Cytoskeleton Systems

1
Chapter 15

• Cytoskeleton Systems

2
Cytoskeleton

• Highly structured portion of the cytosol
• Network of interconnected filaments and tubules
  from the nucleus to the plasma membrane
• Functions as
• Architectural framework
• Internal organization moves organelles and
  cellular components
• Maintain complex shapes
• Very dynamic and changeable
• Important for cell movement and division

3
Major Structural Elements

• Microtubules
• Microfilaments
• Intermediate filaments
• See similar things in bacteria assembly of
  fibers but not AA sequence
• All are linked structurally and functionally
• Each has its major structural component and other
  associated proteins hat all for diversity of
  function

4
Study using EM and fluorescent antibody staining
5
Know everything but size
6
Drugs Used to Study

• Colchicine prevents tubulin polymerization
• Taxol forces microtubule formation
• Cytochalasin D and latrunculin prevents actin
  polymerization
• Phalloidin prevents the depolymerization of
  actin

7
(No Transcript)
8
Microtubules (MT)

• Largest fiber
• 2 groups
• Axonemal MT specific cellular structures such
  as cilia, flagella and basal bodies
• Axoneme is the central shaft and has axonemal MT
  and associated proteins
• Cytoplasmic MT loosely organized and dynamic,
  variety of functions
• Maintain axons polarized shapes spatial
  disposition and directed movement of vesicles and
  organelles and mitotic and meiotic spindles

9
Microtubules

• Tubulin heterodimers building blocks
• Straight hollow tubes of varying length
• Longitudinal array of linear polymers made up of
  protofilaments usually 13 around a lumen

10
Tubulin

• ?-tubulin (dark orange) and ?-tubulin (yellow)
  linked non-covalently into a heterodimer that
  doesnt dissociate
• Share 40 AA homology but very similar shape
• 3 domains
• GTP-binding domain at N terminus
• Middle domain that can bind colchicine
• MT-associated protein (MAP) interacting domain at
  the C terminus
• Both ends of the MT are chemically and
  structurally distinct polarity
• Most organisms have related but not identical
  genes isoforms
• Differs mainly at the C end where they bind MAPs

11
MT Formation
12
MT Formation

• Reversible polymerization of dimers
• Clusters of dimers called oligomers and act as
  the nuclei of MT formation nucleation process
• See a lag phase as the start is very slow
• MT grows by addition of subunits elongation
  phase
• This phase is very fast
• Eventually the free tubulin becomes limiting
  factor so see a plateau phase

13
Stages of MT Formation
14
Tubulin Addition

• Faster growth at the plus end - ? tubulin end
• Concentration of free tubulin at either end will
  determine the rate of addition or subtraction
• Higher critical free tubulin at the plus end
  rather than the minus end will lead to growth at
  the plus and disassembly at the minus end
• Process called treadmilling

15
MT Growth
16
MT Formation Requires GTP

• Dimer bind 2 GTP molecules one on each subunit
• GTP on the ? subunit is hydrolyzed after addition
  to the MT
• GTP is essential but the hydrolysis to GDP is not

17
Dynamic Instability Model

• 2 populations 1 growing and 1 shrinking
• Growing end has a stable tip that has a GTP-cap,
  adds new dimers
• If high tubulin then it is added quickly,
  otherwise it slows down
• Shrinking end had GDP and tip is unstable
  disassembles
• At some tubulin the hydrolysis of GTP on the ?
  subunit exceeds the addition of new dimers

18
Dynamic Instability (cont)

• Alternate between growing/shrinking, usually at
  the plus end
• Growth then shrink MT catastrophe
• Shrink then growth MT rescue

19
(No Transcript)
20
MT Organizing Centers (MTOC)

• Site of MT growth initiation and acts as anchor
• In mitotic cell it is the centrosome and is near
  the nucleus
• Animal cells also have 2 centrioles around the
  centrosome in a diffuse granular material called
  the pericentriolar material

21
Centrioles

• 9 pairs of triplet MT at 90
• important in basal body formation for flagella
  and cilia
• No centriole then the spindles are poorly
  organized during cell division
• Not part of plants

22
(No Transcript)
23
Centrosomes and MOTC

• Centrosomes use ?-tubulin
• Ring structure seen at the base of MT
• Acts as a nucleation site for new MT, anchored by
  the minus end, plus end moves to the cell
  membrane
• Fixed polarity
• MOTC influences the number of MT can change it
  during special cell functions
• Also helps stabilize the MT such as with the
  kinetochore on mitotic chromosomes or cell cotex
  and plus end tracking proteins

24
Functions of MT
25
Drug Effects on MT Assembly

• All are anti-mitotic drugs
• Colchicine binds to tubulin dimer and then
  binds to growing MT but no additional dimers can
  be added resulting in disassembly
• Vinblastine/vincristine acts as anti-cancer
  drug rapid cell growth makes them
  preferentially susceptible for drug
• Taxol stabilizes MT and arrests cells in
  mitosis
• Used in treating breast cancer

26
MT-Associated Proteins (MAPs)

• Level of regulation to organize and function of
  MT
• MAPs bind at intervals along MT wall
  projections that interact with other filaments
  and cellular structures
• Also involved in MT assembly regulations,
  increases stability

27
MAPs

• Motor MAPs
• Kinesin (moves to plus end) and dynein (moves to
  minus end)
• use ATP to drive transport of vesicles and
  organelles
• generate sliding forces
• Non-Motor MAPs
• control MT organization in cytoplasm specific
  for each type
• especially in neurons send out neurites which
  becomes axon carry electrical signals protein
  is MAP2, looser bundles
• MT bundles are denser in axons protein is Tau,
  tigher bundles

28
Microfilaments (MF)

• Smallest filament contractile fibers
  interacting with myosin fibers
• In almost all cell types and have many functions
• amoeboid motion (along surface)
• cytoplasmic streaming (pattern of flow in cell)
• produce cleavage furrow
• attachment to adjacent cells
• cell shape cell cortex and in microvilli

29
Actin

• Building block of MF have a binding site for
  ATP or ADP G-actin (globular)
• G-actin polymerizes to MF F-actin
• G/F-actin can bind many proteins actin binding
  proteins which regulates or modifies actin or are
  regulated/organized by association with actin
• Actin is highly conserved differs in many cells
  but can substitute in function

30
Actin (cont)

• 2 major groups based on sequence
• muscle specific actins - ? actin
• non-muscle - ? and ? actins migrates to
  different areas of cell
• ? actin is predominately at the apical surface
• ? actin is concentrated at basal and sides of
  cells
• Actin-related proteins (Arps) less similar to
  actin

31
Actin Polymerization

• G-actin monomers reversibly polymerize into
  filaments (lag-phase nucleation), more rapid
  polymerization elongation
• 2 linear strands of G-actin wind around each
  other to make F-actin, 13.5 actins per turn

32
Actin and Myosin

• Inherent polarity structurally and chemically
  different ends
• Use myosin subfragment (S1) to determine
  direction
• Barbed end plus
• Pointed end minus

33
Actin Polymerization

• Ends are important independently regulation of
  actin assembly/disassembly
• Add and lose faster at the plus end
• Plus end grows faster when conditions are
  favorable to adding monomers
• ATP is tightly bond to actin but its energy is
  not required for polymerization
• Plus end is ATP-actin
• Slowly, ATP is converted to ADP

34
Actin Structures

• Cells regulate actin forms
• Lamellipodium and filopodia depends on actin
  filaments
• Stress fibers adhere to the surface
• Cortex under membrane gel or lattice of actin

35
Lamellipodium and Filopodia

• Lamellipodia are less organized
• Filopodia are polarized cables with plus end
  pushing to the protrusion

36
Proteins Affecting Actin Dynamics

• Controls nucleation and depolymerization
• Actin binding proteins, phosphotidylinositol and
  small regulatory G proteins (Rac, Rho and Cdc42)
• Amount of ATP-G-actin influences rate
• Cells regulate amount thymosin ?4 binds
  G-actin profilin transfers the G-actin from
  thymosin ?4 to filament
• ADF-Cofilin binds ADP-G-actin and F-actin
  causing turnover of ADP-G-actin at the minus end
• Capping protein prevents depolymerization
  stable actin filament

37
Drugs Affecting Actin Dynamics

• Both drugs cause lose of MF from cell
• Cytochalasins prevents addition of monomers and
  results in depolymerization
• Latrunculin A sequesters actin monomer no
  growth

38
Inositol Phospholipid Regulation

• IP3 is signaling molecule for G proteins
• Phosphotidyl inositol can be phosphorylated (by
  special kinase) to polyphosphoinositides that can
  bind actin-binding proteins
• Phosphotidyl inositol (4,5)-bisphosphate bind
  profilin and CAP Z to regulate their activity
  with actin
• PIP2 binds CAP Z and causes depolymerization
