International
    Telecommunications Union (ITU)

24
What is the International Amateur Radio
Union ?
  • An international federation of national
    associations of licensed radio amateurs
  • 1925 founded 23 Societies 30,000 radio
    amateurs
  • Now about 160 societies 3 million radio
    amateurs

25
Main Objectives
  • The protection, promotion and advancement of the
    Amateur and Amateur Satellite Services and the
    support of member societies
  • Representing the interests of amateur radio at
    and between conferences of international
    telecommunications organisations
  • Enhancement of the self-training role of amateur
    radio
  • Promotion of technical and scientific
    investigation
  • Promoting amateur radio as an emergency
    communications resource

26
Organisation
  • Divided into three Regions which mirror those of
    the ITU
  • One of these Regions hold a Conference of Member
    Societies each year on a rotational basis
    arrive at common positions
  • Regional Executive Committees which attend to the
    affairs of the regions between Regional
    Conferences
  • Worldwide policies developed

27
REGIONS
  • Region 1 Europe, Africa, Middle East and
    Northern Asia 90 National Societies founded
    1950
  • Region 2 North and South America- 40 Member
    Societies founded 1964
  • Region 3 Rest of Asia and the Pacific
    (Australia, New Zealand, Japan) 30 Member
    Societies founded 1968

28
(No Transcript)
29
Region 1 Conference
  • Cavtat, Croatia November 2008
  • 52 National Societies represented
  • Four Committees
  • Credentials and Finance
  • Administration and Organisation
  • HF
  • VHF and Microwave
  • 120 papers
  • External Relations Committee

30
International Governance
  • IARU Administrative Council
  • President, Vice President, whose appointment is
    ratified by a vote of Member Societies, Secretary
    appointed by Society hosting the Headquarters
    (ARRL) plus two representatives from each of the
    three IARU Regions
  • Proposals by Member Societies, Regions or the
    Administrative Council must be published in a
    Calendar circulated to all member societies which
    have five months for a postal vote

31
(No Transcript)
32
Functions of Admin. Council
  • Coordinate the representation of amateur radio at
    ITU Conferences and with Regional organisations
  • Coordinate long-range planning in close
    cooperation with Regional organisations
  • Coordinate the work of the Regional organisations
  • Formulate proposals for consideration by National
    Societies

33
Some Things it Does
  • Represents amateur radio at ITU Working Parties,
    at World Radio Conferences (WRCs) and with
    National administrations through its Member
    Societies
  • Works in international standards forums to seek
    to protect amateur radio
  • Seeks to protect the bands through an organised
    monitoring service
  • Develops consensus among Member Societies on
    issues such as band plans, optimum spectrum
    usage, standards for repeaters and other matters
    and amateur qualifications
  • Seeks to protect and enhance spectrum allocations
  • Operates a worldwide QSL service through its
    network of National Societies

34
International Recognition
  • Recognised by the UN as a Non-governmental
    Organisation (NGO)
  • Sector Member in the Radiocommunications ( R )
    and Telecommunications Development (D) Sectors of
    the ITU
  • Participates in World Radio Conferences
  • Participates in ITU-R Study Groups their Working
    Parties and Task Groups, Radiocommunications
    Advisory Group (RAG), Conference Preparatory
    Meetings and ITU-D Study Group 2
  • Regional organisations participate in the
    regional telecommunications organisations such as
    CEPT in Europe

35
Some Achievements of IARU
  • WARC-79 new bands at 10, 18 and 24 MHz
  • Progress towards international licence
    harmonisation
  • Extension of 7 MHz band in ITU Regions 1 and 3
    WRC-03
  • Improvements in international roaming for
    amateurs CEPT Licence

36
Some Future Objectives
  • New Bands
  • 500 kHz (WRC-11 15 kHz- 415-526.5kHz)
  • 5 MHz (150 kHz band)
  • 70 MHz (500kHz secondary Region 1)
  • Expansion
  • 1800-1810 and 1850-2000 kHz in Region1
  • 7200-7300kHz in Regions 1 and 3 100 kHz
  • 10100-10350 kHz 200 kHz
  • 14000-14400 kHz 50 kHz
  • 18 and 24 MHz 100 kHz
  • 50 MHz Region 1 50-52 MHz with at least 500 kHz
    exclusive (ECA 50-52 MHz Secondary)

37
Some Achievements of IRTS
  • Secured early access to extended 7 MHz band post
    WRC-03
  • Had it upgraded to Amateur Primary on 29 March
    2009
  • Got the Experimenter Exam on a firm footing
  • Secured the general release of 70 MHz
  • Secured three channels at 5 MHz
  • Secured a footnote in the ECA relating to 70 MHz
  • Produced a CD Course Guide
  • Digimodes on 10 MHz
  • Extra power for specified contests and some 500
    kHz permits in pipeline

38
The Case for Amateur Radio
  • Develops national electronic expertise
  • Contributes to electronic innovation
  • Promotes the exploration of propagation phenomena
    and develops methods for the more efficient use
    of spectrum
  • Provides an emergency communications resource
  • Provides a self- training environment
  • Promotes international friendship and
    understanding
  • Is a disciplined and self regulating service

39
The Realities
  • Spectrum allocation and management has always
    been both a political and a technical process
  • World Radio Conferences are the means by which
    world governments distribute the resource of the
    radio frequency spectrum
  • Organised Amateur Radio must be involved in this
    process in a coordinated way both nationally and
    internationally so as to preserve and enhance
    spectrum allocations if you are not even in the
    game you cant possibly win

40
Financing
  • The Regions are financed by the Member Societies
    paying a levy per licensed member Region 1
    about 1.20
  • In 2008 IRTS paid 930 to IARU we would pay
    nearly twice this if all EIs were members of
    their National Society
  • International Secretariat funded by the ARRL
    which hosts it

41
The Union
  • The IARU is an International Union of licensed
    radio amateurs who are members of their National
    Societies
  • As a Union it works to protect and further the
    interests of amateur radio and the radio amateur
  • Support the work of the Union by being a member
    of your National IARU Society

42
Serving Amateur Radio and the Radio Amateur
1925 - 2009
Write a Comment
User Comments (0)
About PowerShow.com
