Title: UD Trucks Sydney Truck Show Impression 1


1
(Trucks used are indicative, trucks are stretched
to match actual sizes)
UD Trucks Sydney Truck Show Impression 1
2
(Trucks used are indicative, trucks are stretched
to match actual sizes)
UD Trucks Sydney Truck Show Impression 2
3
(Trucks used are indicative, trucks are stretched
to match actual sizes)
UD Trucks Sydney Truck Show Impression 3
4
UD Trucks Sydney Truck Show Impression 4
5
Red lights mounted behind feature wall Lighting
back wall
UD Trucks Sydney Truck Show Impression 5
6
Trusses containing spots
Feature wall Height approx 8,2m Full color
banner (11125x5375mm WxH)
Truss wall Height 5,5m
Full color Banner in Frames (5175x5375mm WxH)
42 Plasmascreen
Full color logo Vinyl Approx 1350 x 450mm
Aluminum Specifications Display
Standing Table with white top, White barstools
Slogan in Grey Vinyl - 2500mm Wide
40 LCD Unit
Floor Carpet Tiles 1x1m in Black and Red
40 LCD Unit
White infodesk, white backwall 2400mm High
(Storage area)
UD Trucks Sydney Truck Show Impression 6
7
All Trussing backwall Feature wall Rigged
from ceiling
Feature wall under 10 Angle
11700mm Truss
8200mm Truss
5500mm Truss
2400mm
11700mm Truss
UD Trucks Sydney Truck Show Impression 7
8
Black squares indicate actual sizes of GW, PK
and MK
MK
PK
GW
GW
MK
PK
UD Trucks Sydney Truck Show Impression 8
9
30m
8000mm
2000mm
Storage
42 Plasma
Infodesk
MK Cabin 9735x2200
MK Cabin 9735x2200
18m
PK Cabin 10860x2450
PK Cabin 10860x2450
GW Cabin 7185x2490
GW Cabin 7185x2490
10 M Truss
40 LCD Display
GW Cab Chassis Overall Length 7185 Overall
Height 2970 Overall Width 2490
PK Cab Chassis Overall Length 7730-
10860 Overall Height 2715 Overall Width 2450
MK Can Chassis Overall Length 8235-
9735 Overall Height 2475 Overall Width 2200
40 LCD Display
UD Trucks Sydney Truck Show Impression 9
10
Foot of feature wall Red painted MDF Columns
mounted around trussing Column 500x500mm Approx
2300mm High 10 angle Front piece 250mm wide
Approx 1950mm High (10 angle oposite
direction)
Storage 8000mm x 2000mm x 2400mm (LxDxH) wall
flats
40 LCD Display Unit Red MDF Unit, 1400mm x 800mm
(WxD) Heifht front 200mm Height Rear 700mm 42
Plasmascreen built-in
Infodesk White MDF Desk, 2200mm x 800mm x 1000mm
(LxDxH) 60mm high plint Rear contains lockable
doors (3x) 1 shelf inside
UD Trucks Sydney Truck Show Impression 10
11
Storage 8000mm x 2000mm x 2400mm (LxDxH) wall
flats Corner section for trussing of backwall
approx 650mm x 450mm (WxD)
UD Trucks Sydney Truck Show Impression 11
12
Aluminum A3 size Specifications Display
UD Trucks Sydney Truck Show Impression 12
